About this Manual ............................................................................................................................ 1-1
Safety Messages Used in this Manual .............................................................................................. 1-1
Pre-Delivery Inspection .................................................................................................................... 1-2
Front Axle Tire Alignment ............................................................................................................... 1-2
Service and Assistance ...................................................................................................................... 1-2
Reporting Safety Defects .................................................................................................................. 1-2
Occupant and Cargo Carrying Capacity Label ................................................................................. 1-3
Vehicle Certification Label ............................................................................................................... 1-4
Specifications and Capacities ........................................................................................................... 1-5
Owner and Vehicle Information ....................................................................................................... 1-6
General Warnings ............................................................................................................................. 2-1
Driving Safety ................................................................................................................................... 2-1
Fuel and Propane Gas ....................................................................................................................... 2-1
Propane Gas Leaks ............................................................................................................................ 2-2
Propane Gas Leak Detector .............................................................................................................. 2-3
Carbon Monoxide Warning .............................................................................................................. 2-3
Carbon Monoxide Alarm .................................................................................................................. 2-3
Smoke Alarm .................................................................................................................................... 2-4
Fire Extinguisher ............................................................................................................................... 2-5
Electrical ........................................................................................................................................... 2-5
Loading ............................................................................................................................................. 2-5
Maintenance ...................................................................................................................................... 2-6
Emergency Exits ............................................................................................................................... 2-6
Power Sofas and Beds ....................................................................................................................... 2-6
Slideout Rooms ................................................................................................................................. 2-7
Formaldehyde Information ............................................................................................................... 2-7
Mold, Moisture, and Your Motor Home ........................................................................................... 2-7
Roof and Ladders .............................................................................................................................. 2-8
Roadside Emergency ........................................................................................................................ 2-9
Jump Starting .................................................................................................................................. 2-10
Engine Overheat ............................................................................................................................. 2-10
Seats - Driver/Co-Pilot ..................................................................................................................... 3-1
Fold-Down Dinette Seat ................................................................................................................... 3-1
Seat Belts .......................................................................................................................................... 3-1
Child Restraints ................................................................................................................................. 3-2
Keys .................................................................................................................................................. 3-3
Rev. 1308130220

TABLE OF CONTENTS

Copyright 2013 Winnebago Industries, Inc. All rights reserved.
Part No. 161500-13-002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Access and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Winnebago Access

Summary of Contents for Winnebago Access

  • Page 1: Table Of Contents

    3 – DRIVING YOUR MOTOR HOME Seats – Driver/Co-Pilot ........................3-1 Fold-Down Dinette Seat ........................3-1 Seat Belts ............................3-1 Child Restraints ..........................3-2 Keys ..............................3-3 Rev. 1308130220 Part No. 161500-13-002 Copyright 2013 Winnebago Industries, Inc. All rights reserved.
  • Page 2 Battery Boost Switch ........................3-5 Air Conditioner/Heater – Automotive (Dash) .................. 3-5 Radio In-Dash/Rearview Monitor System ..................3-6 Radio – In-Dash ..........................3-7 Engine Access – Interior ........................3-8 Engine Cooling System ........................3-8 Tires ..............................3-8 Suspension Alignment and Tire Balance ..................3-8 Air Springs –...
  • Page 3 Table Of Contents House/Coach Battery Disconnect Switch ..................6-6 Battery Access ..........................6-6 Battery Care ............................6-7 Circuit Breakers and Fuses – House 12-Volt DC ................6-8 7 – PLUMBING Fresh Water System .......................... 7-1 Water Pump ............................7-2 Disinfecting Your Fresh Water System .................... 7-3 Shower Hose Vacuum Breaker ......................
  • Page 4 Comfort Sofa Sleeper ........................9-6 Roller Shades (Manual) - Solar Day/Night ..................9-9 Wood Furniture and Cabinetry ....................... 9-10 10 – SLIDEOUT ROOMS Slideout Room Keylock ........................10-1 Slideout Room Operation – Electric ....................10-1 Slideout Room – Extreme Weather Precaution ................10-3 Slideout Room Troubleshooting (Lippert) ..................
  • Page 5 Windows ............................12-7 Power Roof Ventilator ........................12-7 Effects of Prolonged Occupancy ....................12-8...

  • Page 7: Introduction

    The instructions included in this manual are intended as a guide, and in no way DANGER indicates a hazardous situation extend the responsibilities of Winnebago which, if not avoided, will result in death or Industries beyond the standard written serious personal injury.

  • Page 8: Pre-Delivery Inspection

    National Highway Traffic Safety Administration delivery inspection of the chassis and all (NHTSA) in addition to notifying Winnebago motorhome components. Industries, Inc. As a part of the pre-delivery inspection...

  • Page 9: Occupant And Cargo Carrying Capacity Label

    SECTION 1 – INTRODUCTION or go to their website at http://www.safercar.gov or write to: Administrator, NHTSA 1200 New Jersey Avenue S.E. Washington, D.C. 20590 You can also obtain other information about motor vehicle safety from the NHTSA website at http://www.safercar.gov OCCUPANT AND CARGO CARRYING CAPACITY LABEL This label is affixed in the driver’s area next to...

