  • Page 1 Rev. 1906181221 Part No. 161500-19-012 Copyright 2018 Winnebago Industries, Inc. All rights reserved.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1 - INTRODUCTION About this Manual ..........................1-1 Safety Messages Used in this Manual ....................1-1 Pre-Delivery Inspection ........................1-2 Before Driving ..........................1-2 Front Axle Tire Alignment ....................... 1-2 Headlight Alignment ......................... 1-2 Service and Assistance ........................1-2 Reporting Safety Defects ........................
  • Page 4 Table Of Contents Keys ..............................3-5 Passenger Workstation ........................3-5 Mirrors – Power Electric ........................3-6 Brake-Shift Interlock ........................3-7 Park Brake – Foot Pedal ........................3-7 Tow/Haul Transmission Mode ......................3-7 Map Light Switch ..........................3-7 Hazard Warning Flashers ........................3-8 Battery Boost Switch ........................
  • Page 5 Table Of Contents Ducted Roof Air Conditioning System ................... 4-17 Air Conditioner Filter ........................4-18 5 - PROPANE GAS Propane Gas Supply .......................... 5-1 Propane Accessory Connection ......................5-2 Safe Use of the Propane Gas System ....................5-3 Propane Gas Warnings and Precautions ................... 5-4 Propane Gas Pressure Regulator .......................
  • Page 6 Table Of Contents Audio/Video System Basic Operation ....................8-1 DVD Player ............................8-1 Audio/Video System Cables ......................8-2 TV (Dining Buffet) - Power Lift ....................... 8-2 Bedroom DVD/Satellite Receiver Connection ................. 8-3 TV Antenna – Digital ........................8-3 TV Antenna – Digital ........................8-4 TV Signal Amplifier .........................
  • Page 7 Table Of Contents Solid Surface Countertop – Corian® ....................11-7 Stainless Steel Appliances ......................11-7 Sink – Stainless Steel ........................11-8 Range and Refrigerator ........................11-8 Vinyl Flooring ..........................11-8 Bathroom ............................11-9 Doors and Windows ........................11-10 Vehicle Storage – Preparation ...................... 11-10 Vehicle Storage –...

  • Page 9: Introduction

    The instructions included in this manual are intended as a guide, and in no way DANGER indicates a hazardous situation extend the responsibilities of Winnebago which, if not avoided, will result in death or Industries beyond the standard written serious personal injury.

  • Page 10: Pre-Delivery Inspection

    BEFORE DRIVING National Highway Traffic Safety Administration Familiarize yourself with State/Province and (NHTSA) in addition to notifying Winnebago local regulations before traveling. There are Industries, Inc. many local rules that may impact your travels.

  • Page 11: Occupant And Cargo Carrying Capacity Label

    However, NHTSA cannot become involved in individual problems between you, your dealer, or Winnebago Industries, Inc. To contact NHTSA, you may either call the Vehicle Safety Hotline toll-free at: 1-888-327-4236; (TTY: 1-800-424-9153) or go to http://www.safercar.gov...

  • Page 12: Vehicle Certification Label

    These pressure levels must be maintained to assure proper handling, safety, 2. Chassis manufacture date. and fuel economy. 3. Month and year of manufacture at Winnebago ® 9. Rear Axle Wheel Configuration: Single or Industries Dual as it relates to the inflation.

  • Page 13: Specifications And Capacities

    80 gal. Notes: All information is based upon the most recent data available. Visit the Winnebago Industries, Inc. web page – www.winnebagoind.com – for the most current product information. The height of each model is measured to the top of the tallest standard feature and is based on the curb weight of a typically equipped unit.

  • Page 14: Owner And Vehicle Information

    Motorhome Serial Number ___________________________________________________________ Chassis Vehicle Identification No. (VIN) ________________________________________________ Vehicle Mileage at Delivery __________________________________________________________ Selling Dealer Name ________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ ® YOUR WINNEBAGO INDUSTRIES DEALER /SERVICE CENTER Name ____________________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ Contact ____________________________________________Phone ________________________ CHASSIS SERVICE CENTER...

  • Page 15: Safety And Precautions

    SECTION 2 - SAFETY AND PRECAUTIONS GENERAL WARNINGS WA RNING • Only seats equipped with seat belts are to be occupied while the vehicle is moving. • Make sure all passengers have seat belts Operating, servicing and maintaining this vehicle can expose you to chemicals fastened.

  • Page 16: Driving Safety

    SECTION 2 - SAFETY AND PRECAUTIONS • Do not operate the cruise control on icy or DRIVING SAFETY extremely wet roads, winding roads, in heavy traffic, or in any other traffic situation where a constant speed cannot be maintained. WA RNING •...
  • Page 17 SECTION 2 - SAFETY AND PRECAUTIONS • Portable fuel-burning equipment, including wood and charcoal grills and stoves shall not WA RNING be used inside the recreational vehicle. The use of this equipment inside the recreational vehicle may cause fires or asphyxiation. Do not fill propane container(s) to more •...

  • Page 18: Propane Gas Leaks

    Replacement When replacing this alarm, we recommend replacing only with the same model, or with one that is also listed for RV application. We recommend obtaining a replacement from your ® Winnebago Industries dealer.

  • Page 19: Carbon Monoxide Warning

    RV application. We Do not run engine in confined areas, such as a recommend obtaining a replacement from your garage, except to move vehicle into or out of the ® Winnebago Industries dealer. area. Further Information CARBON MONOXIDE ALARM...

  • Page 20: Smoke Alarm

    When replacing this alarm, we recommend your motorhome. We recommend obtaining a replacing only with the same model, or with one replacement only from your Winnebago ® that is also listed for RV application. We Industries dealer or a reliable RV parts supplier.

  • Page 21: Loading

    SECTION 2 - SAFETY AND PRECAUTIONS • Improper grounding of the vehicle can cause • Do not mix different construction types of personal injury. Do not plug the utility power tires on the vehicle, such as radial, bias, or cord into an outlet which is not grounded and belted tires, as vehicle handling may be do not adapt the plug to connect to a receptacle affected.

  • Page 22: Power Sofas And Beds

    SECTION 2 - SAFETY AND PRECAUTIONS Escape Window (Lift both red safety latch handles UP and Slider Window Latch push window OUT) -Typical View (Lift latch UP and slide window open) -Typical View Most slider windows along the side of any motorhome can also be used as alternate emergency exits, should the need arise.

