DENON AVR/AVC control protocol
Application model :
Application terminal : RS-232C/ Ethernet
Connector specification
1. RS-232C
Connector type : DB-9pin female type, slave straight connection (DCE type)
( 1pin : GND , 2pin : TxD , 3pin : RxD , 5pin : Common(GND) , 4,6,7,8,9pin : NC )
Communication format :
Synchronous system
Communication system
Communication speed
Character length
Parity control
Start bit
Stop bit
Communication procedure
Communication data length
Version
Date
4.37.2
27.Apr.'06
AVR-5805CI/Upgraded AVR-5805/AVC-A1XVA/Upgraded AVC-A1XV
: Tone step synchronization
: A half duplex
: 9600bps
: 135 bytes (maximum)
Contents
Original
: 8 bits
: None
: 1 bit
: 1 bit
: Non procedural
1/34
Ver. 4.37.2
Page

Advertisement

loading

Related Manuals for Denon AVR-5805CI - AV Receiver

Summary of Contents for Denon AVR-5805CI - AV Receiver

  • Page 1 DENON AVR/AVC control protocol Ver. 4.37.2 Application model : AVR-5805CI/Upgraded AVR-5805/AVC-A1XVA/Upgraded AVC-A1XV Application terminal : RS-232C/ Ethernet Connector specification 1. RS-232C Connector type : DB-9pin female type, slave straight connection (DCE type) ( 1pin : GND , 2pin : TxD , 3pin : RxD , 5pin : Common(GND) , 4,6,7,8,9pin : NC )
  • Page 2 2. Ethernet ： RJ-45(10BASE-T/100BASE-TX) Connector type Example ① Ethernet AVR/AVC Cross cable Example ② AVR/AVC Ethernet Ethernet Straight Straight cable cable Communication format ： Communication system : A half duplex Communication speed : 10Mbps/100Mbps Communication port : TCP port 23 (telnet) Communication data length : 135bytes (maximum) 2/34...
  • Page 3 NETWORK SETUP of AVR-5805UPG/AVC-A1XVA >Procedure of Network Setup mode. (1)Press SYSTEM SETUP button, then System Setup Menu appears on FL-display(and OSD) (2)Select Option Setup and select Network Setup. (3)Set parameters described below. <DHCP> "ON"---Use this setting when DHCP server is on the local network. "OFF"---Use this setting when DHCP server is not on the local network.

