- Page 1 Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com DC SERVO DRIVE SERIES LD DC Servo Control Installation & Operating Manual 7/98 MN1269...
-
Page 2: Table Of Contents
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Table of Contents Section 1 General Information ................Year 2000 Compliance . - Page 3 Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Section 4 Troubleshooting and Maintenance ..............Overview .
-
Page 4: General Information
Limited Warranty For a period of two (2) years from the date of original purchase, BALDOR will repair or replace without charge controls and accessories which our examination proves to be defective in material or workmanship. This... -
Page 5: Safety Notice
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Safety Notice This equipment contains high voltages. Electrical shock can cause serious or fatal injury. Only qualified personnel should attempt the start–up procedure or troubleshoot this equipment. - Page 6 Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Section 1 General Information Caution: To prevent equipment damage, be certain that the electrical service is not capable of delivering more than the maximum line short circuit current amperes listed for the control rating.
-
Page 7: Introduction
Introduction The Baldor “LD” Series Servo Control (see Figure 1-1) is a multi axis pulse width modulated (PWM), high performance servo control designed to be used with DC brush type permanent magnet servomotors. This transistorized servo control is a key component in motion control applications, providing not only converted DC power to the motor, but also precisely controlling current and velocity at the motor. -
Page 8: Features
(973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Features The Baldor “LD” Series switching concept enables the user to operate with the highest possible bandwidth with reduced switching losses, ripple current, EMI and RFI. Servo Control cards are field replaceable. -
Page 9: Model Information
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Model Information Model descriptors that describe key parameters of each unit specify the “LD” Series Servo Control and Chassis. -
Page 10: Functional Description
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Functional Description The “LD” Servo Control consists of (1) a power supply, (2) a velocity control amplifier and (3) fault logic circuitry. -
Page 11: Specifications
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Specifications Standard Chassis & Power Supply Assemblies Output: LD2- LD4- Rated Bus Voltage (VDC) Rated Continuous Current (A) Positive Logic 15VDC (A) Negative Logic 15VDC (A) -
Page 12: Servo Control Card
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Servo Control Card Output LD3015HS Rated Bus Voltage (VDC nominal) Rated Continuous Current (A) Current Limit Adjust (A) 5-15 Peak Current Adjust (A) (maximum time 1.5 seconds) -
Page 13: Chassis Assembly
General Description A typical Baldor “LD” Servo Control like that shown in Figure 1-3 can contain from 1 to 4 servo control cards and a chassis assembly. The chassis assembly includes a Logic Power Supply, Bus Power Supply, Overvoltage Protector, Fans and miscellaneous hardware. -
Page 14: Adjustments
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Adjustments Each servo control card contains six (6) potentiometers located on the top left side of the unit. - Page 15 Motor compensation values are also on this module, allowing custom compensation on specialty motors. These components are already appropriate for Baldor DC servomotors. For a description of the current settings, see Appendix B.) Set Up Testpoints Six testpoints have been added to help with set up and the replacement of a card.
- Page 16 Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Fault Indicators Each servo control card contains four (4) red fault indicators located on the top left side of the unit (for location see Figure 1-4).
-
Page 17: Tools
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Tools There are a few basic tools recommended to install the “LD” Servo Control. Recommended Tools Description and Use Slotted screw driver, medium size... -
Page 18: Installation
Installation Receiving & Inspection Baldor Controls are thoroughly tested at the factory and carefully packaged for shipment. When you receive your control, there are several things you should do immediately. Observe the condition of the shipping container and report any damage immediately to the commercial carrier that delivered your control. - Page 19 Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Figure 2-1 Installing the Module Mount the Chassis Remove the shipping base by taking off the four nuts and bolts at the corners of the chassis.
-
Page 20: General Wiring Considerations
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com General Wiring Considerations Care should be taken to see that all interconnecting wiring is sized and installed in conformance with the National Electrical Code (NEC) or Canadian Electrical Code (CEC) and other applicable local codes. -
Page 21: Signal Wiring
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Signal Wiring All signal wiring and limit circuit wiring need not be larger than 22 AWG gauge. Signal circuits, including the tachometer, should employ twisted, shielded pairs. -
Page 22: Signal Wiring
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Power Wiring Continued Connect the negative lead (black wire) from the first servomotor to terminal 1 on the 12 position terminal block (see Figure 2-2). -
Page 23: Input Wiring Connections
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Input Wiring Connections Left Limit, Right Limit (Pins 8 & 9 for Normally Open, 17 & 18 for Normally Closed) When the Left or Right limit is pulled to common (for normally open switches), output is inhibited in that direction. - Page 24 Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Figure 2-5 Optional Input Signal Wiring Interlock (Pin 10) The interlock is bidirectional. That is, it can be pulled to common internally to disable the output stage of the control or externally to accomplish the same disabling function (see Figure 2–5).
- Page 25 Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com 2-8 Installation MN1269...
-
Page 26: Startup
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Section 3 Start-up Overview The start-up information provided in this section contains the procedures necessary to get each axis running and properly tuned using the 6 adjustment potentiometers on the servo control. -
Page 27: Adjustment Procedure
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Adjustment Procedure Caution: The X–Axis motor may tend to run away, out of control, if the tach wires are reversed. -
Page 28: Troubleshooting And Maintenance
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Section 4 Troubleshooting and Maintenance Overview This troubleshooting section describes the symptoms of possible malfunctions along with information needed to check and correct the causes of a fault. - Page 29 Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Fault Symptom Corrective Action No torque in one direction. Check left or right limit switch wires to ensure that they are not tied to common.
-
Page 30: Servo Control Card Replacement
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com WARNING: Do not touch any circuit board, power device or electrical connection before you first ensure that power has been disconnected and there is no high voltage present from this equipment or other equipment to which it is connected. - Page 31 Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com 4-4 Troubleshooting and Maintenance MN1269...
-
Page 32: Special Functions
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Section 5 Special Functions Current (Torque) Mode The “LD” can be configured for current mode operation by moving jumper P6 to its right position (pins 1 to 2). -
Page 33: Emergency Stop
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Emergency Stop In some applications, a requirement may exist to positively disconnect a motor in the event of an emergency (E) stop. -
Page 34: Condensed Installation Instructions
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Appendix A Condensed Installation Instructions Step 1 Become familiar with the equipment. You should have: Servo Control Cards of the type and quantity you have ordered, mounted to the chassis. - Page 35 Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Figure A-1 Series “LD” Installation Drawing 115VAC 1 phase input bus power for LD-2. 115VAC 3 phase input bus power for LD-4.
-
Page 36: Jumper And Personality Module Settings
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Appendix B Jumper and Personality Module Settings Personality Module Current Settings Refer to Figure B-1. The personality module allows you to calibrate the servo control. -
Page 37: Record Of "Set Up" Configuration
Servo Systems Co. • 115 Main Road • P.O. Box 97 • Montville, NJ, 07045-0097 (973) 335-1007 • Toll Free: (800) 922-1103 • Fax: (973) 335-1661 www.servosystems.com Record of “Set Up” Configuration It is highly recommended that a record be kept of the set up details for future reference. This will come in quite handy for new units, field replacements, and diagnostic aid.