  • Page 23: Slideout Rooms

    SECTION 2 - SAFETY AND PRECAUTIONS The ladder on your motorhome is provided for SLIDEOUT ROOMS limited access to the roof. Walking or working on the roof should be left to qualified service personnel using proper safety equipment in a safe environment. You should WA RNING only walk or work on the roof if you are qualified and have created a safe environment.

  • Page 24: Formaldehyde Information

    SECTION 2 - SAFETY AND PRECAUTIONS • Do not transport items anchored to the of the nature of the use of a motorhome, it is ladder. You could damage the ladder. natural for a motorhome to be introduced into an environment with mold spores.

  • Page 25: Roadside Emergency

    Winnebago will clean the affected area(s) and/or carefully after you are certain the lane is clear. replace affected items as it deems necessary. This is the extent of coverage provided by Winnebago • Let the vehicle coast to a stop, gently steering Industries.

  • Page 26: Jump Starting

    SECTION 2 - SAFETY AND PRECAUTIONS WA RNING Stay out from beneath the motorhome while it is suspended by the towing assembly. Do not allow passengers to occupy a towed vehicle. Death or serious injury can result. JUMP STARTING If your vehicle will not start from the chassis battery, try using the Battery Boost switch to divert power from the house batteries to the starter.

  • Page 27: Driving Your Motorhome

    SECTION 3 - DRIVING YOUR MOTORHOME The information in this section refers only to features installed or adapted to the dash and Lift to Recline Power Seat driver compartment area by Winnebago Controls ® Industries . It also includes passenger seating in the living area of the motorhome.

  • Page 28: Co-Pilot Footrest

    SECTION 3 - DRIVING YOUR MOTORHOME Armrest Adjustment –If Equipped The armrests may be swung upward out of the way for easy exit or access to the front seats. A roller on the underside of the front of the armrest also lets you adjust the resting angle for personal comfort, whether the seat is upright or reclined.

  • Page 29: Seat Belts

    SECTION 3 - DRIVING YOUR MOTORHOME Adjustment To lengthen belt, swivel the tab end at a right angle to belt and pull strap to desired length. To shorten, pull loose end of belt. To Fasten Be sure belt is not twisted. Grasp each part of the belt assembly and push tongue into buckle.

  • Page 30: Child Restraints

    SECTION 3 - DRIVING YOUR MOTORHOME 2. Make sure that it will attach to your vehicle and restrain your child securely and WARNING conveniently so that you are able to install it correctly each time it is used. 3. Be certain that it is appropriate for the child's Never wear the shoulder belt in any height, weight, and development.

  • Page 31: Keys

    SECTION 3 - DRIVING YOUR MOTORHOME KEYS Your motorhome is supplied with several keys. In addition to the chassis manufacturer’s ignition key, you receive keys for the entrance door and exterior compartment doors. Keys have an identification number, either a small metal tag or stamped into the key head.

  • Page 32: Mirrors - Power Electric

    SECTION 3 - DRIVING YOUR MOTORHOME Mirror Heaters The mirrors may also contain heating elements to de-fog or de-ice the mirror glass during cold weather operation. A switch for the mirror heaters is located on the dash. To turn on, press the switch UP.

  • Page 33: Brake-Shift Interlock

    SECTION 3 - DRIVING YOUR MOTORHOME NOTE: Set screws may be located on the PARK BRAKE – FOOT PEDAL opposite side of the mirror arm. Passenger side mirror is similar. ® Ford Chassis The park brake foot pedal and release lever are Sideview Camera located beneath the left side of the dash.

  • Page 34: Hazard Warning Flashers

    SECTION 3 - DRIVING YOUR MOTORHOME Press and Hold the Battery Boost switch in the ON position while turning ignition key for emergency starting power. NOTE: The House/Coach Battery Disconnect switch near the entrance door must be ON and house batteries must be sufficiently charged for this feature to work.

  • Page 35: Radio In-Dash/Rearview Monitor System

    AV Input upper position in the rare event of an internal Interface motor failure. Cover Should the Automatic Safety Retraction feature deploy, go to your nearest Winnebago Basic Operating Instructions ® Industries dealer for service before operating • (1) VOLUME, MUTE, and POWER - the shade again.
  • Page 36 SECTION 3 - DRIVING YOUR MOTORHOME Bluetooth listening. Press to turn on the unit. Press and hold to turn –If Equipped the unit OFF. Your motorhome may be equipped with a • (2) SOURCE - Press to switch between Bluetooth microphone cable for hands-free cell sources menu and the previous source.

  • Page 37: Air Conditioner/Heater - Automotive (Dash)

    SECTION 3 - DRIVING YOUR MOTORHOME A small amount of air will blow out all of the defrost and the dash vents regardless of the mode setting. Further Information See the manufacturer’s user guide provided in your InfoCase for complete operating instructions.

  • Page 38: Front Service Access

    SECTION 3 - DRIVING YOUR MOTORHOME CB Power Wires To Close Hood (Located behind fuse and breaker panel) -Typical View • Swing hood panel up into closed position. • Press top edge of hood panel in with palms of hands, while locking Hood Locks with the FRONT SERVICE ACCESS provided Hood Lock Key (located on key ring).

  • Page 39: Engine Cooling System

    SECTION 3 - DRIVING YOUR MOTORHOME topped up with the same type of coolant as equipped to maintain the special long- life properties. NOTICE When refilling the coolant system of a Motor Cover Allen Wrench vehicle equipped with a rear auxiliary (Located in the InfoCase) automotive heater and motoraid water heater, be sure to allow for additional...

  • Page 40: Tires

    SECTION 3 - DRIVING YOUR MOTORHOME TIRES LIGHTS Improper tire pressure can result in tire All exterior lights should be checked for overloading and abnormal wear and also affects proper operation each time the vehicle is handling, ride characteristics, and fuel economy. prepared for a trip.
  • Page 41 SECTION 3 - DRIVING YOUR MOTORHOME Further Information Refer to the chassis manual provided in your InfoCase for additional information about chassis-supplied fuses and circuit breakers. 3-15...

  • Page 43: Appliances And Systems

    SECTION 4 - APPLIANCES AND SYSTEMS Leveling The appliances installed in your motorhome are manufactured by reputable RV appliance Before operating the refrigerator when the makers and have been tested by independent motorhome is stationary, place a small level on laboratories to meet all applicable standards and the bottom of the refrigerator and make certain codes set for RV appliances.
  • Page 44 SECTION 4 - APPLIANCES AND SYSTEMS Your motorhome is equipped with one of the • “On” Indicator Light- Glows steady when following refrigerators. See the instructions for refrigerator is operating properly. the refrigerator in your motorhome. • “Gas” Indicator Light- Will flash if gas is not available.

