Interroll RollerDrive EC310 Technical Data

Product Description
Properties The ZoneControl is the single zone control for the RollerDrive EC310. The ZoneControl can be used to create
stand-alone, zero pressure accumulation conveyors which require no higher-order control. Additional functions and
communication to upstream and downstream conveyors can be provided via digital inputs and outputs (I/O's). No
DriveControls are needed to set up a conveyor as the ZoneControls include their functions.
Design
The I/O's and voltage supply is provided by a simple switching wire.
information
Communications cable: Conventional Cat-5 cable (IT ethernet cable).
Configuration
The configuration of the ZoneControl can simply be handled by DIP switches. Two versions of conveyor logic are
available: individual or block pull-off.
Functions
• Logic for zero pressure accumulation conveying (incl. initialisation)
• Communication with upstream and downstream zones via peer-to-peer connection
• Speed adjustment
- DIP switch (per accumulation zone)
- External analogue signal (for the entire conveyor system)
• Adjustment of the RollerDrive's direction of rotation
- DIP switch
- External digital signal
• LED status indicator
• Zone sensor connection
• Start sensor connection
• NPN or PNP switching logic
• Switching a second RollerDrive, status reading, starting and stopping of individual zones via I/O's
• Empty running, error signalling of all connected zones via I/O's
• All signals relate to mass of voltage supply
106 DriveControls Overview p 100
Zo n eC o n t r o l
RollerDrive EC310 p 88 RollerDrive EC310 IP66 p 96
The accumulation conveyor logic for RollerDrive EC310
Technical Data
Electrical data
Rated voltage
Temporarily permissible voltage range
Permissible voltage undulation
Rated current
Max. start-up current
Fuse
Protection rate
Ambient conditions
Ambient temperature in operation
Ambient temperature during transport and storage -20 to +75 °C
Max. temperature change
Max. air humidity
Cable cross-sections
Power Supply
Inputs / Outputs (I/O)
The effective current in the application depends on the conveyor weight, conveyor speed and number of cycles.
Reference number: 89RC
Material Specification p 222 Refer to the Planning Section from p 168 onwards for help with planning and design
24 V DC
18 to 26 V DC
3 %, recommended: < 1 %
2.0 A
5.0 A
present, non-replaceable
IP20
0 to +40 °C
1 % in 3 h; 2 cycles in compliance with IEC 60068-2-14
90 %, non-condensing
Fine-wired, 1.5 mm² (AWG 16)
Fine-wired, 0.08 to 0.5 mm² (AWG 28 to 20)
DriveControl
ZoneControl