  • Page 10: Vehicle Certification Label

    These pressure levels must be maintained to assure proper handling, safety, 2. Chassis manufacture date. and fuel economy. 3. Month and year of manufacture at Winnebago ® 9. Rear Axle Wheel Configuration: Single or Industries Dual as it relates to the inflation.

  • Page 11: Specifications And Capacities

    Floorplans feature a wide-body design - over 96". You should be aware that some states restrict access on some or all state roads to 96" in body width. You should confirm the road usage laws in the states of interest to you.

  • Page 12: Owner And Vehicle Information

    Motorhome Serial Number ___________________________________________________________ Chassis Vehicle Identification No. (VIN) ________________________________________________ Vehicle Mileage at Delivery __________________________________________________________ Selling Dealer Name ________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ ® YOUR WINNEBAGO INDUSTRIES DEALER /SERVICE CENTER Name ____________________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ Contact ____________________________________________Phone ________________________ CHASSIS SERVICE CENTER...

  • Page 13: Safety And Precautions

    SECTION 2 – SAFETY AND PRECAUTIONS • Use care when accelerating or decelerating on GENERAL WARNINGS a slippery surface. Abrupt speed changes can cause skidding and loss of control. • Only seats equipped with seat belts are to be occupied while the vehicle is moving. •...

  • Page 14: Propane Gas Leaks

    SECTION 2 – SAFETY AND PRECAUTIONS WARNING Propane gas containers, gasoline, or other flammable liquids shall not be placed or stored onboard the vehicle because a fire or explosion may result. Propane gas containers are equipped with safety valves, which relieve Unlike homes, the amount of oxygen supply is excessive pressure by discharging gas limited due to the size of the recreational vehicle,...

  • Page 15: Propane Gas Leak Detector

    SECTION 2 – SAFETY AND PRECAUTIONS battery during storage periods when the house PROPANE GAS LEAK battery will not be charged regularly by the DETECTOR engine or shoreline. Your coach is equipped with a Propane Gas Further Information Leak Detector, similar to the one shown below. See the manufacturer’s user guide provided in The leak detector sounds an alarm if an unsafe your InfoCase for further instructions.

  • Page 16: Smoke Alarm

    RV application. We that is also listed for RV application. We recommend obtaining a replacement from your recommend obtaining a replacement from your ® Winnebago Industries dealer. ® Winnebago Industries dealer. Further Information...

  • Page 17: Fire Extinguisher

    Extinguisher, the replacement must be the same type and size as the one originally supplied in your coach. We recommend obtaining a replacement only from your Winnebago ® Industries dealer or a reliable RV parts supplier.

  • Page 18: Maintenance

    SECTION 2 – SAFETY AND PRECAUTIONS Using Slider Windows As An MAINTENANCE Emergency Exit • Do not remove the radiator cap while engine Some coaches are required to have a slider and radiator are still hot. Always check window was an alternate exit. This window will coolant level visually at the see-through be marked EXIT and have a red-handled latch.

  • Page 19: Slideout Rooms

    SECTION 2 – SAFETY AND PRECAUTIONS ventilation may allow formaldehyde and other SLIDEOUT ROOMS contaminants to accumulate in indoor air. Ventilation to dilute the indoor air may be obtained from a passive or mechanical ventilation system. Always be sure to thoroughly WARNING ventilate your recreational vehicle before and during each use.

  • Page 20: Roof And Ladders

    SECTION 2 – SAFETY AND PRECAUTIONS thoroughly and quickly. Avoid grease buildup warranty period, Winnebago Industries will not near the stove or sink. Clean the exhaust fan provide any financial assistance to the repair of above the stove often. the condition.

  • Page 21: Roadside Emergency

    SECTION 2 – SAFETY AND PRECAUTIONS • Maximum Capacity: 225 lbs. • If you must change lanes to get to a safe stopping place, use your signals to warn other • Do not overload. Ladder is intended for one motorists and change lanes smoothly and person.

  • Page 22: Recovery Towing

    Vehicle Certification Label. This will allow the towing operator to determine the proper towing equipment to use. ® Winnebago Industries does not assume ENGINE OVERHEAT responsibility for damage incurred while towing this vehicle.

  • Page 23: Driving Your Motor Home

    SECTION 3 – DRIVING YOUR MOTOR HOME The information in this section refers only to features installed or adapted to the dash and driver compartment area by Winnebago ® Industries . It also includes passenger seating in the living area of the coach.

  • Page 24: Child Restraints

    SECTION 3 – DRIVING YOUR MOTOR HOME Lap/Shoulder Belts one person use the same safety belt at any one time, and do not let the safety belts become See your chassis manual for instructions on damaged by pinching them in the doors or in the proper fastening, adjustment, and releasing of seat mechanism.

