Snell ICS 1070 Specifications

Frequency Response
Sensitivity
Nominal Impedance
Crossover Frequency
Recommended Amplifier Power
Maximum Output (per pair)
Placement
Dispersion Angle (+1dB of on-axis response)
Drive Units
Video Shielding
Dimensions
Finishes
Munufactured by
FOR BUILT-IN CABINETS, A UTILITY VERSION
OF THE ACCLAIMED D7 TOWER
The unique cabinet design, placement switch and wide
dispersion tweeter of the ICS 1070 bring the performance
of a freestanding high-end tower to an in-cabinet book-
shelf enclosure. Conventional bookshelf loudspeakers
sound "chesty" and image poorly when used in in-cabinet
applications. The ICS 1070 is a 6.5-inch, D'Appolito Array,
designed by Snell chief engineer, Joe D'Appolito, to fit into
furniture and millwork, and, is tuned to compensate for
the sonic problems that these cabinet boundaries cause.
The twin 6.5-inch long throw woofers provide extended
bass and plenty of output, while the 1-inch low-resonance,
silk dome tweeter enables a large sweet spot for better
stereo imaging. The ICS 1070 uses the same components as
the Snell D7 Tower and AMC 870 in-wall monitor, mounted
in a robust, texture-painted enclosure. This high output
LCR can be used for Left, Center and Right or mixed and
matched with these two siblings to provide clean, im-
pactful sound with an effortless and "airy" soundstage...
perfect for music and movies.
ICS 1070
Design Acoustic Suspension D'Appolito Array
62Hz-22kHz+3dB
90dB
4 Ohms
2.0kHz
50-300 Watts
110dB
Wall, or Shelf
Horizontal: +45 degrees
Vertical: +12 degrees
Tweeter: 1-inch SEAS Silk Dome
Woofer: Two 6.5-inch Poly, 5mm Excursion
Standard
Height: 19.5-inches
Width: 7.75-inches
Depth: 11-inches
Cabinet: Textured Black Paint
Grille: Black Cloth over MDF Frame
Snell Acoustics, PO 3717, Peabody MA 01960
www.snellacoustics.com 978-538-6262 978-538-6266fax
ICS Series
ICS 1070
