B. SYSTEM SIZING REFERENCE
CELL SIZE
320
540
* Correct sizing of a chlorine generator is subject to the specifications of each body of water, and should be carefully
evaluated for best results. Where heightened chlorine demand exists due to warmer climates, humidity, high bather load,
water features and other environmental factors, the maximum pool size should be reduced by at least 30%.
When modifying any plumbing system, it is important to evaluate the total head loss, and any impact that head loss may have
on the design of an existing plumbing system. The following chart will give specific head loss for the Powerclean Salt Cell. If
you have any questions, please contact our tech support department.
DESIGNED FLOW RATE
20%
40%
60%
80%
100%
6
RESIDENTIAL SIZING CHART
POOL SIZE -
STANDARD
20,000 GAL
40,000 GAL
TABLE 1 - SIZING CHART
GPM
20
40
60
80
100
TABLE 2 - FLOW RATE VS HEAD LOSS
POOL SIZE -
HIGH DEMAND*
14,000 GAL
28,000 GAL
ACTUAL HEAD LOSS
.20 Ft Water
.41 Ft Water
1.54 Ft Water
2.28 Ft Water
3.71 Ft Water
CHLORINE
PER DAY
0.78LB
1.35LB
