Important - Make certain that you are electromagnetically grounded
when performing the following procedures. Static electricity can
damage the appliance.
Figure 3-7
Expansion Line Card
Removing Expansion Line Cards
To remove an expansion line card:
1. Power off the appliance and remove the power cords from the power supply units.
2. Loosen the retaining screws on either side of the expansion line card.
3. Holding the screws, pull the expansion line card out of the slot.
Installing Expansion Line Cards
To install an expansion line card:
1. Power off the appliance and remove the power cords from the power supply units.
2. Insert the expansion line card into the slot.
3. Push until the card clicks into place.
4. Tighten the retaining crews on either side of the expansion line card.

Hard Disk Drive

This sections covers installing or removing a hard disk drive.
Hard disk drives
Power-1 5070 Power-1 9070
1 2 (RAID-1)
Hot swappable
Customer Replaceable Parts
Power-1 11000 Series
2 (RAID-1)
Hot swappable
