Exploded View Parts List - Snapper 30214 Illustrated Parts List

EXPLODED VIEW - PARTS LIST
Item Part # Description
1 M194779GS CRADLE (Includes #'s 20, 31 & 55)
2 194150GS KIT, Vibration Mount
3 67989GS NUT, M8 Flange Serrated
4 186058AGS HOUSING, Engine Adapter
5 NSP ASSY, Alternator (see page 4)
6 * NUT, Hex, M8 - 1.25
7 * TPHMS, M8 - 1.25 x 35
8 96796GS WASHER, 8.4 x 22.2 x 3
9 * WASHER, 5/16 - M8 Lock
10 86307GS HHCS, 5/16-24 x 3/4, SEMS
11 24823GS HHCS, 5/16-24 x 7-7/8"
12 * HHCS, M8 - 1.25 x 25
14 191785GS BRACKET, Muffler
15 697815 GASKET, Exhaust
16 * HHCS, M6 - 1.0 x 12
17 188301GS MUFFLER
18 * SHCS, M6 - 1.0 x 20
19 83083GS SCREEN, Spark Arrest
20 B4986GS DECAL, Ground
21 194153GS KIT, Vibration Mount
22 86494GS SCREW, Wing M6 - 1.0 x 16
24 191790GS SHIELD, Heat
25 191190GS CAP
26 74908GS TAPTITE, M5-0.8 x 10 Lg.
31 196830GS DECAL, Warning Exhaust
34 195422GS COVER, RBC, Plastic w/Cap
35 195207GS KIT, Hose Formed
37 B2153GS HHCS, 12 - 14 x 7/8" Self-Driller
Snapper Model 030214 Portable Generator
Item Part #
40 194398GS
41 192980GS
44 193645GS
45 200095GS
48 195373GS
50 188333GS
51 194799GS
52 189235GS
53 202997GS
55 197798GS
58 191743AGS
59 *
900 §
Parts Not Illustrated
* - Items without part numbers are common fasteners and
are available at your local hardware store.
§ - Contact Engine Manufacturer
3
Description
KIT, Fuel Tank Hardware (Includes
Qty 4)
KIT, Valve, Tank
ASSY., Tank, Fuel Service (Includes
#41, 50, 51, 52 & 53)
CAP, Fuel
WIRE, Ground
DECAL, Fuel Level
DECAL, Danger
DECAL, Operating Instructions
DECAL, Warning, CO
DECAL, Fuel Shut Off
ASSY, Control Panel
NUT, Palnut, 3/16"
ENGINE
195605GS MANUAL, Operator's
MS3430 MANUAL, Engine
BB3061BGS BOTTLE, Oil
195639GS KIT, Decals, Service
