1.8 Level A – parameters in address order (9500 only)
Parameter Size Address
Name (hex)
An.Hi 2 02D9
An.Lo 2 02DB
Hi.In 2 02DD
Lo.In 2 02DF
DECP 1 03E1
SP3.A 1 03E2
SP3.B 1 03E3
Brn.3 1 03E4
Rev.3 1 03E5
Set.3 2 02E8
Hys.3 2 02EA
Note: The level A menu is only available in the 9500 instrument.
1.9 Level P – parameters in address order (9500P only)
Parameter Size Address
Name (hex)
MaxProg 1 033A
Prog 1 036C
Note: The level P menu is only available in the 9500P instrument.
Note: The other elements of the programmer (Level P) menu are unavailable from the communications
interface.
