Section 2 - OPERATING INSTRUCTIONS
2.1 PRE-START CHECK LIST
2.1.9. Check the AC electrical outlet that will be
used and make sure it is a polarized outlet. The
machine has a polarized plug (one blade of plug is
wider than the other) that will accept a polarized
extension cord. The extension cord will fit into a
polarized outlet (receptacle) only one way. If plug
does not fit fully into your outlet, reverse the plug. If
it still does not fit, contact a qualified electrician to
install a proper polarized outlet. DO NOT modify or
change this polarized plug in any way.
2.2 STARTING, OPERATION & STOPPING
(RECOIL START MODELS)
(Go to Page 11 for Electric Start Models)
2.2.1. ENGINE
1. Turn fuel shut off valve to the "ON" position. See
Figure 2.3.
FIGURE 2.3
2. Insert key into ignition switch. See Figure 2.4.
3. Move choke control to the choke, "ON" position.
See Figure 2.4.
4. Move engine speed control to the "FAST"
position. See Figure 2.4.
5. Push primer button three times to start a cold
engine. NOTE: Do not use primer button to start
warm engine. See Figure 2.4.
IMPORTANT: Stop the auger/impeller and wheel drive
by releasing the auger/impeller and wheel drive control
levers. Stop the engine by moving the engine speed
control to stop or removing the key from the switch.
TURN VALVE TO
"ON" POSITION
9
MOVE CHOKE TO THE
"ON" POSITION
FIGURE 2.4
6. Pull rope start handle to crank engine.
7. After engine starts, move the choke control to
the no choke, "OFF" position. Allow a brief warm-up
until engine runs smooth.
(Continued on Next Page)
PUSH PRIMER
THREE TIMES
MOVE ENGINE
SPEED CONTROL
TO FAST
INSERT
KEY