  • Page 25: Keys

    SECTION 3 – DRIVING YOUR MOTOR HOME Further Information 3. Be certain that it is appropriate for the child's height, weight, and development. The See the child seat manufacturer’s specific instructions and/or the regulation label instructions for proper attachment and attached to the restraint typically provides this adjustment of the tether and seat belts.
  • Page 26 SECTION 3 – DRIVING YOUR MOTOR HOME Mirror Heat Switch Mirror Adjustment Control Mirror Pivot Lock • Mirror surface tilts in direction of arrow button • Unscrew protective cap and loosen Allen head pressed. set screw to pivot mirror head. •...

  • Page 27: Battery Boost Switch

    SECTION 3 – DRIVING YOUR MOTOR HOME The ignition switch must be on to operate BATTERY BOOST SWITCH mirror controls and heaters. The Battery Boost switch can be used to draw emergency starting power from the house Mirror Heat batteries to start the engine if the chassis battery Switch is discharged.

  • Page 28: Radio In-Dash/Rearview Monitor System

    MENU - Press to access USER SETTING MENU. Press and Hold to access SYSTEM SETUP MENU. • AUDIO - Press and Hold to access AUDIO MENU. Press to return to current playback mode. • CAM - Press to access CAMERA mode.

  • Page 29: Radio - In-Dash

    SECTION 3 – DRIVING YOUR MOTOR HOME Please refer to the manufacturer’s operating guide in your InfoCase for detailed instructions on programming preset station buttons and using this full-featured radio/audio system. Satellite Radio –If Equipped ® Your coach may be equipped with a Sirius satellite radio receiver that plays through your radio.

  • Page 30: Engine Access - Interior

    SECTION 3 – DRIVING YOUR MOTOR HOME Further Information ENGINE ACCESS – INTERIOR Refer to the chassis manual in your InfoCase Front Engine Cover for information and precautions on filling, servicing, and checking the fluid level. NOTE: Take precautions to protect carpet and...

  • Page 31: Air Springs - Rear Helper

    SECTION 3 – DRIVING YOUR MOTOR HOME Out-of-balance tires will not roll smoothly and Air Spring can lead to vibrations and uneven tread wear, such as cupping and flat spots. Tires may need to be balanced if uneven wear is detected or if ride comfort decreases noticeably.

  • Page 33: Appliances And Systems

    SECTION 4 – APPLIANCES AND SYSTEMS The appliances installed in your motorhome are manufactured by reputable RV appliance makers and have been tested by independent laboratories to meet all applicable standards and codes set for RV appliances. See Section 2 - Safety and Precautions of this manual for any safety and precautions you need to take regarding the operation of your appliances.

  • Page 34: Refrigerator Service Access Compartment

    InfoCase. provide most of the functions of the range in your home. REFRIGERATOR SERVICE ACCESS COMPARTMENT (Exterior) The exterior refrigerator service compartment allows access to the rear of the refrigerator for inspection, maintenance, and service.

  • Page 35: Avoiding Asphyxiation

    SECTION 4 – APPLIANCES AND SYSTEMS WARNING IT IS NOT SAFE TO USE COOKING APPLIANCES FOR COMFORT HEATING Cooking appliances need fresh air for safe operation. Before operation: 1. Open overhead vent or turn on exhaust fan. 2. Open window. FAILURE TO COMPLY COULD RESULT IN To Light Range Top Burners DEATH OR SERIOUS INJURY...

  • Page 36: Microwave Oven

    SECTION 4 – APPLIANCES AND SYSTEMS pump and water heater. Indicator lights tell you if MICROWAVE OVEN the water pump is on or if the water heater pilot light is out. -If Equipped Refer to the manufacturer’s user guide located Water And Holding Tank Levels inside the appliance for complete operating Press and Hold the Levels Test switch to show...

  • Page 37: Water Heater - Gas/ Electric

    SECTION 4 – APPLIANCES AND SYSTEMS Tank Capacities See “Tank Capacities” in Section 1 - Introduction. Propane Gas Level Press and Hold the Levels Test switch to show approximate propane tank level. The propane level is registered by a sending unit on the tank.
  • Page 38 SECTION 4 – APPLIANCES AND SYSTEMS Further Information Read the operating and safety information provided in the Water Heater Operation Manual in your InfoCase. WATER HEATER - GAS/ ELECTRIC -If Equipped (with Motoraid water heating system) The gas/electric water heater has a dual power Gas Water Heater Switch feature.

  • Page 39: Pressure-Temperature Relief Valve

    Turn on the Water Heater electric element switch. The shoreline must be connected or generator running for electric operation. Water Heater Exterior Service Access Normally there is an air gap at the top of the water heater tank, which acts as a pressure buffer.

  • Page 40: Propane Gas Furnace

    SECTION 4 – APPLIANCES AND SYSTEMS 2. Open a faucet in the motorhome to relieve water pressure. 3. Pull the handle of the P-T valve straight out and allow water to flow until it stops. Thermostat/Switch Room Temperature •Move from OFF to Thermometer desired temperature •Lift handle straight out to open P-T valve...

  • Page 41: Propane Gas Furnace

    SECTION 4 – APPLIANCES AND SYSTEMS To Shut Down NOTE: If heat does not come out of the heat ducts after a minute or so the burner is • Move Thermostat switch to OFF position. not lit. • Close Propane Gas Tank valve if coach will be Turn thermostat off for 3-5 minutes, stored for a period of time.

