This section details the four step initial configuration
that enables control with factory PID settings to start,
once the setpoint has been entered.

POWER-UP

On power-up the controller will display the self test
sequence and brief display blanking and then alternately
display and nonE
INPT
1

SELECT INPUT SENSOR

Press and hold and use either the
scroll through the sensor selection (see table p.31).
When the correct sensor is displayed, release the
buttons. The controller will now alternately display
selected sensor type
INPT
2 TO SELECT °C/°F
Press and release the button, the controller will now
alternately display
UNIT
Press and hold the button and using the
select °C, °F, Bar, PSI, Ph, Rh or SEt as required. Release
the buttons when the correct unit is displayed.
The controller will now alternately display selected range
(eg. ºC) and unit .
or buttons to
and eg. tc.S
and nonE .
button
3 TO SELECT SP1 (Main setpoint output device)
Note: Dual Relay and Dual SSd Output Options
Models 3311/9311 and 3322/9322 have their
outputs pre-configured. (see page 22)
Press and release the button, the controller will now
alternately display
SP1.D
Press and hold the button and using the
select SSd or rLY as required. Release the buttons when the
correct device is displayed.
The controller will now alternately display
selected output device (eg. SSd ).
4 TO ENTER INITIAL CONFIGURATION INTO
CONTROLLER MEMORY
Press and hold both and
The process temperature (e.g.
alternately displayed as no setpoint has yet been selected.
TO SET THE MAIN SETPOINT
To display the setpoint, press and hold the
0 or °F and 32 will be alternately displayed.
Press and hold the button. Press
to decrease the setpoint.
The main setpoint LED will flash indicating that SP1 output is
ON.
The controller will now be set with the factory PID settings.

SET-UP

and nonE .
button
and
SP1.D
buttons for 3 seconds.
23°C) and ParK will be
button. °C and
to increase or