  • Page 4: Protocol Specification

    Protocol specification The following three data forms is defined. COMMAND The message sent to a system(AVR/AVC) from a controller(Touch Panel etc.) A command to a system is given from a controller. EVENT The message sent to a controller(Touch Panel etc.) from a system(AVR/AVC) The result is sent, when a system is operated directly and a state changes.
  • Page 5 The example of a command * <CR> is the meaning of 0x0D. SIDVD<CR> : Select Input source DVD MSTHX SURROUND EX<CR> : surround Mode Set to THX SURROUND EX MVUP<CR> : Master Volume UP PWON<CR> : system Power ON PWSTANDBY<CR> : system PoWer STANDBY SI?<CR>...
  • Page 6 Others A) COMMAND is receivable also during transmission of EVENT. B) Since CHANNEL VOLUME changes simultaneously when the SURROUND MODE changes, the value of the channel volume of all channels returns as EVENT. C) CHANNEL VOLUME returns the data of ALL channels by the present SURROUND MODE also including an intact channel. In this case, the data of an intact channel is set to "50".
  • Page 7 COMMAND and PARAMETER list COMMAND PARAMETER function example POWER ON/STANDBY change PWON<CR> STANDBY PWSTANDBY<CR> Request PW Status PW?<CR> MASTER VOLUME UP/DOWN , direct change to ***dB MVUP<CR> DOWN MVDOWN<CR> **:00 to 99 by ASCII , 80=0dB, 99=---(MIN) MV80<CR> Request MV Status MV?<CR>...
  • Page 8 COMMAND PARAMETER function example SLB UP CVSLB UP<CR> SLB DOWN ---SURROUND L(B)ch CVSLB DOWN<CR> SLB ** **:38 to 62 by ASCII , 50=0dB CVSLB 50<CR> SRB UP CVSRB UP<CR> SRB DOWN ---SURROUND R(B)ch CVSRB DOWN<CR> SRB ** **:38 to 62 by ASCII , 50=0dB CVSRB 50<CR>...
  • Page 9 COMMAND PARAMETER function example PHONO Select INPUT source SIPHONO<CR> SICD<CR> TUNER SITUNER<CR> SIDVD<CR> SIVDP<CR> SITV<CR> SIDBS<CR> VCR-1 SIVCR-1<CR> VCR-2 SIVCR-2<CR> VCR-3 SIVCR-3<CR> VCR-4 SIVCR-4<CR> V.AUX SIV.AUX<CR> CDR/TAPE SICDR/TAPE<CR> SIAUX<CR> Request SI Status SI?<CR> MAIN-ZONE ON/OFF change ZMON<CR> ZMOFF<CR> Request ZM Status ZM?<CR>...
  • Page 10 10/34...
  • Page 11 COMMAND PARAMETER function example AUTO set DIGITAL INPUT AUTO mode SDAUTO<CR> set DIGITAL INPUT force PCM mode SDPCM<CR> set DIGITAL INPUT force DTS mode SDDTS<CR> ANALOG set force ANALOG INPUT mode SDANALOG<CR> EXT.IN-1 set EXT.IN-1 mode SDEXT.IN-1<CR> EXT.IN-2 set EXT.IN-2 mode SDEXT.IN-2<CR>...
  • Page 12 COMMAND PARAMETER function example 5CH STEREO Both are received as "5CH/7CH/9CH STEREO" , MS5CH STEREO<CR> 7CH STEREO the surround mode which changed return as EVENT. MS7CH STEREO<CR> 9CH STEREO MS9CH STEREO<CR> SUPER STADIUM MSSUPER STADIUM<CR> ROCK ARENA MSROCK ARENA<CR> JAZZ CLUB MSJAZZ CLUB<CR>...
  • Page 13 COMMAND PARAMETER function example TONE DEFEAT ON PARAMETER setting TONE DEFEAT ON/OFF PSTONE DEFEAT ON<CR> TONE DEFEAT OFF PSTONE DEFEAT OFF<CR> TONE DEFEAT ? Request PSTONE DEFEAT Status PSTONE DEFEAT ?<CR> SB:MTRX ON SURROUND BACK SP MODE set PSSB:MTRX ON<CR> SB:NON MTRX ---MTRX ON = SURR.EX ON = DSCRT ON PSSB:NON MTRX<CR>...
  • Page 14 COMMAND PARAMETER function example TUNER Frequency UP/DOWN , direct change TFUP<CR> DOWN TFDOWN<CR> ****** (6 digits) --- ****.** kHz at AM band (>050000 is AM.) TF105000<CR> ****.** MHz at FM band (<050000 is FM.) (1050.00kHz at AM) Request TF Status TF?<CR>...