  • Page 42: Air Conditioner Filter

    SECTION 4 – APPLIANCES AND SYSTEMS NOTE: The ducted roof air conditioning system has ceiling registers that can be closed if necessary to force more cool air toward a specific area of the coach or to route cool air away from a specific area. If too many vents are closed, however, it can cause the air conditioner unit to shut down, particularly in high humidity...

  • Page 43: Propane Gas

    SECTION 5 – PROPANE GAS PROPANE GAS SUPPLY The propane gas system supplies fuel for the gas range/oven, water heater, furnace, and refrigerator (while in gas mode). When used and handled properly, this system is safe and economical and provides modern living conveniences wherever you travel.

  • Page 44: Safe Use Of The Propane Gas System

    SECTION 5 – PROPANE GAS phone directory yellow pages for locations of local propane gas refilling stations or bulk dealerships. DAN G E R NOTE: If you travel outside the U.S. with your motorhome, you may find butane or DO NOT FILL CONTAINER TO MORE propane/butane mixtures available in THAN 80 PERCENT OF CAPACITY.

  • Page 45: Propane Gas Warnings And Precautions

    SECTION 5 – PROPANE GAS • Exercise caution at all times. Be familiar with PROPANE GAS WARNINGS the distinctive odor of propane gas. If a leak is AND PRECAUTIONS suspected, turn off the supply valve immediately. Have the propane gas system It is illegal for vehicles equipped with propane checked by your dealer or other qualified tanks to travel on certain roadways or through...

  • Page 46: Propane Gas Pressure Regulator

    SECTION 5 – PROPANE GAS WARNING WARNING Propane cylinders shall not be placed or Visually inspect the pressure regulator stored inside the vehicle. Propane vent periodically for blockage by cylinders are equipped with safety accumulated debris or insect nests, etc. devices that relieve pressure by Vent obstruction could result in excessive discharging propane to the atmosphere.

  • Page 47: Propane Vaporization In Cold Weather

    SECTION 5 – PROPANE GAS This means that in extremely cold weather when a large volume of gas is being used by the furnace for heating, it is possible to experience a loss of gas pressure. At first, this problem may appear to be caused by an empty tank or a regulator freeze-up, but is actually caused by failure of the liquid gas to vaporize as fast as it is needed by the furnace.

  • Page 49: Electrical

    SECTION 6 – ELECTRICAL Your coach is equipped with an electrical the power converter automatically changes a system consisting of two separate voltages: portion of the 120-volt current to 12-volt DC current. All equipment in the motorhome that is • 12-volt DC system (battery current);...

  • Page 50: Power Center

    (Models with power cord compartment on NOTE: Always keep compartment door and sidewall) access passage closed while shoreline –If Equipped cord is not in use. A flip-up passage in the power cord door lets...

  • Page 51: Circuit Breakers - House 120-Volt Ac

    SECTION 6 – ELECTRICAL condition of the battery. If it is below “full 12-Volt 120-Volt charge”, the Charging Section will start charging House Fuses Circuit Breakers the batteries. If the house batteries have been extremely discharged, they will accept charge at a relatively high amperage rate.

  • Page 52: Electrical Outlets - House 120-Volt Ac

    SECTION 6 – ELECTRICAL “Off” and back to “On”. If the breaker is If the GFCI keeps tripping, have the electrical continually tripped and no overload is evident, system checked and repaired, if necessary, before have the system checked for a short in the wiring using again.

  • Page 53: Operation Warnings And Cautions

    SECTION 6 – ELECTRICAL To use the 120-volt generator, plug the power Refer to the hourmeter to determine when cord into the generator receptacle within the periodic maintenance is due and to record utility compartment before starting the generator. services which have been performed. Operation Warnings and Cautions WARNING The exhaust of all internal combustion...

  • Page 54: House/Coach Battery Disconnect Switch

    This includes the following 12-volt powered components (if equipped): interior 12- volt lighting, range exhaust fan, propane furnace BATTERY ACCESS fan, fresh water pump, systems monitor panel, The house batteries are located in a front refrigerator, roof vent fans, and 120-volt driver or passenger side compartment, depending electrical generator starter.

  • Page 55: Battery Care

    SECTION 6 – ELECTRICAL The two best defenses against sulfating 3. Extend battery tray. and insufficient charge are to: 1. Turn off the House/Coach Battery Disconnect switch to avoid parasitic discharge (the trickle discharge caused by directly connected components like propane gas detectors or digital clock displays, etc.) 2.

  • Page 56: Circuit Breakers And Fuses - House 12-Volt Dc

    If your coach is going to be unoccupied for year. ® two weeks or more, Winnebago Industries • Check the battery fluid level every month, or recommends disconnecting the chassis battery in more often in hot weather.
  • Page 57 SECTION 6 – ELECTRICAL Automotive Chassis and House 12-Volt Circuit Breakers (Located inside passenger compartment) -Typical View House 12-Volt Fuses (Located on the right-hand side of the power converter) -Typical View The fuse panel accepts only blade type plug-in fuses. Always replace fuses with those of the same amperage rating.

