Item Part No.
1 3027501
2 3046992
3 91131
4 90546
5 3027502
6 3031021
7 90619
8 3032142
Qty Description
1 CHANNEL, Weight Mounting
2 BAR, Clamp
4 BOLT, 3/8-16 x 4" Hex Tap, GR5
4 NUT, 3/8-16 Hex Center Lock, GR5 or B
13 BAR, Weight
3 SCREW, 1/2-13 x 4-1/2" Hex Head Cap
3 NUT, 1/2-13 Hex Flange Lock
2 PAD, Anti-Skid, Self-Adhesive
unit breakdown & parts list
S S n n a a p p p p e e r r Z Z - - V V a a c c W W e e i i g g h h t t M M o o u u n n t t G G r r o o u u p p
21
6
