Model:
AVR-5805
Subject:
Disassembly Instructions
Symptom:
Disassembly instructions for the AVR-5805 DAC Unit and Digital
Unit.
Solution:
See the following pages for details:
______________________________________________________________________________________
The information contained in this document is intended for the exclusive use by DENON Authorized Service Centers and their
employees. This document may contain information that is privileged, confidential and may be protected from disclosure under
applicable laws and terms of the DENON Service Agreement. Any distribution, disclosure, dissemination or copying of this
document and the information it contains is prohibited. No responsibility will be accepted by DENON for any damage, injury or loss
resulting from the misuse of the information contained in this document.
100 Corporate Drive Mahwah, NJ 07430
CONFIDENTIALITY NOTICE:
Service Bulletin
No. : OST-US007
Date:
April 26, 2007
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Denon AVR-5805
Summary of Contents for Denon AVR-5805
- Page 1 DENON Service Agreement. Any distribution, disclosure, dissemination or copying of this document and the information it contains is prohibited. No responsibility will be accepted by DENON for any damage, injury or loss resulting from the misuse of the information contained in this document.
- Page 2 Instruction for removal of DIGITAL UNIT ASSY and DAC UNIT ASSY (1) Remove screws, detach the BOTTOM COVER (Not shown in the figure) (2) Remove 6 screws from BACK PANEL, and remove FFCs and cables (3) Remove 4 Card holders, then detach the Rear Plate/Ethernet/IEEE1394 assy unit. Remove the FFCs and cables Remove 4 Card holders Remove 6 screws from BACK PANEL...
- Page 3 (6) Remove the screw. (7) Remove each side board to board connector carefully. Remove the screw (8) Insert the finger in the space, and lift the PWB gradually. (Remove the B to B connectors in the reverse side of the PWB) Lift the PWB gradually Remove the B to B connectors in the reverse side of the PWB...
- Page 4 (9) Remove the Cables and detach the Digital unit assy. Remove the Cables (10) Remove each side board to board connector carefully. And detach the DAC unit assy.
- Page 5 Instruction for re-assemble DIGITAL UNIT ASSY and DAC UNIT ASSY (11) Install the DAC unit assy and insert each side board to board connector. (Insert the hand in the space on both sides, and push the PWB.) (11) Install the Digital unit assy and insert the cables. (12) Insert right side B to B connector.
- Page 6 (13) Confirm from the slot of the back panel, and insert the B to B connector carefully. (Insert a thin board (like the ruler) from the slot, and push the PWB). (14) Insert left side B to B connector and confirm each side board to board connector. (Insert the hand in the space on both sides, and push the PWB.) Insert the B to B Connectors.
- Page 7 (15) Insert FFCs and Cables and tighten 2 screws Tighten 2 screws Insert the FFCs and Cables (16) Install the Rear Plate/Ethernet/IEEE1394 assy unit. (17) Insert 4 Card holders,tighten 6 screws, and insert FFCs and cables Insert the FFCs and cables Insert 4 Card holders Tighten 6 screws (18) Install BOTTOM COVER ,and tighten screws.