  • Page 59: Plumbing

    SECTION 7 – PLUMBING FRESH WATER SYSTEM The fresh water system provides water to the galley sink, shower, bathroom lavatory, toilet and water heater. Water may be supplied by either of two sources: • a fresh water tank and water pump located within the motorhome, or Water Tank Gravity Fill •...

  • Page 60: Water Pump

    SECTION 7 – PLUMBING NOTE: Always keep the tank fill valve in Normal position unless you are filling the tank. If this valve is left in the Tank Fill position while using the city water, water will keep flowing into the tank and out the tank vent tube onto the ground and the water pump will run without delivering water to faucets.

  • Page 61: Disinfecting Your Fresh Water System

    4. Let the system stand at least 4 hours when (Located beneath bed - disinfecting with 50 ppm residual chlorine. (If lift mattress to expose access hole) a shorter time period is desired, then a 100 -Typical View ppm chlorine concentration should be allowed to stand in the system for at least 1 hour.)

  • Page 62: Shower Hose Vacuum Breaker

    SECTION 7 – PLUMBING open for some time to flush the water heater EXTERIOR SHOWER/WASH with clean water. You may also want to turn STATION the water heater off until this is done to avoid wasting energy trying to heat “unused” –If Equipped water).

  • Page 63: Dumping Holding Tanks

    See the toilet manufacturer’s operation Holding Tank Dump Valves (Located in mid-driver side information in your InfoCase for complete access compartment) operating, care and maintenance information. -Typical View See winterizing instructions at the end of this section to prepare the toilet for storage in freezing 1.

  • Page 64: Waste Water System - Waste Pump (Model 26Q)

    NOTE: Always keep service access passage closed while utility connection is not in use. 1st - Pull Black...
  • Page 65 SECTION 7 – PLUMBING water holding tank contains the waste water from 2. Remove dust cap from sewage drain outlet the galley sink, shower, and may include and connect sewage drain hose. Be sure it is bathroom lavatory. firmly attached. See “Specifications”...
  • Page 66 SECTION 7 – PLUMBING sewage back-up into gray tank. Gray water also rinses any black water solids from the sewage drain hose. 5. Open the Gray Waste Tank Drain valve (located beneath driver side of coach ahead of rear wheel) and press and hold the Waste Pump switch (located near the exterior shower.) Release the Waste Pump switch and close the Gray Waste Tank Drain valve as...

  • Page 67: Holding Tank Heater

    SECTION 7 – PLUMBING Holding Tank Level Indicators batteries would not support overnight heating without a supplemental charging See “Systems Monitor Panel” in Section 4– source. Appliances for further information on the monitor panel and checking tank levels. WATERLINE & TANK DRAIN See “Specifications”...

  • Page 68: Water Heater Bypass And Antifreeze Siphon Valves

    SECTION 7 – PLUMBING Normal By-Pass Flow Mode CAUTION Water Tank Drain Valve (Typical) Leave bypass valve handle in NORMAL FLOW position if draining water and blowing out waterlines. Place in BYPASS position ONLY when using antifreeze solution in waterlines. WINTERIZING PROCEDURE You can winterize the water and plumbing system of your coach using one of the following...
  • Page 69 Leave open after water stops flowing. the system. A “blow-out” plug can be 5. Drain Toilet. Press the toilet flush pedal and ® ® purchased at any Winnebago or Itasca hold until water stops flowing in the toilet. dealer. Then turn water pump switch off.
  • Page 70 SECTION 7 – PLUMBING 8. Let air flow for five minutes until water is and prevent entry and contamination by completely drained out of faucets and drain airborne debris, insects, and rodents. valves. Then close faucets one at a time. 9.
  • Page 71 SECTION 7 – PLUMBING NOTE: Ensure that all drain valves are CLOSED before pumping RV antifreeze WARNING into the water system. Refer to the “Water System Drain Valve Locations” chart at the end of this NEVER use automotive antifreeze/ section for valve locations on your coolant in your RV water system.
  • Page 72 SECTION 7 – PLUMBING and prevent entry and contamination by airborne debris, insects, and rodents. Your drainage and fresh water systems are now winterized. See instructions for removal from storage in Section 11 - Maintenance and Storage. To Winterize the Waste Pump Water Heater Drain Plug -If Equipped (Remove with socket)

  • Page 73: Water System Drain Valve Locations

    Drain plug on outside of coach behind service door. Use socket to remove drain plug. Water Heater • Beneath galley sink. Open doors and remove panel to Bypass Valve access. Winterization • Beneath the bed. Lift mattress to expose access hole. (Antifreeze) Valve 7-15...
  • Page 74 Water Heater • Beneath galley sink. Remove panel to access. Bypass Valve Winterization • Beneath the bed. Lift mattress to expose access hole. (Antifreeze) Valve Waterlines • Two (2) valves beneath the bed. Lift mattress to expose access hole. Also, place the tip of your finger inside the city water connection and gently press the backflow valve (small “button”...
  • Page 75 “button” in center of connector) to drain any water left in the city waterline. Water Tank • One (1) valve beneath the bed. Lift mattress to access. Water Heater • Drain plug on outside of coach behind service door. Use socket to remove drain plug.