  • Page 45: Refrigerator - Residential

    SECTION 4 - APPLIANCES AND SYSTEMS • Press the TEMP SET button to change temperature setting from 1 to 9 on display. Start at the ‘coldest’ setting to ensure coldest WARNING temperature in the freezer compartment, then adjust warmer as necessary after cold food has At refrigerator/freezer or motorhome End been added.

  • Page 46: Ice Maker

    SECTION 4 - APPLIANCES AND SYSTEMS NOTE: Your ice maker is equipped with an automatic shutoff. As ice cubes fill the storage bin, the wire arm is raised to the OFF (arm up position). Further Information Refer to the manufacturer’s user guide provided in your InfoCase for complete operating instructions, safety precautions, and maintenance information.

  • Page 47: Refrigerator Service Access Compartment - Residential

    SECTION 4 - APPLIANCES AND SYSTEMS RANGE AND OVEN WITH GLASS RANGE COVER • CLOSED –If Equipped NOTE: See the appliance manufacturer’s user guide provided in your InfoCase for complete operating instructions and safety precautions. The Range and optional Oven in your motor home operate on propane gas and will provide •...
  • Page 48 SECTION 4 - APPLIANCES AND SYSTEMS To Light Oven Pilot • Turn the SPARK knob, you will hear the igniter “click”. See “Oven Operation” in the manufacturer’s user guide provided in your InfoCase. NOTE: If the burner does not light within about ten seconds or if the flame should go out Avoiding Asphyxiation during cooking, turn the burner off.

  • Page 49: Microwave Oven

    SECTION 4 - APPLIANCES AND SYSTEMS NOTICE WARNING Do not store items in oven. Portable fuel-burning equipment If oven would turn on stored items can including wood and charcoal grills and ignite resulting in fire and or property stoves, shall not be used inside the damage.

  • Page 50: Washer/Dryer - Stackable

    SECTION 4 - APPLIANCES AND SYSTEMS Further Information Model 33C See the manufacturer’s user guide provided in your InfoCase for instructions on replacement of light bulbs and replacement or cleaning of grease filter elements. WASHER/DRYER – STACKABLE –If Equipped Your motorhome may be equipped with a Stackable Washer/Dryer for the luxury of home as you travel.
  • Page 51 SECTION 4 - APPLIANCES AND SYSTEMS Model 35F CAUTION Open a window or vent while operating dryer. It is dangerous to create a negative air pressure inside a vehicle containing fuel-burning appliances. To Open the Door During a Cycle The door can be unlocked for up to five (5) minutes into any wash cycle and at any time during a dry cycle.

  • Page 52: Washer/Dryer - Prep Package

    We recommend obtaining parts and service for the Washer/Dryer installation from your ® Winnebago Industries dealer. The approximate fluid levels are measured by electronic sensors on the sides of the tanks. There SYSTEMS MONITOR PANEL is generally more fluid in a tank than indicated on the monitor panel.
  • Page 53 SECTION 4 - APPLIANCES AND SYSTEMS Press the Black Waste Level Selector switch switch is on and the system is operable. Water to select the desired black tank level (front or will be available as soon as a faucet is opened. rear) to be displayed on the monitor panel.
  • Page 54 SECTION 4 - APPLIANCES AND SYSTEMS At the touch of a button, this panel will display the fresh water and holding tank levels and the house battery condition. You can start the generator or turn on the water pump and water heater.

  • Page 55: Power Control System (Pcs)

    SECTION 4 - APPLIANCES AND SYSTEMS POWER CONTROL SYSTEM (PCS) –If Equipped The Power Control System (PCS) monitors the electrical usage of the appliances and equipment in the motorhome and allows you to use certain high energy appliances, such as the microwave or washer/dryer, without overloading the shoreline circuit breaker or generator to help prevent nuisance tripping.
  • Page 56 SECTION 4 - APPLIANCES AND SYSTEMS NOTE: Read the Water Heater Operation Manual for complete Safety Warnings, Operating Instructions, and Maintenance Information before operating the water heater. Be sure the water heater is filled with water before starting either electric or propane gas operation.

  • Page 57: Motoraid Water Heater

    SECTION 4 - APPLIANCES AND SYSTEMS MOTORAID WATER HEATER –If Equipped The Motoraid uses heat from the chassis engine cooling system to heat water in the water heater while driving. Hoses are routed from the engine to a heat exchanger surrounding the water heater tank.

  • Page 58: Furnace - Propane Gas

    SECTION 4 - APPLIANCES AND SYSTEMS • Lift handle straight out to open P-T valve when water heater is cold. -Typical View Temp Selector buttons MODE • Press the UP arrow to 4. Let the handle of the P-T valve snap shut. •...

  • Page 59: Heat Pump

    SECTION 4 - APPLIANCES AND SYSTEMS We recommend that you provide when outside temperatures begin to reduce the adequate ventilation when using the efficiency of the Heat Pump. The Heat Pump will furnace for the first time to avoid a not operate when the outside temperature falls nuisance smoke alarm.

  • Page 60: Air Conditioner Filter

    SECTION 4 - APPLIANCES AND SYSTEMS All cooling functions controlling to setpoint have a short cycle protection time delay of three minutes. There will be no delay if the cycle OFF time exceeds three minutes. NOTE: The ducted roof air conditioning system has ceiling registers that can be closed if necessary to force more cool air toward a specific area of the motorhome or to...

  • Page 61: Propane Gas

    SECTION 5 - PROPANE GAS PROPANE GAS SUPPLY Tank Gauge The propane gas system supplies fuel for the Tank Fill Overflow Valve Valve gas range/oven, water heater, furnace, and refrigerator (while in gas mode). When used and handled properly, this system is safe and economical and provides modern living conveniences wherever you travel.

  • Page 62: Propane Accessory Connection

    SECTION 5 - PROPANE GAS to the National Propane Gas Association, propane gas outlets in the United States do not WARNING offer any other type of liquefied petroleum gas than propane to the general public.) Check local phone directory yellow pages for locations of Do not fill propane container(s) to more local propane gas refilling stations or bulk than 80 percent of capacity.

