Snapper FAST-VAC 5600148 Parts Manual page 15

Weight Mount Group
REF NO PART NO.
1 5025018X10
2 5025158
3 5049082A
4 5025098
5 5049143
6 5025210
7 1717627
Footnotes
The above parts group applies to the following Mfg. Nos.:
5600148 (S150X S/N: 2012628763 & Above - 52" Mower Deck)
5600057 (S200X - 61" Mower Deck)
5600002 (S150X - 48" Mower Deck)
5600003 (S150X - 48" Mower Deck)
5600004 (S150X S/N: 2012628762 & Below - 52" Mower Deck)
© Copyright 2007 Briggs and Stratton. All Rights Reserved.
QTY. DESCRIPTION
2 BOLT, 1/2-20 X 1-1/4" GD5 YZ
2 WASHER, 1/2 SAE
1 HOLDER ASMY - WEIGHT
2 NUT, 1/2-20 HEX NYLON LOCK
1 ROD- .500DIA 13.75LG YELLOW
2 PIN, HAIR
3 WEIGHT, 50LBS
15
TP 400-7356-00-AT-SP