  • Page 77: Entertainment

    SECTION 8 – ENTERTAINMENT VIDEO SELECTION SYSTEM –If Equipped The Video Selection System allows you to • The Video Selection System allows you to switch the antenna, AUX/VCR, cable TV, watch DVD’s from either the lounge area satellite TV, or DVD signal to any TV set (main TV), bedroom, or the exterior location in the coach.

  • Page 78: Tv - (Swing-Out)

    SECTION 8 – ENTERTAINMENT Further Information TV – (SWING-OUT) See the television manufacturer’s user guide –If Equipped provided in your InfoCase for complete operating (Typical View - your coach may vary in instructions. appearance according to floorplan) Your coach may be equipped with a TV TV –...

  • Page 79: Bedroom Tv 12-Volt Master Power Switch

    SECTION 8 – ENTERTAINMENT AUDIO-VIDEO SYSTEM BASIC OPERATION NOTE: For your convenience, we have also included a handy, tear-out version of this “A/V System Basic Operation” guide in Section 8 of your Operator’s Manual Supplement. See your InfoCase for specific operating guides for audio and video components.

  • Page 80: Dvd Player

    SECTION 8 – ENTERTAINMENT • When main menu screen The DVD player is connected to the TV and appears, use arrow buttons on plays through the TV stereo speakers or the remote to select desired entry deluxe sound rear radio speakers in the lounge or press the center button on area of the coach.

  • Page 81: Flip-Down Screen Video Players

    SECTION 8 – ENTERTAINMENT • Volume is adjusted with the DVD remote (or • See Video Player instruction guide in your volume buttons on DVD player). InfoCase for remote control instructions and additional information on wireless headphones. FLIP-DOWN SCREEN VIDEO PLAYERS 12-Volt Master Power (Rear Bunk models only)

  • Page 82: Electrical Inverter

    SECTION 8 – ENTERTAINMENT To Play CD Audio (or CD Video) • The Video Player is also capable of playing CD Audio music and CD Video discs. • Insert the CD label side down (facing you) into the slot on the side of the player. The player will automatically switch to proper mode to play audio or video CD.

  • Page 83: Tv Signal Amplifier

    SECTION 8 – ENTERTAINMENT Operating the Digital Antenna Further Information See the antenna manufacturer’s user guide 1. Turn the Video Selection box ON. provided in your InfoCase for complete operating and maintenance information. TV SIGNAL AMPLIFIER The TV Signal Amplifier is built into the Video Selection Box antenna and can be turned on or off with a power (Located near entertainment center cabinet)

  • Page 84: Exterior Cable Tv - 12V Connection

    A second connection may be included inside a cabinet in the bedroom for the rear TV (if equipped). ® See your authorized Winnebago Industries dealer for proper installation and sealing of roof mounted components.

  • Page 85: Furniture And Softgoods

    SECTION 9 – FURNITURE AND SOFTGOODS SLEEPING FACILITIES WARNING Do not exceed 225 lbs. maximum weight capacity. Misuse of ladder could result in death or serious injury. See Operators Manual before using ladder. WARNING • Maximum Capacity: 225 lbs. Sleeping facilities are not intended for use while vehicle is in motion.

  • Page 86: Sofa/Bed Conversion

    SECTION 9 – FURNITURE AND SOFTGOODS •Lower ladder to floor. •Make sure top of ladder is properly engaged onto retainer brackets and ladder is resting firmly on floor before using. Security Latch (Located on front of sofa) - Pull OUT to release •...

  • Page 87: Dinette/Bed Conversion

    SECTION 9 – FURNITURE AND SOFTGOODS DINETTE/BED CONVERSION –If Equipped (Typical view – your coach may differ) Security Latch Handle accessible through front sofa opening Dinette to Bed 1. Release the catch on the table leg brace and fold the leg up against the bottom of the table. Security Latch Handle (Shown with sofa seat lifted) - Press DOWN to release...

  • Page 88: Dinette/Bed Conversion - Dream Dinette

    SECTION 9 – FURNITURE AND SOFTGOODS 3. Arrange dinette cushions to cover bed area. DINETTE/BED CONVERSION - DREAM DINETTE ™ –If Equipped (Typical view – your coach may differ) Dinette to Bed 1. Release the lock rod (located on the bottom of the table) by turning the lock rod clockwise.

  • Page 89: U-Shaped Dinette/Bed Conversion

    SECTION 9 – FURNITURE AND SOFTGOODS 4. Arrange dinette cushions to cover bed area. 2. Lift edges of the dinette cushions up and push the dinette table straight down. Make sure the table is lowered as far as it will go so when arranging the cushions to cover the bed area, they are even with the other dinette cushions.

