COPYRIGHT © 2006
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
21" STEEL DECK COMMERCIAL
WALK BEHIND MOWERS
McDonough, GA, 30253 U.S.A.
Revision 3,
Parts Manual for
SERIES 0, 1 & 2
PUSH MODELS
C21400R2
C21500KWV
C21501KWV
6/13/2006
PROPELLED
MODELS
CP21400R2
CP21401R2
CP21402R2
CP21500KWV
CP21501KWV
CP21550KWV
ECP21400R2
ECP21500KWV
ECP21501KWV
ECP21550V
Manual No.
7006144
TP 400-5199-3-WB-N
Advertisement
Table of Contents
Related Manuals for Snapper C21400R2
Summary of Contents for Snapper C21400R2
-
Page 1: Walk Behind Mowers
COPYRIGHT © 2006 SNAPPER PRODUCTS, INC. ALL RIGHTS RESERVED. 21" STEEL DECK COMMERCIAL WALK BEHIND MOWERS PUSH MODELS McDonough, GA, 30253 U.S.A. Revision 3, 6/13/2006 Parts Manual for SERIES 0, 1 & 2 PROPELLED MODELS C21400R2 CP21400R2 C21500KWV CP21401R2 C21501KWV... -
Page 3: Table Of Contents
PAGE GROUP Handles & Controls Cutting Deck, Blade, Interlock Front Wheel Bracket, Latches Rear Wheel Brackets, Latches Front And Rear Wheels Drive System Self-Propelled Transmission (Differential) Throttle Controls & Engine Specs. Decals Adapter, Brackets Accessory - Grass Bag Recycling Kits Accessory - Snapperizer Accessory - Thatcherizer 21"... -
Page 4: Handles & Controls
Handles & Controls Manual No. 7006144 21" STEEL DECK COMMERCIAL TP 400-5199-3-WB-N SERIES 0, 1 & 2... - Page 5 Handles & Controls Item Part No Description 7046914 HANDLE, Upper 7024890 HANDLE, Middle 7033986 HANDLE, Lower Right Hand 7033985 HANDLE, Lower Left Hand 7024978 CONTROL, Blade 7033904 CLIP, Blade Control 7025036 CABLE, Blade Control 7027774 CABLE, Blade Control 7027393 CABLE, Blade Control 7032826 HANDLE, Wheel Drive 7014307...
- Page 6 Handles & Controls Manual No. 7006144 21" STEEL DECK COMMERCIAL TP 400-5199-3-WB-N SERIES 0, 1 & 2...
- Page 7 Handles & Controls Item Part No Description 7014343 BUSHING 7023792 PIN, Clutch Handle 7091020 NUT, Push (for handle pin) 7023886 DECAL, Wheel Control 7022460 GRIP, Foam 7032833 STRAP, Handle 7090391 WASHER, 5/16 Internal Tooth Lock 7090095 NUT, 1/4-28 Hex 7015753 JOINT, Ball 7024087 DECAL, Speed Selector...
-
Page 8: Cutting Deck, Blade, Interlock
Cutting Deck, Blade, Interlock Manual No. 7006144 21" STEEL DECK COMMERCIAL TP 400-5199-3-WB-N SERIES 0, 1 & 2... - Page 9 Cutting Deck, Blade, Interlock Item Part No Description 7057663 DECK, Mower 7091601 NUT, 5/16-18 Hex Flange Lock 7090731 BOLT, 5/16-18 x 1/2" Short Neck Carriage 7091169 BOLT, 5/16-18 x 1-1/8" Short Neck Carriage 7090324 SCREW, 3/8-18 x 1" Self-Tapping (Engine Mounting) 7032417 SPRING, Wheel Bracket Type Interlock 7026175...
- Page 10 Cutting Deck, Blade, Interlock Manual No. 7006144 21" STEEL DECK COMMERCIAL TP 400-5199-3-WB-N SERIES 0, 1 & 2...
- Page 11 Cutting Deck, Blade, Interlock Item Part No Description 7090187 WASHER, 5/16 Split Lock 7091511 NUT, 5/16-18 Hex 7026471 WIRE, Interlock (Kawasaki) (not shown) Footnotes: 21" STEEL DECK COMMERCIAL SERIES 0, 1 & 2 Note Was 90196 Manual No. 7006144 TP 400-5199-3-WB-N...
