Snapper LT145H33GBV Parts Manual

Lawn tractors manual clutch hydro drive series “g”
Hide thumbs Also See for LT145H33GBV:
Table of Contents

Advertisement

Quick Links

IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE AND
PRACTICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS
AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS
MANUFACTURED PREVIOUSLY.
COPYRIGHT © 2002
SNAPPER INC.
ALL RIGHTS RESERVED
Parts Manual for
LAWN TRACTORS
MANUAL CLUTCH
(Rev. 3, 01/27/04)
HYDRO DRIVE
SERIES "G"
MODELS
LT145H33GBV
LT145H38GBV
WLT145H38GBV
LT150H38GKV
ELT145H33GBV
MANUAL No. 06448

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LT145H33GBV and is the answer not in the manual?

Questions and answers

Related Manuals for Snapper LT145H33GBV

Summary of Contents for Snapper LT145H33GBV

  • Page 1 LT150H38GKV ELT145H33GBV IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.

  • Page 2: Table Of Contents

    CONTENTS GROUP PAGE WHEELS, FRONT AND REAR ......................3 HOOD, BUMPER, HEADLIGHTS & COMPONENTS..............4 & 5 STEERING WHEEL, CONSOLE, FUEL TANK ................6 & 7 SEAT, REAR FENDER & COMPONENTS ..................8 & 9 CAST FRONT AXLE ....................... 10 & 11 TRANSMISSION GROUP (Hydro Drive) ................12 & 13 FRAME, CLUTCH, BRAKE &...

  • Page 3: Wheels, Front And Rear

    ITEM PART NO. DESCRIPTION 5-8515 ASSEMBLY, Front Tire & Rim (Includes items 2, 3, 4, 5 & 6) (Models: LT145H33GBV & ELT145H33GBV) 5-8517 ASSEMBLY, Front Tire & Rim (Includes items 2A, 3, 4, 5 & 6) (Model: LT145H38GBV & LT150H38GBV) 7-2702 TIRE, 13 x 5.00...

  • Page 4: Hood, Bumper, Headlights & Components

    HOOD, BUMPER, HEADLIGHTS & COMPONENTS NOTE: TO ORDER HOOD ASSEMBLY FOR MODELS LT145H33GBV AND LT145H38GBV USE ASSEMBLY No. 5-2921. NOTE: TO ORDER HOOD ASSEMBLY FOR MODEL ELT145H33GBV USE ASSEMBLY No. 5-3528. MANUAL No. 06448...

  • Page 5: Hood, Bumper, Headlights & Components

    DECAL, Reflect (Left Hand) (Model ELT145H33GBV) 2-6179 DECAL, Reflect (Right Hand) (Model ELT145H33GBV) 2-2968 DECAL - SNAPPER, 4” Molded Logo (Silver Letters - Blue Stripe) 9-0858 SCREW, 5/16-18 x 1/2” Self-Tapping, Grade 5 (4) 2-4061 BOLT, Shoulder, 3/8-16 x 1-1/4” Hex Socket, Torx (2)

  • Page 6: Steering Wheel, Console, Fuel Tank

    STEERING WHEEL, CONSOLE, FUEL TANK ASSEMBLY MANUAL No. 06448...

  • Page 7: Steering Wheel, Console, Fuel Tank

    STEERING WHEEL, CONSOLE, FUEL TANK ITEM PART NO. DESCRIPTION 5-3746 ASSEMBLY, Console (Includes items 2 thru 7) 2-8565 CONSOLE 1-1791 RETAINER (4) 9-1495 SCREW, 1/4-20 x 3/4” Hex Head Cap, Grade 5 (2) 5-2891 ASSEMBLY, Strap-Clinch Stud (2) 7-6978 NUT, 1/4-20 Hex Nyloc (2) 2-6196 ASSEMBLY, Flange Bearing 9-1575...

  • Page 8: Seat, Rear Fender & Components

    SEAT, REAR FENDER & COMPONENTS ASSEMBLY MANUAL No. 06448...
  • Page 9 SCREW, 1/4-20 x 5/8” Hex Washer Head, Self-Tapping (4) 7-3346 PAN, Seat (Fender) 9-1761 RIV-NUT, 5/16-18 Round (2) 2-2971 DECAL - SNAPPER, 7.28” Molded Logo, Silver Letters & Blue Stripe 2-6415 DECAL - CAUTION, Battery Location 7-3344 SUPPORT, Fender 9-1523 SCREW, 5/16-18 x 5/8”...

  • Page 10: Cast Front Axle

    CAST FRONT AXLE MANUAL No. 06448...

  • Page 11: Bearing,

    CAST FRONT AXLE ITEM PART NO. DESCRIPTION 1-0746 RING, 5/8 External Retaining 1-0935 WASHER, 49/64 x 1-1/8 x 1/16” Flat (3) 1-4669 FITTING, 3/16 Lube (3) 1-9034 ARM, Steering 7-2411 AXLE, Cast 2-8666 SPACER, 25/64 x 1/2 x 1-13/16” (2) 2-8689 SPACER, Center 3-1036...

  • Page 12: Transmission Group (Hydro Drive)

    TRANSMISSION GROUP (Hydro Drive) MANUAL No. 06448...

