Corner Roller - Snapper COMMERCIAL WALK-BEHIND Parts Manual

4
3
2
1
3
8
ITEM PART NO.
-- 6-1300
1 1-6829
2 2-7209
3 9-0517
4 2-7208
5 9-0563
6 9-0118
7 3-3080
8 7-6979*
*NOTE: Only two of these nuts are needed on the 48" Deck. The 48" Deck is equipped with
MANUAL No. 06929

CORNER ROLLER

5
6
3
5
DESCRIPTION
KIT, Corner Roller (Incl. items 1 thru 8)
ROLLER, Corner
SPACER, Roller
WASHER, 3/8" Flat (3)
BOLT, 3/8-16 x 5-1/2" Hex Head Cap
SCREW, 3/8-16 x 1" Hex Head Cap, Grade 5 (2)
WASHER, 3/8" Split Lock
BRACKET, Roller
NUT, 3/8-16 Hex Nyloc (3)
weld-nuts as illustrated above.
NOTE: Kit 6-1300 will fit models PRO 736 & PRO 748
NOTE: THE WELDNUTS SHOWN
HERE ARE USED ON THE
48" DECK ONLY.
7
8
COMMERCIAL WALK-BEHIND ACCESSORIES
8
36" & 48"
CUTTING DECKS