  • Page 90: Dinette Conversion

    3. Place dinette table(s) securely onto the dinette dinette seat (lift removable panel below pedestal leg(s). seat cushion to access) or you may use the back dinette seat cushion and two bolster cushions, depending on model. -Typical View Reverse steps to reassemble to dinette configuration.
  • Page 91 SECTION 9 – FURNITURE AND SOFTGOODS Sofa to Bed 1. Remove seat back cushions and set aside. 2. Using the pull strap (attached to the back side 4. Unfold the bottom section of the sofa bed and of the sofa), pull the sofa back out and extend extend all the way down to the floor.
  • Page 92 SECTION 9 – FURNITURE AND SOFTGOODS NOTE: The air mattress is plugged into an AC Turn the Comfort Adjust dial to the OFF power outlet behind the sofa. position to disable the Silent Night Comfort It may be necessary to press the “Reset” Adjust feature.

  • Page 93: Roller Shades (Manual) - Solar Day/Night

    SECTION 9 – FURNITURE AND SOFTGOODS NOTICE To avoid mattress damage, fold edges back 6 inches and foot end back 20 inches before returning to sofa position. 6. Grasp the pull strap and proceed to bring sofa all the way up. Once the sofa is back in original position, replace the sofa back cushions.

  • Page 94: Wood Furniture And Cabinetry

    No matter which species you choose for your new Winnebago Industries motorhome cabinetry, please keep in mind that no two pieces of wood are exactly the same.

  • Page 95: Slideout Rooms

    SECTION 10 – SLIDEOUT ROOMS Rear slideout switches are typically located on SLIDEOUT ROOM KEYLOCK a wall in the rear of the coach in or near the slideout room. Location varies by model and A Master Slideout Room Keylock is located floorplan.
  • Page 96 SECTION 10 – SLIDEOUT ROOMS To Retract Slideout Room Before Retracting! WARNING • Be sure the coach is level and the Parking Brake is set. CRUSH HAZARD. Keep people and • Ensure exterior compartment doors are closed objects clear of the inside and outside of the slideout room when operating.

  • Page 97: Slideout Room - Extreme Weather Precaution

    SECTION 10 – SLIDEOUT ROOMS • Press the Slideout Room “RETRACT/IN” SLIDEOUT ROOM switch and hold until the room is fully TROUBLESHOOTING retracted, then release the switch. (LIPPERT) • To stop retracting the room during operation, release the button. -If Equipped •...

  • Page 98: Slideout Emergency Retraction (Lippert)

    10-4...
  • Page 99 UP (disengage). Slideout Motor Retention Screw (Located along exterior slideout trim) -If Equipped 2. Pull back wipe seal to access slideout motor. 3. Using a flat-head screwdriver, push bottom of slideout motor UP to disengage (approximately 1/2” from base). Repeat on opposite slideout motor.

  • Page 100: General Slideout Care

    SECTION 10 – SLIDEOUT ROOMS Slideout Room Seal Care and 5. When the slideout room is fully retracted, secure the room with a support item (e.g. 2x4 Maintenance wood board) above the interior slideout room While most household cleaners work well for to secure room during travel.

  • Page 101: Maintenance And Storage

    • Have the sealant replaced if you notice any of attention. Delaying these repairs may allow water the above. Your local Winnebago Industries leakage and result in damage to interior ceiling dealer has the correct and necessary parts and and body panels, upholstery, etc., which is not experience to help you maintain your sealants.

  • Page 102: Exterior Finish

    SECTION 11 – MAINTENANCE AND STORAGE weight to the vehicle. This, in effect, reduces the • Wash with cool water out of direct sunlight amount of cargo you can carry and remain within using a mild liquid soap (any “no-tears” baby GVWR and GAWR limits.

  • Page 103: Exterior Graphic Care

    SECTION 11 – MAINTENANCE AND STORAGE If the finish begins to look dull or discolored, • Wash graphics with plain soap and water or it may need to be cleaned with a polishing or any car wash detergent. Rinse thoroughly. cleaning compound formulated for gel-coated •...

  • Page 104: Exterior Lights

    EXTERIOR LIGHTS motorhome is parked for an extended ® period of time. Most Winnebago Industries vehicles have polycarbonate lenses on exterior lamps, which are very sensitive to a variety of chemical solvents and cleaners.

  • Page 105: Ceiling Fabric Care

    SECTION 11 – MAINTENANCE AND STORAGE UltraLeather Cleaning Chart WARNING Detergent/ Cleaner/ Type of Stain Water Degreaser  Coffee, Tea When cleaning upholstery and fabric, do  not use lacquer thinner, nail polish Red Wine, Liquor remover, laundry soaps, or bleach. Never ...

  • Page 106: Water Stains

    SECTION 11 – MAINTENANCE AND STORAGE These materials are made from polypropylene Most commercially available carpet and or polyester synthetic fibers, so they clean very upholstery cleaners will do an excellent job well with virtually no damage to the color or removing stains.

  • Page 107: Cabinetry - Cleaning

    SECTION 11 – MAINTENANCE AND STORAGE stubborn stains, perform the following CABINETRY – CLEANING procedures for your stainless steel appliances to start shining again. Wooden items may be cleaned with a soft cloth and a good quality wood finish cleaning Scale product.