  • Page 63: Safe Use Of The Propane Gas System

    SECTION 5 - PROPANE GAS The Propane Accessory Connection is provided with a shut-off valve that has on/off CAUTION indicator arrows. Rotate the shut-off valve “clockwise” to turn gas supply OFF. Rotate the shut-off valve “counter-clockwise” to turn gas Turn valve off when not in use. supply ON.

  • Page 64: Propane Gas Warnings And Precautions

    SECTION 5 - PROPANE GAS • Have the entire propane gas system inspected for possible leaks and missing or damaged D A N G E R parts at each filling. Also inspect before and after each trip, and any time trouble is suspected.

  • Page 65: Propane Gas Pressure Regulator

    SECTION 5 - PROPANE GAS • Never use an open flame to test for propane gas leaks. Replace all protective covers and caps on propane system after filling. Make sure valve is closed and door latched securely. • Portable fuel-burning equipment, including wood and charcoal grills and stoves, shall not be used inside the recreational vehicle.

  • Page 66: Propane Vaporization In Cold Weather

    SECTION 5 - PROPANE GAS entering the tank can cause problems. To help avoid the possibility of freeze-up, always keep tank control valve closed when not in use, even when tank is empty, to prevent moisture from collecting on the inside. If regulator freeze-up should occur, you may attempt to thaw the regulator using a light bulb.

  • Page 67: Electrical

    SECTION 6 - ELECTRICAL Your motorhome is equipped with an when the auxiliary electric generator is running, electrical system consisting of two separate the power converter automatically changes a voltages: portion of the 120-volt current to 12-volt DC current. All equipment in the motorhome that is •...
  • Page 68 SECTION 6 - ELECTRICAL be used is designed to mate with the prongs of the power cord plug, the electrical connection can be expected to carry rated load. Connecting the Power Cord To connect to an external source, remove the cord from the utility compartment and plug it into a suitable power outlet to provide external power to the motorhome and converter/charger system.

  • Page 69: Inverter Unit - 1000W

    SECTION 6 - ELECTRICAL power fails, contact the park attendants and have them check the fuse or breaker for your supply receptacle. INVERTER UNIT – 1000W The inverter changes 12-volt DC battery power into 120-volt AC power for use by 120- volt AC equipment inside the motorhome.

  • Page 70: Inverter/Charger Unit - 2000W

    SECTION 6 - ELECTRICAL INVERTER/CHARGER UNIT – 2000W NOTICE –If Equipped The 2000-watt inverter/charger has an AC Do not store items around the inverter input circuit breaker to protect the inverter/ unit. The inverter generates heat while charger from overloads. The inverter/charger operating and needs unrestricted airflow also has “built in”...

  • Page 71: Power Center

    SECTION 6 - ELECTRICAL Inverter/Charger Control Panel The inverter/charger has a wall-mounted NOTICE control panel that can be programmed for several charging options. It will also display warnings for Do not store items too closely around the overload conditions or other operating failure inverter unit in the storage compartment.
  • Page 72 SECTION 6 - ELECTRICAL 120-Volt 12-Volt Circuit Breakers House Fuses 120-Volt House 12-Volt House Power Center Circuit Breakers Circuit Breakers (Models 27N and 30T) Power Center -Typical View (Model 36Z) -Typical View Certain circuits, however, remain unchanged for use by items which require 120-volt current, such as the air conditioner(s), the refrigerator in AC mode, the microwave oven, etc.

  • Page 73: Circuit Breakers - House 120-Volt Ac

    SECTION 6 - ELECTRICAL Charging Section component itself. When an overload or short develops, the breaker will open preventing The converter charges house batteries while damage to the system. 120-volt external power is connected. The Shut off the equipment (example: roof air converter will automatically “sense”...

  • Page 74: Electrical Generator - 120-Volt

    SECTION 6 - ELECTRICAL • Push to Reset circuit after monthly testing or ground fault tripping. • Push to Test at least monthly. Should break circuit. Press Generator Power Cord Reset button to Receptacle reconnect. GFCI Outlet (Ground Fault Protector) WARNING WARNING Do not plug the power cord into the...
  • Page 75 SECTION 6 - ELECTRICAL Automatic Generator Start (AGS) –If Equipped The Automatic Generator Start feature monitors house battery voltage and motorhome interior temperature, and has the ability to automatically start the Generator to help maintain full air conditioning function and house battery charge.

  • Page 76: Electrical System - House 12-Volt Dc

    SECTION 6 - ELECTRICAL Operation Warnings and Cautions WARNING The exhaust of all internal combustion engines contains carbon monoxide (CO). This poisonous gas is colorless, odorless, tasteless, and lighter than air. The exhaust systems of both your motorhome • Press and •...

  • Page 77: House/Coach Battery Disconnect Switch

    SECTION 6 - ELECTRICAL Chassis Battery NOTE: Some electronic displays and memory functions may need to be reset after The chassis battery is used to operate the power has been reconnected. engine starter and automotive accessories and controls found on the instrument panel. The See also “Battery Care”...

  • Page 78: Battery Care

    SECTION 6 - ELECTRICAL The two best defenses against sulfating and insufficient charge are to: 1. Turn off the House/Coach Battery Disconnect switch to avoid parasitic discharge (the trickle discharge caused by directly connected components like propane gas detectors or digital clock displays, etc.) 2.

  • Page 79: Circuit Breakers And Fuses - House 12-Volt Dc

    If your motorhome is going to be unoccupied battery, make sure all 12-volt equipment ® for two weeks or more, Winnebago Industries in the motorhome is off and the power recommends disconnecting the chassis batteries cord has been disconnected. Be sure to in your motorhome to avoid battery discharge.
  • Page 80 SECTION 6 - ELECTRICAL House 12-Volt Circuit Breakers (Models 33C, 35F, and 36Z) A label on the panel states the amperage rating and circuit protected for each breaker. The circuit breaker panel is located behind a door or pull-off panel on a lower cabinet face in either the galley/lounge area or beneath the rear Functional Non-Functional...

  • Page 81: Plumbing

    SECTION 7 - PLUMBING Always fill the fresh water tank at an approved FRESH WATER SYSTEM potable water filling facility or a known purified drinking water source. The Fresh Water System provides water to the galley sink, shower, bathroom lavatory, toilet, The tank is filled through the City Water and water heater.
  • Page 82 SECTION 7 - PLUMBING 6. Turn OFF city water supply and disconnect hose from the Fresh Water Inlet. 7. Turn the Fresh Water valve to Normal position to use the water pump. The Tank Fill position is only for pressure filling the water tank from the city water hose connection.

