Resol DeltaSol SL Manual page 15

System 7: Solar system with east-/west collectors
Sensors
GND R4
1 2 3 4 5 6 7 8
10
2 2 2
S1 S5
R1 R2
Relais
S6
S7
9 R3 R2
11 N
S2
Sensors
S1 Temperature collector
S2 Temperature store
L
base
N
S3 Free
R1 L
S4 Free
S5 Temperature collector
N N N
2
S6 Free
3 3 3
Netz
Mains
The controller compares the temperatures at the collector sensors S1 and S5 to
the store temperature at sensor S2. If one of the measured temperature difference
is higher than the adusted switch-on temperature difference, the corresponding
pump (R1 and / or R2) will be switched on, thus loading the store until either the
switch-off temperature difference or the store maximum temperature is reached.
Hydraulic variant 1
Relay
1 / GND R1 Solar pump collector
2 / GND
R2 Solar pump collector 2
R3 Free
3 / GND
R4 Free
4 / GND
5 / GND
S6
Hydraulic variant 2
R1 / N / PE
R2 / N / PE
R3 / N / PE
R4 / R4
15 15
