2–2
T1K–MODBUS Specifications
T1K–MODBUS Base Controller Specifications
Operating Temperature
Storage Temperature
Ambient Humidity
Voltage Withstand
Insulation Resistance
Vibration Resistance
Shock Resistance
Noise Immunity
Atmosphere
Size
Weight
Connector
Connection Port Type
Protocol
Station Number
Number of I/O Points
Baud Rate (bps)
Communication Data
Start Bit
Stop Bit
Parity Bit
Communication Timeout
RTS On / RTS Off Delay Time
Communication Status Indicators
Module Status Indicators
General
32° F to 131° F (0° C to 55° C)
–4° F to 158° F (–20° C to 70° C)
30% – 95% relative humidity (non–condensing)
1500VAC, 1 minute (15–pin connector internal)
500VDC, 10MΩ
MIL STD 810C, Method 514.2
MIL STD 810C, Method 516.2
NEMA (ICS3–304) Impulse noise 1µs, 1000V
FCC class A RFI (145MHz, 435MHz 10W, 10cm)
No corrosive gases
Environmental Pollution Level is 2.
1.89"Wx3.15"Hx3.26"D (48Wx80Hx83D)mm
6.0 oz. (170 g)
MODBUS Port Specifications
15–pin female D–shell connector
RS232C, RS–422/485
MODBUS RTU
1 to F7h (247) Rotary Switch Setting
Inputs: 1024; Outputs: 1024
300, 600, 1200, 2400, 4800, 9600, 19200,
38400 (Dip Switch 1–3 selectable)
8 Bit (Fixed)
1 Bit (Fixed)
1 Bit (Default), 2 Bit
Selectable with Dip Switch 4 ON (Option Mode)
Use T1K–MODBUS Setup Tool
ODD (Default) / EVEN / NONE;
Selectable with Dip SW 4 ON (Option Mode)
Use T1K–MODBUS Setup Tool
500ms, 1s (Default), 2.5s, 5s, 10s, 25s, 60s
Selectable with Dip SW 4 ON (Option Mode)
Use T1K–MODBUS Setup Tool
0 (Default) / 2 / 5 / 10 /50 /100 / 500 ms
Selectable with Dip SW 4 ON (Option Mode)
Use T1K–MODBUS Setup Tool
RUN, ERR, TX, RX
PWR, DIAG
