CAL Controls 3300 Communications Manual page 7

1.5 Level 2 - parameters in address order
Parameter Size Address
Name (hex)
SP1.P
SP1_ontime 2 0062
SP1_proptime 2 0078
Disp bit 002A
Hand 1 018F
PL.1 1 0190
PL.2 1 0191
SP2.A 1 0192
SP2.b 1 0193
Hi.SC 2 0094
Lo.SC 2 0096
Inpt 1 0198
Unit 1 0199
COMMERCIAL IN CONFIDENCE
R/W ModBus Internal Storage, Step rate in
Function Internal units, Limits
read/write
not stored
R 3
R 3
RW 1/5 0=low res, 1= high res
RW 3/6 No scaling
step by 1
min 0=off, max=100
RW 3/6 No scaling
step by 1
min=0, max=100
RW 3/6 No scaling
step by 1
min=0, max=100
RW 3/6 0=none, 1=dvhi, 2=dvlo, 3=band,
4=fshi, 5=fslo, 6=cool
RW 3/6 0=none, 1=ltch, 2=hold, 3=ltho,
4=nlin
RW 3/6 HiSc * 10 [LIN]
step by 0.1 or 1
min=Sensor Min, max=Sensor Max
RW 3/6 LoSc * 10 [LIN]
step by 0.1 or 1
min=Sensor Min, max=Sensor Max
RW 3/6 0=none, 1=Tcb, 2=Tce, 3=Tcj,
4=Tck, 5=Tcl, 6= Tcn, 7=TcR,
8=Tcs, 9=Tct, 10=RTD, 11=lin1
12=lin2, 13=lin3, 14=lin4, 15=lin5
RW 3/6 0=none, 1=C, 2=F, 3=bar, 4=PSI,
5=Ph, 6=Rh, 7=set
Page 6
Comments
must be computed as
SP1_ontime/SP1_proptime
*100%
9500P 7=EOP
9500
11=lin
12-15 unused