  • Page 83: Water Pump

    SECTION 7 - PLUMBING • Open a faucet on the motorhome (such as the • Insert hose into fill opening and turn water exterior wash station, if equipped) to relieve supply on. Tank is full when water flows from line pressure. the tank vent tube beneath the motorhome and out of the Gravity Fill door.
  • Page 84 SECTION 7 - PLUMBING 4. Open all faucets, hot and cold. 5. Turn ON the Water Pump switch. 6. Close each faucet as it begins to deliver a steady stream of water (close cold water first). Leave hot water faucets on until they also deliver a steady stream of water.

  • Page 85: Full-Coach Water Filtration System

    SECTION 7 - PLUMBING • Fill canister about 1/3 with clean water and FULL-COACH WATER add a couple of tablespoons of household FILTRATION SYSTEM bleach, then scrub with a sponge or brush to disinfect. Rinse thoroughly. –If Equipped • Lubricate the O-ring with clean silicone The full-coach water filtration system is grease to ensure a proper watertight seal, then connected to the cold water lines throughout the...
  • Page 86 SECTION 7 - PLUMBING Disinfecting with City Water Fill tank empty, pour chlorine solution into the tank through the gravity fill port. When disinfecting through the city water fill, Use 1 gallon solution for each 15 gallons of an external cartridge-type water filter assembly tank capacity.

  • Page 87: Shower Hose Vacuum Breaker

    SECTION 7 - PLUMBING water. This method has the additional benefit of disinfecting the city water hose at the same time. Continuous Tank Disinfection (Superchlorination) Some RVers like to ensure continuous sanitation of their fresh water tank by “superchlorination”– maintaining an effective low level of chlorine in the tank at all times.

  • Page 88: Toilet

    SECTION 7 - PLUMBING your pet outside the motorhome. Some models See winterizing instructions at the end of this may have a Water Pump switch located near the section to prepare the toilet for storage in freezing shower faucet for convenience. conditions.
  • Page 89 SECTION 7 - PLUMBING • 1st - Pull Black Waste Tank Drain Sewage Drain Valve to drain Outlet/Dust Cap Black Water (sewage) Tank, then close. • 2nd - Pull Gray Waste Tank Drain Black Waste Gray Waste Tank Valve to drain Gray Tank Drain Valve Drain Valve Water (sink/shower)

  • Page 90: Waste Water System (Waste Pump)

    SECTION 7 - PLUMBING CAUTION WARNING Service inlet access must be closed when Do not use the tank flush valve unless the utility connections are not in use. fullway termination valve is in the open position. May result in an unsanitary When using a sewer hook-up, keep the dump condition leading to illness or personal injury.
  • Page 91 SECTION 7 - PLUMBING Waste Pump 2. Remove dust cap from sewage drain outlet and connect sewage drain hose. Be sure it is The 12-volt Waste Pump disposes black firmly attached. holding tank waste (for the front toilet) through a small diameter sewer hose, which is then drained through the main sewage drain outlet.
  • Page 92 SECTION 7 - PLUMBING Black Waste Tank Drain Valve #2 (Front) Black Waste Tank Drain Valve (Rear) (Located in water service center) (Located in water service center) -Typical View -Typical View NOTE: DO NOT OPEN BOTH VALVES AT 6. Press and Hold the Waste Pump switch ONCE.

  • Page 93: Waterline & Tank Drain Valves

    SECTION 7 - PLUMBING 10. Rinse sewage drain hose thoroughly with WATERLINE & TANK DRAIN water and stow. VALVES NOTE: We recommend that you dump all The waterline and tank drain valves are used holding tanks before traveling to avoid to drain water from the water tank and the water carrying unnecessary weight.

  • Page 94: Water Heater Bypass And Antifreeze Siphon Valves

    SECTION 7 - PLUMBING CAUTION Leave bypass valve handle in NORMAL FLOW position if draining water and blowing out waterlines. Place in BYPASS position ONLY when using antifreeze solution in waterlines. WINTERIZING PROCEDURE You can winterize the water and plumbing Water Tank Drain Valve -Typical installation shown system of your motorhome using one of the...
  • Page 95 Then use a compressed air (Requires socket and ratchet). hose regulated to 30 psi or less to force air through the system. A blow-out plug can be ® purchased at any Winnebago Industries dealer. 7-15...
  • Page 96 SECTION 7 - PLUMBING holding tanks. Although these products may have a deodorizing effect, they may damage plastic and rubber parts in the City Water Connection system. 16. Empty the water pump strainer filter bowl to avoid water freezing and cracking the filter bowl.
  • Page 97 SECTION 7 - PLUMBING antifreeze. See the “Water System Drain Valve Antifreeze Locations” chart at the end of this section for Siphon Tube location on your model. • Insert into Leave the Water Heater Bypass valve handle container of in NORMAL FLOW position if draining water RV water system and blowing out waterlines.
  • Page 98 SECTION 7 - PLUMBING 10. Turn the Winterization valve so it points toward the waterline to the water pump. This will stop the flow from the antifreeze siphon tube and revert the tank line flow to the water pump. 11. Replace the protective cap onto the end of the antifreeze siphon tube to keep out insects and debris when not in use.

  • Page 99: Winterizing Optional Appliances

    SECTION 7 - PLUMBING To Winterize the Waste Pump 4. Ensure water has drained from the Ice Maker supply line, then reconnect to inlet valve. (Model 35F with forward bathroom toilet) 5. Ice Maker is now winterized. • Ensure that black and gray holding tanks are completely empty.
  • Page 100 SECTION 7 - PLUMBING Winterizing Washer/Dryer (Stackable) –If Equipped Method 1 – Drain Water If you have decided to completely drain the motorhome waterlines, follow these steps to winterize your Washer/Dryer: 1. With the Washer/Dryer power OFF, pour 1/2 quart of RV-type antifreeze into the Washer drum.
  • Page 101 SECTION 7 - PLUMBING 2. Press ON/OFF button, set water temperature 5. Unplug Washer/Dryer from electrical outlet to WARM, then press START. Let machine (or disconnect power). fill until the drum turns (this could take up to 6. Turn Water Supply Faucets OFF. Disconnect 1 to 2 minutes).
  • Page 102 SECTION 7 - PLUMBING To use Washer/Dryer again after seasonal storage: 1. Reconnect water inlet hoses to corresponding HOT/COLD faucets. Turn faucets ON. NOTE: Check water inlet hoses and pump periodically (see manufacturer’s user guide for further information). 2. Plug Washer/Dryer into electrical outlet or reconnect power supply.

