SNOWTHROWER & HITCH REMOVAL
NOTE: Whenever removed, install clevis pins, hitch pins,
clips and hardware onto snowthrower and hitch for stor-
age.
1. Fully lower the attachment lift.
2. See Figure 25. Disconnect the drive shaft by pulling
back on the locking collar (A)and then pulling the
shaft off.
3. See Figure 26. Disconnect the attachment electrical
connection.
4. See Figure 27. Remove the hardware securing the
remote deflector control, and remove the control.
5. See Figure 23. Detach the snowthrower from the
snowthrower hitch by moving the shot pins (B) into
open position.
6. Lower the snowthrower to the ground and back out.
7. See Figure 15 & 16. Disconnect the drive shaft (A,
Figure 15) from the transmission (B, Figure 16) by
pulling on the locking collar (A). Slide the drive shaft
out from the front of the tractor. The drive shaft may
remain attached to the hitch assembly for storage.
8. See Figure 14. Disconnect hydraulic hoses.
Disconnect hairpins (A) and remove clevis pins (B).
Slide hitch assembly (C) off of the slots on the tractor
(E).
Snowthrower Hitch & Removal
19
