Snapper CP215519HV Parts Manual page 7

HANDLES & CONTROLS - Upper End
Item Part No Qty
35 7091585 1
36 7074113 1
37 7075182 1
38 7091167 1
39 7091018 1
40 7090188 3
41 7034162 1
42 7024641 1
43 7076978 1
44 7012080 2
45 7078026 1
45 7074138 1
46 7075308 1
Footnotes:
21" STEEL DECK WALK BEHIND
SERIES 19 & 20
Description
NUT, 3/8-16 Hex Center Lock
LEVER, Shift
KNOB, Shift
SCREW, #8-32 x 1/2" Cross Recess Filister Head Machine
NUT, #8-32 Hex
WASHER, 3/8" Flat
COTTER PIN, 5/16 Self Lock
TIE, Wire, 1.29 long, black
NUT, 1/4-28 Hex Nyloc
CABLE-TIE, 7"
THROTTLE CONTROL, 5.5 HP, Honda (50.81" long)
THROTTLE CONTROL, 6.0 HP Kawasaki (53.25" long)
THROTTLE KNOB
7
Note
used on CP215519HV &
CP215520HV
used on CP216019KWV &
CRP216019KWV
Manual No. 7006155
TP 400-5189-A-WB-N
