Handles & Controls - Upper End - Snapper CP215519HV Parts Manual

HANDLES & CONTROLS - Upper End
Item Part No Qty
1 7074411 1
2 7074156 1
3 7074418 1
4 7034872 1
5 7074141 1
5 7029344 1
5 7102235 1
6 7074473 1
7 7075305 1
7 7028407 1
8 7034604 1
9 7012121 1
10 7012122 1
11 7074003 1
12 7074133 1
13 7091305 1
14 7031961 2
15 7028465 2
16 7091190 2
17 7091576 2
18 7023813 3
19 7079577 2
20 7026219 1
21 7090505 2
22 7090053 2
23 7074140 1
24 7091200 4
25 7014343 2
26 7023792 1
27 7091020 1
28 7023810 1
29 7090391 2
30 7100181 1
31 7091069 2
32 7029782 1
33 7028488 1
34 7028568 1
Footnotes:
21" STEEL DECK WALK BEHIND
SERIES 19 & 20
Description
HANDLE, Upper
HANDLE, Middle
BAIL, OPC Control
CLIP, Zone Control
CABLE, Zone Control (56-5/16" Long)
CABLE, Zone Control (49.98" Long)
CABLE, Zone Control (60.3" Long)
HANDLE, Clutch
COVER, Grip, Black 1.125"
GRIP, International Symbol, Black 4.6"
CABLE, Clutch Control (41-1/4" Long)
COVER, Vinyl
SPRING, Clutch- 21S
BRACKET, Shift
ROD, Speed Control (1/4-28 thread)
SCREW, 3/8-16 x 2" Hex Head Cap, GR 5
WASHER, 7/16" Flat
WASHER, Nylon
BOLT, 5/16-18 x 1-1/2" Curved Head
NUT, 1/4-20 Hex
CLIP, Wiring Harness
SCREW, 1/4-20 x 1-1/2" Hex Head Cap GR5
CLAMP, 7/8" Double Cable
SCREW, 1/4-20 x 2" Hex Head Cap, GR 5
WASHER, 1/4" Internal Tooth Lock
CONTROL PANEL (w/o Electrical Switch Hole)
SCREW, 1/4-20 x 1/2" Pan Head Self-Tap (Torx)
BUSHING, .27 x .35 x .4 Flange
PIN, 1/4 x 1-1/2"
PUSH-NUT, 1/4"
FOAM GRIP, 18.75" long
WASHER, 5/16" Internal Tooth Lock
DECAL, Commercial, Control Panel
NUT, 5/16-18 Hex, GR 5
DECAL, OPC Bail (International Symbol)
GUIDE, Rope (1/4-20 thread)
WASHER, Belleville
5
Note
used on CP216019KWV &
CRP216019KWV
used on CP215519HV
used on CP215520HV
used on CP215519HV &
CP215520HV
was 7091100
was 7091023
or 7091511
Manual No. 7006155
TP 400-5189-A-WB-N