-
Page 12: Front Wheel Bracket, Latches
Front Wheel Bracket, Latches Manual No. 7006144 21" STEEL DECK COMMERCIAL TP 400-5199-3-WB-N SERIES 0, 1 & 2... - Page 13 Front Wheel Bracket, Latches Item Part No Description 7051885 ASSEMBLY, Arm, Left Wheel 7051886 ASSEMBLY, Arm, Right Wheel 7015761 BOLT, 5/16-18 x 3/4" Shoulder 7012325 LATCH, Height 7027702 GRIP, Latch 7031016 ARM, Left Wheel 7031017 ARM, Right Wheel 7011791 RETAINER, 5/16 Bolt 7091601 NUT, 5/16-18 Hex Flange 7041666...
-
Page 14: Rear Wheel Brackets, Latches
Rear Wheel Brackets, Latches Manual No. 7006144 21" STEEL DECK COMMERCIAL TP 400-5199-3-WB-N SERIES 0, 1 & 2... - Page 15 Rear Wheel Brackets, Latches Item Part No Description 7046983 BEARING 7091012 SCREW, #10-32 x 3/8" Self-Tapping 7035717 LATCH, Height Adjusting 7091604 BOLT, 1/4-20 x 1/2" Short Neck Carriage (Gr. 5) 7091601 NUT, 5/16-18 Hex Flange Lock 7052909 ASSEMBLY, Wheel Arm (Square Hole, Front Left & Rear Right) 7052908 ASSEMBLY, Wheel Arm (Round Hole, Front Right &...
-
Page 16: Front And Rear Wheels
Front And Rear Wheels Manual No. 7006144 21" STEEL DECK COMMERCIAL TP 400-5199-3-WB-N SERIES 0, 1 & 2... -
Page 17: Front And Rear Wheels
Front And Rear Wheels Item Part No Description 7022801 WHEEL, Rear 9.20 x 2.00 Steel Rim 7022800 WHEEL, Rear 9.20 x 2.00 Steel Rim 7026182 WHEEL, Front 8.00 x 2.00 Steel Rim 7031121 HUB-CAP (Front Wheels) 7031960 HUB CAP (Rear Wheels) 7090377 NUT, 7/16-18 Hex Center Lock 7031961... -
Page 18: Drive System Self-Propelled
Drive System Self-Propelled Manual No. 7006144 21" STEEL DECK COMMERCIAL TP 400-5199-3-WB-N SERIES 0, 1 & 2... - Page 19 Drive System Self-Propelled Item Part No Description 7012354 BELT, Poly-Vee 7034179 LINK, Differential 7051921 ASSEMBLY, Clutch Idler 7032832 ARM, Clutch Idler 7012124 PULLEY, Idler 7091025 SCREW, 1/4-28 x 1-3/8" Hex Head Cap 7090303 NUT, 1/4-28 Hex Lock 7012117 BUSHING, 3/8 I.D. Nylon 7072284 SHAFT, Hex 7019383...
- Page 20 Drive System Self-Propelled Manual No. 7006144 21" STEEL DECK COMMERCIAL TP 400-5199-3-WB-N SERIES 0, 1 & 2...
- Page 21 Drive System Self-Propelled Item Part No Description 7015752 LINK, Transfer 7061275 ASSEMBLY, Drive Disc 7017696 BUSHING 7029025 SPRING (Wheel Drive & Idler) 7032116 ARM, Idler 7013847 RETAINER, 3/8 Bolt 7090947 BOLT, 1/4-20 x 1-1/2" Carriage 7090372 NUT, 1/4-20 Hex Center Lock 7052987 ASSEMBLY, Deck Bracket 7033774...
-
Page 22: Transmission (Differential
Transmission (Differential) Manual No. 7006144 21" STEEL DECK COMMERCIAL TP 400-5199-3-WB-N SERIES 0, 1 & 2... - Page 23 Transmission (Differential) Item Part No Description 7059070 ASSEMBLY, Transmission 7092062 NUT, 5/16-24 Hex Lock 7014263 WASHER, Spring 7019213 PULLEY, Poly-Vee Belt 7011724 WASHER, Spring 7053942 ASSEMBLY, Housing Right 7051908 HOUSING, Right Side 7014155 SCREW, 5/16-24 x 1-1/8" Rib Neck 7012314 SEAL, 5/8 I.D.