  • Page 103: Water System Drain Valve Locations

    SECTION 7 - PLUMBING WATER SYSTEM DRAIN VALVE LOCATIONS Model System Drain Valve Locations Model 27N Waterlines • Valve located in rear passenger side compartment behind rear axle. • Open exterior shower faucet and lay shower head on ground. Also, place the tip of your finger inside the city water connection and gently press the backflow valve (small “button”...
  • Page 104 SECTION 7 - PLUMBING Model 33C Waterlines • Inside utility compartment (rear driver side compartment) • Open exterior shower faucet and lay shower head on ground. Also, place the tip of your finger inside the city water connection and gently press the backflow valve (small “button”...
  • Page 105 SECTION 7 - PLUMBING Model 36Z Waterlines • Inside utility compartment (rear driver side compartment). • Open exterior shower faucet and lay shower head on ground. Also, place the tip of your finger inside the city water connection and gently press the backflow valve (small “button”...

  • Page 107: Entertainment

    SECTION 8 - ENTERTAINMENT Exterior Speaker System FRONT TV IGNITION SWITCH INTERLOCK –If Equipped If your motorhome is equipped with a front overhead TV, it is plugged into a special Zones Button electrical outlet with a built-in ignition switch interlock. The device allows the front overhead •...

  • Page 108: Audio/Video System Cables

    SECTION 8 - ENTERTAINMENT TV Sound through Exterior Speakers When watching TV programs alone, the TV normally plays sound through its own built-in stereo speakers. If you wish to connect TV stereo sound output to the Exterior speakers for a richer sound quality, follow these steps: 1.

  • Page 109: Bedroom Dvd/Satellite Receiver Connection

    SECTION 8 - ENTERTAINMENT 3. To lower the TV back into stored position, press the control switch DOWN. The power WARNING lift/lower mechanism will stop automatically when the TV is all the way seated into stored position. Never allow the antenna to touch electrical power lines or any other NOTE: Be sure that the buffet counter is clear electrical wires.

  • Page 110: Tv Signal Amplifier

    SECTION 8 - ENTERTAINMENT 3. Rotate the Attenuator Dial fully CLOCKWISE. WARNING 4. Press Release Button on the Rotational Knob and rotate antenna (until maximum number of Never allow the antenna to touch LED lights illuminate on the Signal Meter). electrical power lines or any other NOTE: LED lights will illuminate from left to electrical wires.

  • Page 111: Tv Digital Satellite System Wiring

    TV before attempting to operate the portable (if equipped). antenna dish. ® See your authorized Winnebago Industries • There must be a clear “line of sight” to the dealer for proper installation and sealing of roof satellite. Mountains, buildings, trees, mounted components.

  • Page 112: Satellite Dish And Cable Tv Connections (Input)

    SECTION 8 - ENTERTAINMENT SATELLITE DISH AND CABLE TV CONNECTIONS (INPUT) –If Equipped The portable satellite dish and cable television input connectors are located in the utility compartment, shoreline compartment, or water service center, depending on model. To receive a cable signal, turn off the TV Signal Amplifier.
  • Page 113 SECTION 8 - ENTERTAINMENT Exterior Entertainment Center -Typical View Further Information Please read the manufacturer’s user guide in your InfoCase for complete operating instructions.

  • Page 115: Furniture And Softgoods

    SECTION 9 - FURNITURE AND SOFTGOODS 1. Pull release lever and slide the table to the SLIDING BUFFET TABLE AND center position until it locks into place. CHAIRS –If Equipped Release Lever (Typical View – Your motorhome may differ in appearance) Buffet Chairs The Buffet Chairs are free-standing to allow greater freedom of movement.

  • Page 116: Buffet Table And Chairs

    SECTION 9 - FURNITURE AND SOFTGOODS Buffet Table Extension 1. Grasp the edge of the buffet table and pull all the way out. 2. Remove table leaf extension from storage location. NOTE: The table extension leaf is stored in the rear wardrobe, in a cabinet near the dinette, or beneath the bed.
  • Page 117 SECTION 9 - FURNITURE AND SOFTGOODS Folding chairs are also provided for additional seating when needed. The folding chairs are located beneath the sofa (Model 30T). Free-standing chairs are not intended for occupancy while the vehicle is in motion and must be stored before driving.

  • Page 118: Sleeping Facilities

    SECTION 9 - FURNITURE AND SOFTGOODS DINETTE/BED CONVERSION – DREAM DINETTE ™ –If Equipped (Typical View – Your motorhome may differ in appearance) 3. Push edge of buffet table in to adjoin with the table extension. Dinette to Bed 1. Remove both dinette back cushions and set aside.

  • Page 119: Sofa/Sleeper

    SECTION 9 - FURNITURE AND SOFTGOODS 3. Release the lock rod on the bottom of the dinette table by pulling down. Lock Rod Reverse steps to convert back into dinette 4. Push table straight down. Lower dinette seat seating. cushions. Once the table is up, engage the lock rod by pushing the lock rod up.

  • Page 120: Extendable Sectional Sofa

    SECTION 9 - FURNITURE AND SOFTGOODS Sofa to Bed 4. Bed is now ready for use. 1. Remove sofa seat back, set aside. 2. Pull sofa seat UP and OUT. 5. Reverse steps to store bed into sofa position. 6. When the bed is back in the sofa position, close the two (2) doors located on each end of the sofa.
  • Page 121 SECTION 9 - FURNITURE AND SOFTGOODS WARNING Stow sectional sofa extension before retracting slide rooms. Failure to observe can cause injury and will cause equipment damage. Extending Sectional Sofa 1. Lift and Hold the black lever (located on the arm of the sectional) to release the sectional extension.

  • Page 122: Power Loft Bed

    SECTION 9 - FURNITURE AND SOFTGOODS Sofa to Bed • Pull strap straight out from the face of the sofa to release the security latch. • With the strap pulled out, lift the front edge of the sofa seat upward. •...
  • Page 123 SECTION 9 - FURNITURE AND SOFTGOODS WARNING Keep people away from operating mechanism and pinch hazard areas during use. Failure to do so could cause injury. • The bed is now ready for use. To access the Loft Bed see “Loft Bed Ladder” later in this section.
  • Page 124 SECTION 9 - FURNITURE AND SOFTGOODS 5. Turn the key (located near the loft bed or monitor panel, depending on model) to the Manual Retraction of Loft Bed “OFF” position. If the Power Loft Bed is malfunctioning you may need to manually retract the loft bed. 1.
  • Page 125 SECTION 9 - FURNITURE AND SOFTGOODS To Use the Loft Bed Ladder 1. Lift ladder horizontally. CAUTION 2. Slide C-shaped retainer ends at the top of ladder onto brackets at rear edge of the Loft To avoid injury, never use the loft bed Bed.