  • Page 15 COMMAND PARAMETER function example Z2CV Z2FL UP ZONE-2 CHANNEL VOLUME UP/DOWN , Z2CVFL UP<CR> direct change to **dB FL DOWN ---FRONT Lch Z2CVFL DOWN<CR> FL ** **:38 to 62 by ASCII , 50=0dB Z2CVFL 50<CR> FR UP Z2CVFR UP<CR> FR DOWN ---FRONT Rch Z2CVFR DOWN<CR>...
  • Page 16 COMMAND PARAMETER function example PHONO ZONE-2 mode set , and select source Z2PHONO<CR> ---The name of PARAMETER is the same as that of the time of SI COMMAND. Z2AUX<CR> SOURCE ZONE-2 mode cancel Z2SOURCE<CR> ZONE-2 VOLUME UP/DOWN , direct change to ***dB Z2UP<CR>...
  • Page 17 COMMAND PARAMETER function example Z2MS STEREO SURROUND mode set Z2MSSTEREO<CR> DOLBY PRO LOGIC All are received as "STANDARD" , Z2MSDOLBY PROLOGIC<CR> the surround mode which changed return as EVENT. DOLBY PL2 Z2MSDOLBY PL2<CR> DOLBY PL2x Z2MSDOLBY PL2X<CR> DOLBY DIGITAL Z2MSDOLBY DIGITAL<CR> DOLBY D EX Z2MSDOLBY D EX<CR>...
  • Page 18 COMMAND PARAMETER function example Z2PS TONE DEFEAT ON PARAMETER setting TONE DEFEAT ON/OFF Z2PSTONE DEFEAT ON<CR> TONE DEFEAT OFF Z2PSTONE DEFEAT OFF<CR> TONE DEFEAT ? Request Z2PSTONE DEFEAT Status Z2PSTONE DEFEAT ?<CR> SB:MTRX ON SURROUND BACK SP MODE set Z2PSSB:MTRX ON<CR> SB:NON MTRX ---MTRX ON = SURR.EX ON = DSCRT ON Z2PSSB:NON MTRX<CR>...
  • Page 19 COMMAND PARAMETER function example PHONO ZONE-3 mode set , and select source Z3PHONO<CR> ---The name of PARAMETER is CDR/TAPE the same as that of the time of SI COMMAND. Z3CDR/TAPE<CR> SOURCE ZONE-3 mode cancel Z3SOURCE<CR> ZONE-3 VOLUME UP/DOWN , direct change to ***dB Z3UP<CR>...
  • Page 20 Cursol/Enter/Setup/Parameter COMMAND PARAMETER function example “Cursor Up” Control SSCUP<CR> “Cursor Down” Control SSCDN<CR> “Cursor Left” Control SSCLT<CR> “Cursor Right” Control SSCRT<CR> “Enter” Control SSENT<CR> MEN ON “System Setup Menu ON” Control SSMEN ON<CR> MEN OFF “System Setup Menu OFF” Control SSMEN OFF<CR>...
  • Page 21 mServer/iRadio Extended Control COMMAND PARAMETER function example “Cursor Up” Control NS90<CR> “Cursor Down” Control NS91<CR> “Cursor Left” Control NS92<CR> “Cursor Right” Control NS93<CR> “Enter (Play/Pause)” Control NS94<CR> “Stop” Control NS9C<CR> Request Onscreen Display Information List NSA<CR> (ASCII CODE Character ) (Return NSA0-NSA8.
  • Page 22 EVENT(or RESPONSE) and PARAMETER list EVENT PARAMETER function example POWER ON/STANDBY change PWON<CR> STANDBY PWSTANDBY<CR> MASTER VOLUME change , **:00 to 98 by ASCII MV80<CR> 98 = +18dB(MAX) 80 = 0dB 10 = -70dB 00 = -80dB 99 = ---(MIN) FL ** CHANNEL VOLUME change , **:00 to 62 by ASCII CVFL 50<CR>...
  • Page 23 EVENT PARAMETER function example OUTPUT MUTE ON/OFF change MUON<CR> MUOFF<CR> PHONO INPUT source change SIPHONO<CR> SICD<CR> TUNER SITUNER<CR> SIDVD<CR> SIVDP<CR> SITV<CR> SIDBS<CR> VCR-1 SIVCR-1<CR> VCR-2 SIVCR-2<CR> VCR-3 SIVCR-3<CR> VCR-4 SIVCR-4<CR> V.AUX SIV.AUX<CR> CDR/TAPE SICDR/TAPE<CR> SIAUX<CR> VIDEO INPUT source change SVDVD<CR> SVVDP<CR>...
  • Page 24 EVENT PARAMETER function example DIRECT SURROUND mode change MSDIRECT<CR> PURE DIRECT MSPURE DIRECT<CR> STEREO MSSTEREO<CR> MULTI CH IN MSMULTI CH IN<CR> M CH IN+PL2X C MSM CH IN+PL2X C<CR> M CH IN+PL2X M MSM CH IN+PL2X M<CR> MULTI CH IN 7.1 MSMULTI CH IN7.1<CR>...
