Page 1
E – European Model I – Intermediate Frame Model Thank you for buying a SNAPPER Product! Before operating your Snow Thrower, read this manual carefully and pay particular attention to the “IMPORTANT SAFETY INSTRUCTIONS” on Pages 2 & 3. Remember that all power equipment can be dangerous if used improperly.
If you have any questions pertaining to your snow thrower which your dealer cannot answer to your satisfaction, call or write the Customer Service Department at SNAPPER, McDonough, Georgia 30253. Phone: 800/935-2967.
Spark from the plug could ignite gas exiting engine. SNAPPER dealer at least once a year and have the dealer install any new safety devices. assure that original maintained.
DECALS DANGER ROTATING IMPELLER. DO NOT use hand to unclog auger/impeller or discharge chute. Stop engine and remove key before unclogging. GROUND SPEED CONTROL. Snowthrower has 4 Forward speeds and 1 Reverse speed. Rabbit/Fast. Turtle/Slow. R/Reverse. DANGER ROTATING AUGER. Keep Away. DO NOT allow children or others in the area when Snowthrower is being operated.
Page 6
DECALS HEARING PROTECTION REQUIRED. Machine exceeds 100Lwa. MAXIMUM HANDLE VIBRATION 34 M/SEC DANGER – ROTATING AUGER. KEEP AWAY. SAFETY INSTRUCTIONS TO PREVENT INJURY: 1) Read Owner’s Manual for operating and safety instructions. 2) Observe all labels and instructions. 3) DO NOT defeat safety features of controls. They are for your protection.
Replace damaged cord immediately. Contact your Snapper service dealer for assistance. To reduce the risk of electric shock, use only with an extension cord intended for outdoor use having a cord type: SW-A, SOW-A, STW-A, STOW-A, SJW-A, SJTW-A or SJTOW-A.
Section 2 - OPERATING INSTRUCTIONS WARNING Objects can be thrown by the snow thrower while it is in operation. Thrown objects could cause serious injury to the operator or bystanders. Always wear safety goggles or other suitable eye protection. Keep people and pets away from area. 2.2.3.
Replace damaged cord immediately. Contact your Snapper service dealer for assistance. To reduce the risk of electric shock, use only with an extension cord intended for outdoor use having a cord type: SW-A, SOW-A, STW-A, STOW-A, SJW- A, SJTW-A or SJTOW-A.
Section 2 - OPERATING INSTRUCTIONS WARNING Objects can be thrown by the snow thrower while it is in operation. Thrown objects could cause serious injury to the operator or bystanders. Always wear safety goggles or other suitable eye protection. Keep people and pets away from area.
3.1 INTRODUCTION To retain the quality of the snow thrower, use only genuine SNAPPER replacement parts. Contact a local SNAPPER dealer for parts and service assistance. For the correct part or information for a particular snow thrower, always mention model and serial number.
Rubber Drive Tire Shear Bolts - 1/4-20 x 1-1/2” Hex Nuts - 1/4-20 Parts Manual for Intermediate Frame Snow Thrower - Series 3 Domestic Models: I4223, I5223, I55223, I6223, I7243, European Models: EI5223,EI55223, EI7243 manual service manual service before any other...
Section 4 - REPAIR & ADJUSTMENTS WARNING Before attempting any adjustments, maintenance, service, or repairs, stop engine and auger, always remove key from ignition switch, remove spark plug wire and secure wire away from spark plug. 4.1 AUGER BELT ADJUSTMENT/REPLACEMENT When operating machine release the auger clutch control, auger should come to a complete stop in 5 seconds.
Visually check engine drive belt for cracking, fraying, severed or belt strands exposed. NOTE: Auger and Drive Belts are difficult to install. It may be necessary to allow an authorized Snapper Dealer to install these belts. 1. Remove belt cover. See Figure 4.2.
Page 16
Visually check engine drive belt for cracking, fraying, severed or belt strands exposed. NOTE: Auger and Drive Belts are difficult to install. It may be necessary to allow an authorized Snapper Dealer to install these belts. 1. Remove belt cover. See Figure 4.2.
DO NOT reuse bolt or nut under any circumstances. Always replace existing hardware with genuine Snapper new replacement shear bolts and nuts. DO NOT substitute these shear bolts and nuts with hardware other than what is specified as auger/impeller and engine damage can result.
Section 4 - REPAIR & ADJUSTMENTS 4.1.8. SINGLE HANDLE CONTROL ADJUSTMENT (7 HP Models Only) IMPORTANT: Standing in the operator’s position, the left handle bar lever is for wheel drive engagement and disengagement. The right handle bar lever is for auger/impeller engagement and disengagement.
Section 4 - REPAIR & ADJUSTMENTS WARNING Before attempting any adjustments, maintenance, service, or repairs, stop engine and auger, always remove key from ignition switch, remove spark plug wire and secure wire away from spark plug. Before tilting machine, drain all the fuel from fuel tank. Allow engine to run, outdoors where fumes can be safely dissipated, until all fuel is removed from carburetor.
PROBLEM Engine Will Not Start 1. Fuel tank empty. Using Recoil Starter 2. Engine needs choking and priming. 3. Spark plug wire disconnected. 4. Fuel shut off valve closed. Engine Will Not Start 1. Power extension cord not plugged into machine or Using Electric Starter 120 Volt outlet for U.S.A.
For three (3) years from purchase date for the original purchaser's residential, non-commercial use, SNAPPER, through any authorized SNAPPER dealer will replace, free of charge (except for taxes where applicable), any part or parts found upon examination by the factory at McDonough, Georgia, to be defective in material or workmanship or both.