  • Page 126: Roller Shades (Manual) - Solar/Blackout

    CABINETRY –If Equipped People are drawn to the natural beauty of ® wood. At Winnebago Industries , our craftsmen work with the art found in each piece of wood to create cabinets of superior quality, backed by the Loft Bed Winnebago Industries warranty.
  • Page 127 SECTION 9 - FURNITURE AND SOFTGOODS Stains are likely to exaggerate the difference between open and closed grains and other markings in wood. Grain variation and color change should be expected. As hardwood ages, it will darken when exposed to different types of light.

  • Page 129: Slideout Rooms And Leveling

    The ignition key must be placed in the on or run position to operate the slideout room(s). The park brake must be applied for the room(s) to run. Winnebago recommends running the engine whenever you run the slideout rooms in or out, the engine alternator should insure the rooms have adequate 12-volt DC power to operate correctly.
  • Page 130 SECTION 10 - SLIDEOUT ROOMS AND LEVELING To Retract Slideout Room WARNING Before Retracting! • Be sure the motorhome is level and the Parking Brake is set. CRUSH HAZARD. Keep people and • Ensure exterior compartment doors are closed objects clear of the inside and outside of the slideout room when operating.

  • Page 131: Slideout Room - Extreme Weather Precaution

    SECTION 10 - SLIDEOUT ROOMS AND LEVELING • Press the Slideout Room “RETRACT/IN” • The circuit breaker may be tripped. The switch and hold until the room is fully circuit breaker, labeled “Slideout Power” is retracted, then release the switch. located on a panel on an interior wall of the passenger side storage compartment just •...

  • Page 132: General Slideout Care

    SECTION 10 - SLIDEOUT ROOMS AND LEVELING Since only the rear wheels are locked GENERAL SLIDEOUT CARE while in PARK, raising either one or both of the rear wheels off the ground could • Keep slideout room seals clean. allow the vehicle to roll off the jacks. •...

  • Page 133: Checking Hydraulic Oil Level

    SECTION 10 - SLIDEOUT ROOMS AND LEVELING briefly and a chime will sound when the ignition 2. Turn the Leveling System Power switch ON, key is turned to the On or Run positions if the use the arrow “Down” button and select “Auto jacks are down.
  • Page 134 SECTION 10 - SLIDEOUT ROOMS AND LEVELING of debris and contamination of hydraulic oil in the reservoir, which could lead to pump failure or other problems. Breather/Fill Cap Hydraulic Oil Reservoir (Located behind driver side front tire) -Typical View NOTE: Only fill the hydraulic reservoir with the jacks in the retracted (UP) position.

  • Page 135: Maintenance And Storage

    • Have the sealant replaced if you notice any of attention. Delaying these repairs may allow water the above. Your local Winnebago Industries leakage and result in damage to interior ceiling dealer has the correct and necessary parts and and body panels, upholstery, etc., which is not experience to help you maintain your sealants.

  • Page 136: Exterior Automotive Paint Finish

    SECTION 11 - MAINTENANCE AND STORAGE weight to the vehicle. This, in effect, reduces the initial 60-day cure stage, a coat of wax or amount of cargo you can carry and remain within polish can help protect the surface from these GVWR and GAWR limits.
  • Page 137 SECTION 11 - MAINTENANCE AND STORAGE Washing Procedure These types of road conditions may cause surface damage to your motorhome. If • Rinse area to be washed with cold water to possible, it is best to avoid these types of remove surface residue.

  • Page 138: Exterior Graphic Care

    SECTION 11 - MAINTENANCE AND STORAGE Polishing and/or Waxing be repaired or covered as quickly as possible to avoid penetration by moisture, especially in NOTE: When your motorhome is new or has freezing climates. been repainted for any reason, no polish If the fiberglass has been damaged and or wax should be applied to the finish contains cracks, tears, or holes, use plastic...

  • Page 139: Plastic Parts - Cleaning

    Use the following cautionary lists as a guide when selecting EXTERIOR LIGHTS cleaning products to use on plastic parts. ® Most Winnebago Industries vehicles have polycarbonate lenses on exterior lamps, which are very sensitive to a variety of chemical NOTICE solvents and cleaners.

  • Page 140: Cabinetry - Cleaning

    SECTION 11 - MAINTENANCE AND STORAGE Draperies, Curtains, and cleaning products. Some water-based household cleaning products are not formulated for use on Bedspreads fabrics and may cause excessive shrinkage or These items may be woven from a variety of fading. Always test any cleaning product on a fabrics.

  • Page 141: Solid Surface Countertop - Corian

    SECTION 11 - MAINTENANCE AND STORAGE surface material is extremely heat resistant, but SOLID SURFACE sudden contact by a very hot material with a cold ® COUNTERTOP – CORIAN countertop surface could cause a crack that would need to be repaired. Likewise, Care and Maintenance concentrated high heat sources in a small area, You can easily maintain the beauty of your...

  • Page 142: Sink - Stainless Steel

    SECTION 11 - MAINTENANCE AND STORAGE the stain. Rinse thoroughly with a sodium SINK – STAINLESS STEEL bicarbonate and water solution, then follow up by rinsing with water. Clean carefully. Care and Cleaning Instructions Oil and Grease Stains The stainless steel sink can usually be cleaned To remove oil and grease stains, use a mild with water and soap or detergent using a soft dishwashing liquid and hot water.

  • Page 143: Bathroom

    SECTION 11 - MAINTENANCE AND STORAGE Treatment of Stains • Sweep or vacuum floor daily (use a vacuum without a beater bar head.) Remove loose dirt Acids, alkali, alcoholic beverages, coffee, soft ® with a soft brush or Swiffer type product. drinks, ketchup, fruit, fruit juices, food, •...

  • Page 144: Doors And Windows

    SECTION 11 - MAINTENANCE AND STORAGE Tub and Shower Walls VEHICLE STORAGE – The tub and shower walls in the bathroom PREPARATION should be cleaned with mild soap and warm water. Do not use an abrasive cleaner on the Properly preparing your vehicle for storage shower walls and tub, as scratching and will lessen the possibility of damage to your discoloration may occur.

