Operating Instructions

14. Technical Data

Sensor / Sensor Accommodation
Housing:
Protection category:
Operating temperature:
Max. working pressure:
Working frequency:
Transmitting power:
Weight:
Dimension:
Accuracy:
Evaluation Unit
Supply voltage:
Power consumption:
Current consumption:
Protection category:
Operating temperature:
Enclosure dimensions:
Weight:
Additional data:
Cable glands:
Screw terminals:
Current output signal:
Measurement value alarm relay output:
Data storage:
Pulse output:
RS 232 Interface:
RS 485 Interface:
EN 01/2012
Steel St52, galvanised
(stainless steel 1.4541 option)
IP 65, DustEx 20 or GasEx 1 (option)
Front end of sensor: -20 ... + 80 °C [-4 ... 176 °F]
Optional: -20 ... + 200 °C [-4 ... 392 °F]
Sensor electronic: 0 ... + 60 °C [32 ... 140 °F]
1 bar, optional 10 bar
K-Band 24.125 GHz, ± 100 MHz
Max. 5 mW
Approx. 1.3 kg
Ø 60, Ø 20, L 290 mm
+/- 2 ... 5 % in calibrated range
110 / 240 V AC 50/60 Hz (optional 24 V DC)
20 W / 24 VA
Max. 1 A @ 24 V
IP 65 to EN 60 529/10.91
-10 ... +45 °C [14 ... 113 °F]
225 x 237 x 174 (W x H x D)
Approx. 2.5 kg
3 x M16 (4.5 - 10 mm Ø)
0.2 – 2.5 mm² [AWG 24-14]
4 ... 20 mA (0 ... 20 mA), load < 700 W
Relay with switching contact - Max. 250 V AC, 1 A
Flash
Open collector - Max. 30 V, 20 mA
Bus interface
