- Page 1 ASSEMBLY / OPERATOR'S MANUAL GF 5001 MHA - GYROTEDDER PLEASE READ CAREFULLY BEFORE USING THE MACHINE N° 95205 B.GB - 05.1999...
-
Page 2: About Improvements
DEAR OWNER, In buying a KUHN machine you have chosen wisely. Into it have gone years of thought, research and improvements. You will find, as have thousands of owners all over the world, that you have the best that engineering skill and actual field testing can produce. You have purchased a dependable machine, but only by proper care and operation can you expect to receive the performance and long service built into it. - Page 3 CONTENTS Page...
-
Page 4: Safety Advice
SAFETY ADVICE DESIGNATED USE OF THE MACHINE GF 5001 MHA GF 5001 MHA... -
Page 5: Basic Principles
GENERAL SAFETY RECOMMENDATIONS BASIC PRINCIPLES... - Page 6 ATTACHMENT...
-
Page 7: Power Take-Off
POWER TAKE-OFF (rotational frequency) Rotational frequency Rotational frequency 540 min... -
Page 8: Hydraulic System
HYDRAULIC SYSTEM TIRES... -
Page 9: Maintenance
MAINTENANCE... - Page 10 SPECIAL SAFETY RECOMMENDATIONS...
-
Page 11: Safety Decals
SAFETY DECALS... -
Page 13: Technical Specifications
TECHNICAL SPECIFICATIONS... - Page 14 ASSEMBLY INSTRUCTIONS 1) Frame assembly (photos 1 and 1 A) NOTE 2) Fitting the 3-point frame (fig 2) 3) Fitting the stand (photo 3)
- Page 15 4) Fitting reflectors (fig. 4) 5) Fitting frame shield (photo 5) 6) Fitting the wheels (photo 6)
- Page 16 7) Fitting tine arms and tines Before fitting tine arms and tines fold the intermediate and the outer rotors in working position. 12 daNm 88 ft.lbs 16 daNm (120 ft.lbs) 16 daNm 120 ft.lbs...
- Page 17 8) Fitting control cords (photo 9)
- Page 18 9) Fitting the safety guards (photos 10 and 10 A) 5 daNm / 37 ft.lbs 3 daNm / 20 ft.lbs 9 daNm / 65 ft.lbs...
-
Page 19: Fitting To The Tractor
ATTACHMENT FITTING TO THE TRACTOR GF 5001 MHA... -
Page 20: Pto Shaft
PTO SHAFT PTO shaft to the 540 rpm (min ) tractor drive These recommendations and adjustments must be respected to avoid damage or premature wear of the PTO. Never connect the PTO to the 1000 rpm (min ) tractor drive. To avoid accidents which could be serious, make sure that the guards are always correctly in place and secured with the safety chain (photo 11). -
Page 21: Working Position And Adjustments
WORKING POSITION AND ADJUSTMENTS GF 5001 MHA NEVER ENGAGE THE TRACTOR PTO WHEN THE OUSIDE ROTORS ARE FOLDED INTO TRANSPORT POSI- TION. - Page 22 GF 5001 MHA...
-
Page 23: Operating Speed
OPERATING SPEED First time over Second time over (rotational frequency) (rotational frequency) -
Page 24: Transport Position
TRANSPORT POSITION NEVER ENGAGE THE TRACTOR PTO WHILE THE MACHINE IS IN THE TRANSPORT POSITION. KEEP ALL PERSONS AWAY FROM THE VICINITY OF THE MACHINE BEFORE PIVOTING THE OUTER ROTORS INTO WORK OR TRANSPORT POSITION. -
Page 25: Parking The Machine
PARKING THE MACHINE IF EVER THE GF 5001 MHA IS TO BE PARKED WHILST IN ITS TRANSPORT POSITION, AN AREA MUST BE USED WHERE THE GROUND IS VERY EVEN AND LEVEL. WEDGES MUST ALWAYS BE PLACED UNDER THE 2 CENTRAL WHEELS (photo 24). - Page 26 LUBRICATION Grease the following points with SHELL Multi-Purpose grease NLGI grade 2 : Once a day Once a week Once a year Lubricate the following points with SHELL OIL : Once a week TO ENSURE TROUBLE FREE OPERATION OF YOUR MACHINE, WE RECOMMEND SHELL LUBRICANTS...
-
Page 27: Optional Accessories
OPTIONAL ACCESSORIES 1) 3-POINT FRAME EXTENSION (Kit No 114 6230) (photo 26) 2) DUPLEX REDUCTION GEARBOX (Kit No 111 6440) GF 5001 MHA (rotational frequency) (rotational frequency) GF 5001 MHA (rotational frequency) (min... - Page 28 3) SIGNALLING ELEMENTS (Kit No. 111 6680)
-
Page 30: Sound Levels
SOUND LEVELS Sound levels given out by : GF 5001 MHA Gyrotedder Sound levels have been measured in accordance with the measuring methods as defined in : HM Agricultural Inspectorate AGRICULTURAL MACHINERY NOISE Legislation and guidance on methods of testing... -
Page 31: Limited Warranty
LIMITED WARRANTY KUHN S.A. THESE CONDITIONS ARE SUBJECT TO THE FOLLOWING EXCEPTIONS : THE CUSTOMER WILL BE RESPONSIBLE FOR AND BEAR THE COSTS OF:... - Page 32 LIMITED WARRANTY IS DEPENDENT UPON THE STRICT OBSERVANCE BY THE PURCHASER OF THE FOLLOWING PROVISIONS : DISCLAIMER OF FURTHER WARRANTY There are no warranties, expressed or implied, except as set forth above. There is no warranty of merchantability. There are no warranties which extend beyond the description of the product contained herein.
- Page 33 - N O T E S -...
- Page 35 This machine complies with the safety requirements of the European machinery directive. The Operator should respect all Health and Safety regulations as well as the Highway Code. For your own safety, use only genuine KUHN spare parts. The manufacturer disclaims all responsibilities due to incorrect use or non-compliance with the...
- Page 36 KUHN parts KUHN S.A. 4 Impasse des Fabriques F - 67706 SAVERNE CEDEX Tél. : + 33 (0) 3 88 01 81 00 - Fax : + 33 (0) 3 88 01 81 03 www.kuhnsa.com - E-mail : info@kuhnsa.com...
