CAL Controls 3300 Communications Manual page 6

1.3 Level C - parameters in address order
Parameter Size Address
Name (hex)
Addr 1 03D5
Baud 1 03D6
Data 1 03D7
Dbg 1 03D8
note that all changes to the communications level parameters take effect immediately on leaving the
menu, or on receipt of the exit program mode command. The dbg feature may be set on or off. When
on, the right-most digit will flash 3 horizontal segments on receipt of a character when a
communications board is fitted, the left-most digit will flash on transmission of a character.
1.4 Level 1 - parameters in address order
Parameter Size Address
Name (hex)
Set.2 2 0081
Ofst 2 0083
Band 2 0085
Bnd.2 2 0087
Tune 1 0189
Dac 1 018A
Int.t 1 018B
Der.t 1 018C
Cyc.t 1 018D
Cyc.2 1 018E
SP.lk bit 0028
SPrr 2 02D0
Soak 2 02D2
SPrn 1 03D4
COMMERCIAL IN CONFIDENCE
R/W ModBus Internal Storage, Step rate in
Function Internal units
read/write
RW 3/6 0..255
RW 3/6 0=1200, 1=2400, 2=4800, 3=9600,
4=19200
RW 3/6 0=18n1, 2=18e1, 3=18o1,
RW 3/6 0=off, 1=on
R/W ModBus Internal Storage, Step rate in Internal units,
Function Limits
read/write
RW 3/6 Degrees * 10 [LIN]
Step 0.1 or 1 depending on disp selection
min=LoSc, max=HiSc
RW 3/6 Degrees * 10 [LIN]
normal inc/dec
see separate details for limits
RW 3/6 Degrees * 10 [LIN]
normal inc/dec
min=0.1 max=25% of Sensor Maximum
RW 3/6 Degrees * 10 [LIN]
normal inc/dec
see separate details for limits
RW 3/6 0=off, 1=on, 2=park, 3=at Setpoint
RW 3/6 stored as value*2 so 0.5 is stored as 1
step by 0.5
Min=0.5 max=5.0
RW 3/6 intt * 10 up 10.0, then intt+90
normal inc/dec
0=off min=0.1, max=60
RW 3/6 1 — 200 in 1 sec steps
RW 3/6 Cyct * 10 up 10.0, then Cyct+90
normal inc/dec
0=off min=0.1, max=81
RW 3/6 Cyc2 * 10 up 10.0, then Cyc2+90
normal inc/dec
0=off min=0.1, max=81
RW 1/5 0=off, 1=on
RW 3/6 Stored as SPrr
if <100 step by 1, if <1000 step by 5 else step by
10
min=0 max=9990
RW 3/6 0xFF00 = - - , 0=off, otherwise Soak * 10
Step by 1 up to 120, then 5 up to 300 then by 10
min = 1, max=1440
RW 3/6 0=off, 1=on, 2=hold
Page 5
Comments
valid range 1..247
Comments
9500 max is
100% of sensor
maximum
9500 display
effected by DECP
when LIN input
selected
9500P See Level P
section for notes
on starting a
program