  • Page 25 EVENT PARAMETER function example DOLBY H/P MSDOLBY H/P<CR> DTS+DOLBY H/P MSDTS+DOLBY H/P<CR> PL2x C+THX MSPL2X C+THX PL2 C+THX MSPL2 C+THX PL+THX MSPL+THX NEO:6 C+THX MSNEO:6 C+THX THX5.1 MSTHX5.1<CR> THX U2 CINEMA MSTHX U2 CINEMA<CR> THX MUSIC MODE MSTHX MUSIC MODE<CR> THX GAMES MODE MSTHX GAMES MODE<CR>...
  • Page 26 26/34...
  • Page 27 EVENT PARAMETER function example USER1 USER mode change MSUSER1<CR> USER2 MSUSER2<CR> USER3 MSUSER3<CR> USER0 ---User 1(or User 2 or User 3) Change User OFF MSUSER0<CR> TONE DEFEAT ON TONE DEFEAT ON/OFF change PSTONE DEFEAT ON<CR> TONE DEFEAT OFF PSTONE DEFEAT OFF<CR> SB:MTRX ON SURROUND BACK MODE change PSSB:MTRX ON<CR>...
  • Page 28 EVENT PARAMETER function example ****** (6 digits) TUNER Frequency change TF105000<CR> --- ****.** kHz at AM band (1050.00kHz at AM) ****.** MHz at FM band **(PRESET No.) TUNER PRESET change to No.** TPA1<CR> (PRESET No.”A1”) TUNER BAND , MODE change ---Band set to AM TMAM<CR>...
  • Page 29 EVENT PARAMETER function example Z2CV FL ** ZONE-2 CHANNEL VOLUME change , Z2CVFL UP<CR> FR ** **:00,38 to 62 by ASCII Z2CVFL DOWN<CR> C ** 62 = +12dB(MAX) Z2CVFL 50<CR> SW ** 50 = 0dB Z2CVFR UP<CR> SL ** 38 = -12dB(MIN) Z2CVFR DOWN<CR>...
  • Page 30 EVENT PARAMETER function example Z2SV V.AUX Z2SVV.AUX<CR> SOURCE ZONE2 VIDEO SELECT mode cancel Z2SVSOURCE<CR> Z2MS STEREO ZONE2 SURROUND mode change Z2MSSTEREO<CR> DOLBY PRO LOGIC MSDOLBY PRO LOGIC<CR> DOLBY PL2 C MSDOLBY PL2 C<CR> DOLBY PL2 M MSDOLBY PL2 M<CR> DOLBY PL2 G MSDOLBY PL2 G<CR>...
  • Page 31 USER3 Z2MSUSER3<CR> EVENT PARAMETER function example Z2PS TONE DEFEAT ON PARAMETER setting Z2PSTONE DEFEAT ON<CR> TONE DEFEAT OFF TONE DEFEAT ON/OFF Z2PSTONE DEFEAT OFF<CR> SB:MTRX ON SURROUND BACK SP MODE set Z2PSSB:MTRX ON<CR> SB:NON MTRX ---MTRX ON = SURR.EX ON = DSCRT ON Z2PSSB:NON MTRX<CR>...
  • Page 32 EVENT PARAMETER function example PHONO ZONE-4 source change Z4PHONO<CR> ---The name of PARAMETER is CDR/TAPE the same as that of the time of SI COMMAND. Z4CDR/TAPE<CR> SOURCE ZONE-4 mode cancel Z4SOURCE<CR> ZONE-4 VOLUME change , **:00 to 99 by ASCII Z480<CR>...
  • Page 33 mServer/iRadio Extended Control EVENT PARAMETER function Onscreen Display Information(mserver/iRadio) is Answered By the NSA Command. Display Line1 Information NSA0**************_?????<CR> Display Line3 Information NSA1 ************_?????<CR> Display Line4 Information NSA2 ************_?????<CR> Display Line5 Information NSA3 ************_?????<CR> Display Line6 Information NSA4 ************_?????<CR> Display Line7 Information NSA5 ************_?????<CR>...
  • Page 34 EVENT PARAMETER function Onscreen Display Information(mserver/iRadio) is Answered By the NSE Command. Display Line1 Information NSE0**************_?????<CR> Display Line3 Information NSE1 ************_?????<CR> Display Line4 Information NSE2 ************_?????<CR> Display Line5 Information NSE3 ************_?????<CR> Display Line6 Information NSE4 ************_?????<CR> Display Line7 Information NSE5 ************_?????<CR> Display Line8 Information NSE6 ************_?????<CR>...
