Level 3 - CAL Controls 3300 Operating Manual

LEVEL 3

OUTPUT CONFIGURATION
Note: 'Read only' after initial configuration. rSET ALL full
reset to factory settings required to change
subsequently.
SP1.D
[nonE] rLY
SP1.D
Select SP1 output device
[nonE] SSd rLY
SP2.D
Read SP2 output device
(read only)
Dual Relay and Dual SSd output options Models
3311 and 3322 are factory set. See page 22
Note: (when in initial configuration only)
Hold and or for 10 seconds to move to or
from output devices in shaded portion.
SSd rLY1 rLY2 SSd1
rLY2 rLY1 SSd2
BURN
Sensor burn-out/break protection
Caution: Settings affect fail safe state.
SP1
[uP.SC] Upscale
dn.SC
Downscale
1u.2d Upscale
1d.2u Downscale
REU.D
Select output modes: Direct/Reverse
Caution: Settings affect fail safe state.
SP1
[1r.2d] Reverse
1d.2d Direct
1r.2r
Reverse
1d.2r
Direct
Select Reverse on SP1 for heating and Direct for
cooling applications.
SP2
Upscale
Downscale
Downscale
Upscale
SP2
Direct
Direct
Reverse
Reverse
19
