Snapper CP215519HV Parts Manual page 25

GRASS BAG & ACCESSORIES
Item Part No Qty
7058572 1
1 7075766 1
2 7050711 1
3 7042489 1
4 7019247 1
5 7058037 1
6 7047081 1
7 7047082 1
8 7091984 1
9 7012306 1
10 7024228 1
11 7091070 1
12 7072107 3
13 7013860 3
14 7024340 1
15 7100516 2
16 7011791 4
17 7091076 1
18 7090951 1
19 7043327 1
20 7078102 1
21 7078101 1
22 7075306 1
23 7090001 2
24 7016814 1
7060440
7063041
7061200
7061201
7061256
Footnotes:
21" STEEL DECK WALK BEHIND
SERIES 19 & 20
Description
ASSEMBLY, Grass Bag (Slider type)
GRASS BAG, Slider Type (Black w/Gray Letters)
ASSEMBLY, Slider
CONNECTOR, Grass Bag
WIRE, Bag Connector (12" Wide)
ASSY, Grass Bag Adapter (Incl. items 6 thru 13)
ADAPTER, Grass Bag
BRACKET, Rope Pulley
SCREW, 5/16-18 x 1-1/4" Pan Head Machine
BUSHING, Flange (Powdered Metal)
PULLEY, Plastic
NUT, 5/16-18 Hex Flange Lock GR 5
WASHER, 15/32" Flat
RIVET, 3/16 x .344
SPACER, .316 I.D. x .375 O.D. x .310 thick
KNOB, Fluted, 5/16-18 x .633
RETAINER, 5/16" Bolt
WASHER, 5/16" Flat
NUT, 5/16-18 Hex Large Flange Center Lock
BRACE, Bag Adapter, KWV
SCREW, M6 x 1.0 x 30MM Hex Head Cap
SLEEVE, .237/.242 I.D. x .3135/.3185 O.D. x .748
STANDOFF
BOLT, 5/16-18 x 3/4" Short Neck Carriage GR 5
PLUG, Chute Adapter
KIT, Snapperizer (21" Hi-Vac Steel Deck Models) (other
accesseries not shown)
KIT, Snapperizer (21" F & M Outlip Steel Deck Models) (other
accesseries not shown)
KIT, Recycling Cover (other accesseries not shown)
KIT, Recycling Plug (Quad Blade) (other accesseries not shown) for 4HP & above engines
KIT, Thatcherizer (other accesseries not shown)
25
Note
Includes items 1 through 4
CP215519HV, CP215520HV &
CP216019KWV
used on CP215519HV &
CP215520HV
or 7091508
for 4HP & above engines
Manual No. 7006155
TP 400-5189-A-WB-N
