- Page 1 Parts Manual for 38" & 42" Twin Bag Catcher MODEL 1695171 Briggs & Stratton Yard Power Products Group 535 Macon Road Manual No. 7102883 McDonough, GA, 30253 U.S.A. 800-935-2967 Revision IR, 9/2/2008 TP 400-5414-IR-AT-N...
- Page 3 Table Of Contents PAGE GROUP Twin Bag Catcher Assembly 38" & 42" Twin Bag Catcher Manual No. 7102883 TP 400-5414-IR-AT-N...
- Page 4 Twin Bag Catcher Assembly Manual No. 7102883 38" & 42" Twin Bag Catcher TP 400-5414-IR-AT-N...
- Page 5 Twin Bag Catcher Assembly Item Part No Description 1733758 COVER ASSEMBLY, Twin Catcher 1960404 SCREW, Phillips, 10 - 24 x 3/4 720537 HANDLE, Plastic 1933896 NUT, Hex .10 - 24 1675707 CLIP, Tube Grass Bag 1703764 BAG, Grass 1733491 HOOP, Twin 1931333 BOLT, Carriage, 5/16 - 18 x 3/4, G5 1703807A...
- Page 6 Twin Bag Catcher Assembly Manual No. 7102883 38" & 42" Twin Bag Catcher TP 400-5414-IR-AT-N...
- Page 7 Twin Bag Catcher Assembly Item Part No Description 1733948A PLATE, Reinforcement, Upright 1925003 SCREW, Hex Washer Head Taptt 1/4 - 20 x.5 720525 PIN, Cover Hinge 1733504A PIVOT, Hinge 1960074 CLIP, Hair Pin * DECAL, ID Plate 1733903A PLATE, Reinforcement, Frame 1930595 SCREW, Hex Whiz Lock Flange, 5/16 - 18 x 1.25 1732488...
- Page 10 IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS MANUFACTURED Briggs & Stratton Yard Power Products Group 535 Macon Road McDonough, GA, 30253 U.S.A. 800-935-2967 www.snapper.com Copyright © 2008 Briggs & Stratton Corporation Milwaukee, WI USA. All Rights Reserved Manual No. 7102883...