  • Page 145: Vehicle Storage - Removal

    SECTION 11 - MAINTENANCE AND STORAGE 8. Wash and wax the motorhome. (if equipped). See appropriate filter installation instructions in Section 7 - 9. Inspect all seams and seals around doors, Plumbing. windows, vents, and any other joints. Replace or repair any that are damaged. Sealing NOTE: Always purge a new filter with clean materials and compounds can be purchased running water before using.

  • Page 146: Chassis Service And Maintenance

    SECTION 11 - MAINTENANCE AND STORAGE NOTE: Before turning the water supply on, assure that the water faucet filter is in place and that the water shut-off valve (typically located inside galley cabinet beneath sink) is OPEN. 3. Be sure the ice bin is in place and the automatic shutoff arm is down.

  • Page 147: Motorhome Maintenance Chart

    SECTION 11 - MAINTENANCE AND STORAGE MOTORHOME MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Propane Gas System ...
  • Page 148 SECTION 11 - MAINTENANCE AND STORAGE MOTORHOME MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Safety Equipment Check operation of the following items: ...
  • Page 149 SECTION 11 - MAINTENANCE AND STORAGE MOTORHOME MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Sealants ...

  • Page 151: Miscellaneous

    SECTION 12 - MISCELLANEOUS NOTE: We recommend that you dump all LOADING THE VEHICLE holding tanks before traveling to avoid carrying unnecessary weight. NOTE: Your motorhome’s load capacity is designated by weight, not by volume, so you cannot necessarily use all available WARNING space when loading your motorhome.
  • Page 152 SECTION 12 - MISCELLANEOUS Corner Weighing (Side-to-Side) You will first drive only your front wheels onto the scale pad, then drive ahead so that the The most accurate method of weighing a whole vehicle is on the scale, then finally pull off motorhome is to weigh each “corner”...

  • Page 153: Car Or Trailer Towing

    SECTION 12 - MISCELLANEOUS axle is 12,000 lbs., then the load on each rear dual listed Gross Weight Ratings. See “Vehicle set (left rear duals or right rear duals) should not Certification Label” in the Introduction section exceed 6,000 lbs. for information on gross weight ratings.

  • Page 154: Trailer Wiring Connector

    SECTION 12 - MISCELLANEOUS located outside our recommended limits) places The following diagram shows proper excessive stress on the hitch. This abuse of the connection of trailer or tow vehicle wiring to the ball mount and the hitch may cause premature motorhome light system.

  • Page 155: Fireplace

    SUV or pickup. (Hitch ratings are independent of towing vehicle ratings.) ® NOTE: Some Winnebago Industries models equipped with a Class 3 hitch may have a label limiting vertical tongue load to 350 lbs. Some Winnebago Industries models 12-5...

  • Page 156: Windows

    SECTION 12 - MISCELLANEOUS Stationary Extended Mode - Step Switch OFF (Step Remains Extended) With the Step power switch in the OFF position, the step will extend when the screen door is opened and will stay extended whether the door is opened or closed. NOTE: The step switch is “locked”...

  • Page 157: Power Roof Ventilator

    SECTION 12 - MISCELLANEOUS Vertical Slider Windows –If Equipped Vertical windows have spring-loaded catches on both sides of the window that pop out to hold the window in its fully raised position. Press both catches inward while opening and closing the window.

  • Page 158: Awning - Power

    SECTION 12 - MISCELLANEOUS POWER ROOF VENTILATOR Manual Dome Crank Knob –If Equipped • Slide to OPEN before turning on fan Fan ON and Speed Selection Power Roof Ventilator Power Roof Ventilator NOTE: For best results, close all other roof vents, windows, and doors, then open To Operate Ceiling Ventilator one (1) window the farthest distance...

  • Page 159: Storage Compartment Doors

    SECTION 12 - MISCELLANEOUS STORAGE COMPARTMENT DOORS The high-density gaskets used on the exterior storage compartments are designed to provide a more positive seal against dust and weather. To ensure that exterior storage compartment doors have latched properly, press firmly on the bottom or side edges of the doors with the palms of your hands.

  • Page 160: Effects Of Prolonged Occupancy

    SECTION 12 - MISCELLANEOUS Humidity and Condensation • Keep the rungs of the ladder clean and dry while in use. Never use the ladder when it is Moisture condensing on the inside of raining, snowing, or icy. The rungs can windows is a visible indication that there is too become slippery.
  • Page 161 INDEX About this Manual ..........................1-1 Air Conditioner Filter ........................... 4-18 Air Conditioner/Heater – Automotive (Dash) ..................3-11 Audio/Video System Basic Operation ....................8-1 Audio/Video System Cables ........................8-2 Awning – Power ........................... 12-8 Bathroom .............................. 11-9 Battery Access ............................6-11 Battery Boost Switch ..........................
  • Page 162 Index Electrical Generator – 120-Volt ......................6-8 Electrical Outlets – House 120-Volt AC ....................6-7 Electrical System – House 120-Volt AC ....................6-1 Electrical System – House 12-Volt DC ....................6-10 Emergency Exits ............................. 2-7 Engine Access – Interior ........................3-12 Engine Cooling System ........................
  • Page 163 Index Loading the Vehicle ..........................12-1 Maintenance ............................2-7 Map Light Switch ........................... 3-7 Microwave Oven ............................. 4-7 Microwave Oven/Range Hood ....................... 4-7 Microwave/Convection Oven ......................... 4-7 Mirrors – Power Electric ......................... 3-6 Mold, Moisture, and Your Motorhome ....................2-10 MotorAid Water Heater ........................
  • Page 164 Index Roof ..............................11-1 Roof and Ladders ............................ 2-9 Roof Ladder ............................12-9 Safe Use of the Propane Gas System ...................... 5-3 Safety Messages Used in this Manual ....................1-1 Satellite Dish and Cable TV Connections (Input) .................. 8-6 Sealants – Inspection and General Information ..................11-1 Seat Belts ..............................
  • Page 165 Index Undercarriage ............................11-1 Vehicle Certification Label ........................1-4 Vehicle Storage – Preparation ......................11-10 Vehicle Storage – Removal ........................ 11-11 Vinyl Flooring ............................11-8 Washer/Dryer – Prep Package ......................4-10 Washer/Dryer – Stackable ........................4-8 Washer/Dryer (Combination) ......................... 4-8 Waste Water System ..........................

This manual is also suitable for:

Adventurer 35fAdventurer 30tAdventurer 36zAdventurer 33c

Table of Contents