  • Page 108: Galley Sink

    SECTION 11 – MAINTENANCE AND STORAGE • Do not use abrasive powder detergents that RANGE AND REFRIGERATOR could ruin the surface finish. For care and appearance maintenance of the • Do not use wool, abrasive brushes, or tools range and refrigerator, refer to the appliance that have previously cleaned other metals, manufacturer’s operation and maintenance because as well as scratching the surface, they...

  • Page 109: Bathroom

    SECTION 11 – MAINTENANCE AND STORAGE • Protect flooring from prolonged direct BATHROOM sunlight exposure. Treatment of Stains Toilet For instructions on the care of your toilet, refer Acids, alkali, alcoholic beverages, coffee, soft to the information in your InfoCase. drinks, ketchup, fruit, fruit juices, food, vegetables, mustard, ink, and iodine: Tub and Shower Walls...

  • Page 110: Vehicle Storage - Removal

    SECTION 11 – MAINTENANCE AND STORAGE 4. Clean and defrost the refrigerator. Prop the If you are storing your vehicle through the door open slightly to allow any odors to winter, or in cold climates, extra preparations dissipate. Place an open box of baking soda must be made to protect equipment and systems inside the refrigerator to help absorb odors.

  • Page 111: Chassis Service And Maintenance

    SECTION 11 – MAINTENANCE AND STORAGE 14. Clean wall and counter surfaces. 15. Replace batteries, if necessary, and check out electrical system to make sure all lights and electrical components operate. 16. Check tires for proper cold inflation pressure. See “Vehicle Certification Label” in Section 1 - Introduction.

  • Page 112: Coach Maintenance Chart

    SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Propane Gas System ...
  • Page 113 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Safety Equipment Check operation of the following items: ...
  • Page 114 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Sealants ...

  • Page 115: Miscellaneous

    In urban areas, the most common places to tire. (If the left side weighs 3,100 lbs. and the find a public access scale are commercial truck right side weighs 2,700 lbs., at least 100 lbs. of stops. In rural areas, most grain storage elevators the load must be shifted from the left side to the have scales available.
  • Page 116 SECTION 12 – MISCELLANEOUS Corner Weighing (Side-to-Side) You will first drive only your front wheels onto the scale pad, then drive ahead so that the The most accurate method of weighing a whole vehicle is on the scale, then finally pull off motorhome is to weigh each “corner”...

  • Page 117: Car Or Trailer Towing

    SECTION 12 – MISCELLANEOUS axle is 12,000 lbs., then the load on each rear dual listed Gross Weight Ratings. See “Vehicle set (left rear duals or right rear duals) should not Certification Label” in the Introduction section exceed 6,000 lbs. for information on gross weight ratings.

  • Page 118: Trailer Wiring Connector

    SECTION 12 – MISCELLANEOUS Before descending a steep or long grade when TRAILER WIRING towing a trailer, reduce speed and shift into a CONNECTOR lower gear to control vehicle speed. Avoid prolonged or frequent application of brakes, Your coach is pre-wired for trailer or car which could cause overheating and brake failure.

  • Page 119: Power Awning

    350 The tow vehicle brakes may be rated for lbs. All Winnebago Industries models operation at GVWR, not GCWR. equipped with a Class IV hitch have a...

  • Page 120: Storage Compartment Doors

    STORAGE COMPARTMENT COVER/FOLDING TABLE The ladder on your vehicle is provided for limited access to the roof. -If Equipped Walking or working on the roof should be left Depending on model, your coach may be to qualified service personnel using proper safety equipped with a folding table located in the rear equipment in a safe environment.
  • Page 121 SECTION 12 – MISCELLANEOUS WARNING Do not exceed 225-lb. maximum weight capacity. Misuse of ladder could result in death or serious injury. See Operators Manual before using ladder. • Maximum Capacity: 225 lbs. • Do not overload. Ladder is intended for one person.

  • Page 122: Humidity And Condensation

    SECTION 12 – MISCELLANEOUS 2. The turbine fan will start automatically as the You can help reduce excessive moisture vent dome is raised and stop as the vent dome inside the motorhome by taking the following is lowered and closed. (Fan Speed knob must steps: be in a position other than 0-Off).
  • Page 123 Electrical System – House 12-Volt DC ..6-5 Air Conditioner Filter ........ 4-10 Emergency Exits .......... 2-6 Air Conditioner/Heater – Automotive Engine Access – Interior ......3-8 (Dash) ............3-5 Engine Cooling System ....... 3-8 Air Springs – Rear Helper ......3-9 Engine Overheat ........
  • Page 124 Range Hood ..........4-4 Undercarriage ..........11-1 Refrigerator ..........4-1 U-Shaped Dinette/Bed Conversion ....9-5 Refrigerator Service Access Compartment .. 4-2 Vehicle Certification Label ......1-4 Reporting Safety Defects ......1-2 Vehicle Storage – Preparation ....11-9 Roadside Emergency ........2-9 Vehicle Storage –...

Table of Contents

Save PDF
