Thank you for buying a SNAPPER Product! Before operating your Snow Thrower, read this manual carefully and pay
particular attention to the "IMPORTANT SAFETY INSTRUCTIONS" on Pages 2 & 3. Remember that all power
equipment can be dangerous if used improperly. Also keep in mind that SAFETY requires careful use in accordance
with the operating instructions and common sense.
COPYRIGHT © 2003
SNAPPER PRODUCTS INC.
ALL RIGHTS RESERVED
Safety Instructions & Operator's Manual for
MODEL NUMBER EXPLANATION
9
SNOW THROWER
26
6
24 – 24" Auger Width
26 – 26" Auger Width
30 – 30" Auger Width
TWO STAGE
LARGE FRAME
SERIES 6
MODELS
8246
9266E
E
ELECTRIC START
SERIES DESIGNATION
6 – Series Designation
E – Electric Start
MANUAL No. 7-5394 (I.R. 3/3/03)
9266
11306
