(6) Remove the screw.
(7) Remove each side board to board connector carefully.
(8) Insert the finger in the space, and lift the PWB gradually.
(Remove the B to B connectors in the reverse side of the PWB)
Remove the B to B connectors
in the reverse side of the PWB
Remove the screw
Lift the PWB gradually