-
Page 24: Throttle Controls & Engine Specs
Throttle Controls & Engine Specs. Manual No. 7006144 21" STEEL DECK COMMERCIAL TP 400-5199-3-WB-N SERIES 0, 1 & 2... - Page 25 ENGINE, 4 HP 2-Cycle Robin WT-125V-600009 ENGINE, 4 HP 2-Cycle Robin WT-125V-600005 Footnotes: NOTE: Snapper part number is printed on the throttle control conduit. NOTE: Purchase engine parts from engine manufacturer's dealer. 21" STEEL DECK COMMERCIAL SERIES 0, 1 & 2 Note Manual No.
-
Page 26: Decals
Decals Manual No. 7006144 21" STEEL DECK COMMERCIAL TP 400-5199-3-WB-N SERIES 0, 1 & 2... - Page 27 7023009 DECAL, Noise Control 7023008 DECAL, GS 7017218 DECAL, Spark Plug 7023886 DECAL, Wheel Control 7024204 DECAL, Snapper (3.38 Dia.) 7026878 DECAL, OHV (Overhead Valve) 7026877 DECAL, Kawasaki 7024197 DECAL, 4 HP - 2 Cycle Footnotes: 21" STEEL DECK COMMERCIAL SERIES 0, 1 &...
-
Page 28: Adapter, Brackets
Adapter, Brackets Manual No. 7006144 21" STEEL DECK COMMERCIAL TP 400-5199-3-WB-N SERIES 0, 1 & 2... - Page 29 Adapter, Brackets Item Part No Description 7051951 ASSEMBLY, Bag Adapter & Cover 7016107 ADAPTER, Grass Bag 7019287 COVER, Bag Adapter 7023000 HINGE, Chute Cover 7091604 BOLT, 1/4-20 x 1/2" Short Neck Carriage 7090053 WASHER, 1/4 Internal Tooth Lock 7091576 NUT, 1/4-20 Hex 7032661 STOP, Cover 7023042...
-
Page 30: Accessory - Grass Bag
Accessory - Grass Bag Manual No. 7006144 21" STEEL DECK COMMERCIAL TP 400-5199-3-WB-N SERIES 0, 1 & 2... - Page 31 Accessory - Grass Bag Item Part No Description 7061239 KIT, Grass Catcher 7074426 BAG, Grass (Commercial) 7050711 ASSEMBLY, Slider 7042489 CONNECTOR, Grass Bag 7026313 WIRE, Bag Connector 7016050 ADAPTER, Bag 7024340 SPACER 7024085 NUT, 5/16-18 Wing (Nylon Patch) 7011791 RETAINER, 5/16 Bolt 7091076 WASHER, 5/16 Flat 7090951...
-
Page 32: Recycling Kits
Recycling Kits Manual No. 7006144 21" STEEL DECK COMMERCIAL TP 400-5199-3-WB-N SERIES 0, 1 & 2... -
Page 33: Recycling Kits
Recycling Kits Item Part No Description 7061200 KIT, Recycling Cover (Includes the 2 items below) 7061201 KIT, Recycling Plug (Quad Blade) (Incl. the 2 items below) 7029149 COVER, 21” Deck 7016814 PLUG, Chute Adapter 7026407 BLADE, 21” Quad Edge Ninja Footnotes: 21"... -
Page 34: Accessory - Snapperizer
Accessory - Snapperizer Manual No. 7006144 21" STEEL DECK COMMERCIAL TP 400-5199-3-WB-N SERIES 0, 1 & 2... - Page 35 Accessory - Snapperizer Item Part No Description 7060440 KIT, Snapperizer 7051243 SCREEN, Fastener Assembly 7039759 RING, Bottom 7091297 NUT, 5/16-24 Hex 7090187 WASHER, 5/16 Split Lock 7012587 SPRING Footnotes: 21" STEEL DECK COMMERCIAL SERIES 0, 1 & 2 Note (Includes Items 1 Thru 5) Was 90223 Manual No.
-
Page 36: Accessory - Thatcherizer
Accessory - Thatcherizer Manual No. 7006144 21" STEEL DECK COMMERCIAL TP 400-5199-3-WB-N SERIES 0, 1 & 2... - Page 37 Accessory - Thatcherizer Item Part No Description 7061256 KIT, Thatcherizer (Includes items listed below) 7032891 ** LATCH, Frame Attachment 7026572 BAR, Mount (Right Hand) 7026573 BAR, Mount (Left Hand) 7018499 ROD, Tine 7018700 SUPPORT, Wheel 7019948 TRAY, Tine 7018496 KIT, Tine Thatching Spring 7014100 ** BUSHING, Wheel Adjuster 7018493...
- Page 40 21" STEEL DECK COMMERCIAL WALK BEHIND MOWERS SERIES 0, 1 & 2 IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.
