1.6 Level 3 - parameters in address order
Parameter Size Address
Name (hex)
SP1.d 1 019D
SP2.d N/A N/A
Burn 1 019E
Rev.d 1 019F
Rev.l 1 01A0
Span 2 00A1
Zero 2 00A3
Chek bit 0026
Read (var) 2
Read (hi) 2 007A
Read (lo) 2 007C
Data (Ct A) 2 0432
Data (Ct B) 2 0434
Data (Ct 1) 2 0436
Data (Ct 2) 2 0438
Data (Ct 3) 2 043A
Data (Ct 4) 2 043C
Data (Os 1) 2 043E
Data (us) 2 0440
Data (Os 2) 2 0442
Ver 2 04FD
(S/W ver)
Rset bit 0027
1.7 Level 4 - parameters in address order
Parameter Size Address
Name (hex)
Der.S 1 019A
Dis.S 1 019B
Lock 1 019C
Prog bit 002D
No.Al bit 002E
COMMERCIAL IN CONFIDENCE
R/W ModBus Internal Storage, Step rate in
Function Internal units, Limits
read/write
R 3/6 0=none, 1=rly, 2=ssd, 3=rly1,
4=rly2
5=ssd1(ssd2)
N/A N/A Not stored
RW 3/6 0=upsc, 1=dnsc, 2=1u2d, 3=1d2u
RW 3/6 0=1r2d, 1=1d2d, 2=1r2r, 3=1d2r
RW 3/6 0=1n2n, 2=1l2n, 3=1n2l, 4=1l2l
RW 3/6 Span * 10 [LIN]
normal inc/dec
min = -0.25 * Sensor Min
max = 0.25 * Sensor Max
RW 3/6 Zero * 10 [LIN]
normal inc/dec
min = -0.25 * Sensor Min
max = 0.25 * Sensor Max
RW 1/5 0=off, 1=on
R 3 Read(hi) * 10 [LIN]
R 3 Read(lo) * 10 [LIN]
R 3 CtA * 25
R 3 CtB * 25
R 3 Ct1 * 25
R 3 Ct2 * 25
R 3 Ct3 * 25
R 3 Ct4 * 25
R 3 Os1 * 10 [LIN]
R 3 Us * 10 [LIN]
R 3 Os2 * 10 [LIN]
R 3 0xFFFF/ 0x01 means ver 391
0x02 means ver 392
0x03 means ver 941
0x04 means ver 951
0X05 means ver 952
RW 1/5 0=none, 1=all
R/W ModBus Internal Storage, Step rate in
Function Internal units, Limits
read/write
RW 3/6 Ders * 10
RW 3/6 0=dir, then 1..32
step by 1
min=0, max=32
RW 3/6 0 = none, 1=lev3, 2=lev2, 3=all
1/5 0 = auto, 1=stay
RW 1/5 0 = off, 1=on
Page 7
Comments
9500
0=none 1,3,4,10=ssd
2,5,6,8=rly 7,9=anlg
Inverse of SP1.d
computed from 2 vars (below)
Read(hi) - Read(lo) with
degC to decF if required (if
unit=1)
3300/9300 ver 1
3300/9300 ver2
9400 ver 1
9500 ver 1
9500 P ver 2
Comments
