RESIDENCE COLONNA CONDENS KV 130 - 30 ISC
EN USER MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Riello Residence Colonna Condens KV 130-30 ISC

Summary of Contents for Riello Residence Colonna Condens KV 130-30 ISC

  • Page 1 RESIDENCE COLONNA CONDENS KV 130 - 30 ISC EN USER MANUAL...

  • Page 2: Table Of Contents

    Please accept our renewed thanks for your purchase. Riello S.p.A. INDEX GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 General safety information .

  • Page 3: General

    GENERAL GENERAL 1 . 1 General safety information This instruction manual and that for the installer Periodically check that and R’s Technical Assistance Service are inte- operating pressure in gral parts of the boiler. They must be kept safe and the water circuit is over must ALWAYS accompany the boiler, even if it is sold 1 bar.

  • Page 4: Control Panel

    GENERAL 1 .3 Control panel °C boiler pressure gauge Displays the pressure in the central heating circuit. Storage cylinder temperature selector Allows you to set the temperature of the domestic hot water. Green LED When lit, shows that a flame is being detected. Two figure digital display Displays information on boiler status.

  • Page 5: Technical Assistance Service

    TECHNICAl ASSISTANCE SERvICE 2 TECHNICAl ASSISTANCE SERvICE Have R’s Technical Assistance Service start-up your boiler for the first time. Once this has been done, the boiler can be left to function automatically. Under certain circumstances, such as after long periods of disuse, the user may need to re-start it without involving the R’s Technical Assistance Service .
  • Page 6 TECHNICAl ASSISTANCE SERvICE SUMMER (}): With the function selector set to Summer, the boiler functions only in domestic hot water mode. The temperature gauge (1) shows the temperature of the hot water inside the storage cylinder. °C To ensure correct functioning, set the room tempe- rature thermostat to its minimum setting.
  • Page 7 TECHNICAl ASSISTANCE SERvICE STARTING UP ThE bOILER If a timer or room thermostat is installed, these must be switched on and adjusted to a temperature higher than current room temperature before the boiler can start up. The boiler will remain in stand-by mode until the bur- ner ignites following a request for heat.

  • Page 8: Shutdown

    TECHNICAl ASSISTANCE SERvICE 2 .2 Shutdown If you are going away for a short period of time like a weekend or a short holiday, etc., turn the function se- lector to “0” OFF/RESET. The digital display reads out the message shown alongside.

  • Page 9: Warning Leds And Errors

    TECHNICAl ASSISTANCE SERvICE 2 .3 Warning leds and errors ThE MAIN CONTROL PANEL Green LED (3) Off = boiler in stand-by, burner out On = burning lit, boiler functioning normally. Red LED (5) Safety shutdown: an error code flashes on the display. Burner lockout: the red LED lights and an error code flashes on the display.

  • Page 10: Cleaning

    TECHNICAl ASSISTANCE SERvICE Dealing with error AL41 Check the pressure on the control panel pressure gauge. If it is below 0.5 bar, proceed as follows. − Turn the function selector to “0” − Remove the top front panel from the boiler by pulling it forwards.

  • Page 11: Useful Information

    TECHNICAl ASSISTANCE SERvICE 2 .6 Useful information Seller: ..............Installer: .
  • Page 12 RIELLO S.p.A. 37045 Legnago (VR) Tel. 0442630111 - Fax 0442630371 - www.riello.it As part of the company’s ongoing commitment to perfecting its range of products, the appearance, dimensions, technical data, equipment and accessories may be subject to variation.
