TECHNICAL SPECIFICATIONS

POWER SUPPLY
Supply rated values
Vdc with reversible polarities
INPUTS
8 inputs for RTD sensors, Pt100 type with 3 wires (max section 1.5mm²)
Connections on removable terminal strips
Input channels protected against electromagnetic interference
Cable compensation for thermistors
OUTPUTS
2 alarm relays (ALARM AND TRIP) SPDT
1 sensor or operating failure (FAULT) relay SPST
Output relays with 10A-250Vac-res COSФ=1 contacts.
2 ventilation management relays (FAN 1 and FAN 2) SPST
Wi-Fi Connection: protocol 802.11 b/g/n, frequency 2.4 GHz with removable external antenna
DIMENSIONS
100 x 100 mm DIN 43700 depth 150 mm (including antenna - installed at 90° - and terminal
board)
TESTS AND PERFORMANCE
Construction in compliance with CE regulations
Protection from electrical interference EN 61000-4-4
Dielectric strength 1500 Vac for a min. between output relays and sensors, relay and power
supply, power supply and sensors
Accuracy ±1% full scale value, ±1 digit
Ambient operating temperature from –20°C to +60°C
Humidity 90% non-condensing
Frontal film polycarbonate IP65
6
NT538 WS
NT538 WS
85-260 Vac-Vdc
50/60HZ
●
●
●
●
500m (1 mm²)
●
●
●
●
Max 100m
in open field
Hole 92 x 92 mm
●
●
●
●
●
●
●