  • Page 13: Transmission Group (Hydro Drive)

    TRANSMISSION GROUP (Hydro Drive) ITEM PART NO. DESCRIPTION 7-3684 ASSEMBLY, Transaxle, Tuff Torq 7-2387 ROD, Roll Release (K46) 9-1708 PIN, Clevis 1/4” x 5/8” 9-0055 WASHER, 1/4 x 5/8 x 1/16” Flat (2) 9-0555 PIN, 3/32” x 1/2” Cotter 7-2601 BRACKET, Torque 9-1497 SCREW, 3/8-16 x 1-1/2”...

  • Page 14: Frame, Clutch, Brake & Steering Components

    FRAME, CLUTCH, BRAKE & STEERING COMPONENTS 55 56 SEE PAGE 31 FOR RELATED PARTS 42 41 MANUAL No. 06448...
  • Page 15 FRAME, CLUTCH, BRAKE & STEERING COMPONENTS ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 7-3345 FRAME, Tractor (1 piece) 9-0619 NUT, 1/2-13 Hex Flange Lock 1-4451 TIE, Wire 1-5992 WASHER, 5/8” Flat (2) 2-7936 ROD END (2) 2-3645 PIN, 3/16 x 1-1/2” Clevis 9-0482 NUT, 3/8-24 Hex Jam (2) 2-2742...

  • Page 16: Blade Engagement & Transmission Controls

    BLADE ENGAGEMENT & TRANSMISSION CONTROLS Ref: page 14, item 62 MANUAL No. 06448...

  • Page 17: Blade Engagement & Transmission Controls

    BLADE ENGAGEMENT & TRANSMISSION CONTROLS ITEM PART NO. DESCRIPTION 7-3345 FRAME, Tractor (1 Piece) 2-4616 BUSHING, Flange (2) 3-3488 BRACKET, Hood Pivot 2-8630 CLIP, Wire 9-1598 PIN, 1/8 x 3/4” Cotter 1-4296 WASHER, 1/2 Shim 9-1573 BOLT, 1/4-20 x 5/8” Short Neck Carriage, Grade 5 5-2562 ASSEMBLY, Steering Adjuster 9-1584...

  • Page 18: Belt Guide Assembly

    BELT GUIDE ASSEMBLY ITEM PART NO. DESCRIPTION 3-5963 BRACKET, Belt Guide 9-1575 NUT, 5/16-18 Hex Center Lock, Grade B or 5 (4) 2-8303 STUD, Belt Guide (2 or 4) 3-5528 STUD, Belt Guide 38” Dual Brake Deck (2) 7-2924 STUD, Belt Guide 2-8304 STUD, Belt Guide 33”...

  • Page 19: Electrical Components

    ELECTRICAL COMPONENTS ITEM PART NO. DESCRIPTION 6-0618 KIT, Battery (Includes Caution Tag, Part No. 1-6134 & Battery without Acid) 9-0372 NUT, 1/4-20 Hex Center Lock, Grade B or 5 (2) 1-7853 TRAY, Battery 1-2485 RETAINER, 1/4“ Bolt 2-6414 CABLE, Ground (Black) 7-5622 SOLENOID (Was 18604) 9-0539...

  • Page 20: 33" Cutting Deck, Belts, Brakes

    33” CUTTING DECK, BELTS, BRAKES SILHOUETTE OF SECTOR LIFT PLATE SILHOUETTE OF SECTOR LIFT PLATE MANUAL No. 06448...
  • Page 21 33” CUTTING DECK, BELTS, BRAKES ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 5-3690* ASSEMBLY, Deck 33” Cutting 9-0584 BOLT, 1/4-20 x 1/2” Flange Lock. Gr. 5 (Includes items 46A & 81) 9-0850 BOLT, 3/8-16 x 3/4” Carriage, Gr. 5 5-3693** ASSEMBLY Deck, 33”...
  • Page 22 38” CUTTING DECK ASSEMBLY (page 1 of 4) MANUAL No. 06448...
  • Page 23 38” CUTTING DECK ASSEMBLY (page 2 of 4) ITEM PART NO. DESCRIPTION 6-1960 DECK, 38” (painted shell w/decals 1-4852, 1-6973 & 2-6154) 2-8365 BRACKET, Front Linkage (2) 3-3756 BRACKET, LH Front Gage Wheel 3-3891 BRACKET, LH Rear Wheel 3-4875 ANGLE, Front 3-5494 BRACKET, RH Front Gage Wheel 3-5505...
  • Page 24 38” CUTTING DECK ASSEMBLY (page 3 of 4) MANUAL No. 06448...

  • Page 25: 38" Cutting Deck, Belts, Brakes

    38” CUTTING DECK ASSEMBLY (page 4 of 4) ITEM PART NO. DESCRIPTION 1-3847 RETAINER, 3/8” Bolt 1-8574 IDLER, 4-1/8” Flat 2-4604 BOLT, 3/4” Dia. X 3.01 Shoulder; 1/2-13 Thread 2-4607 SWIVEL, Brake Link 2-6122 WHEEL, Gage 38” Deck (3) 2-6831 DECAL, CPSC Cut Finger 2-7168 SCREW, 5/16-18 x 1”...

  • Page 26: Spindle (30" & 33" Decks)

    SPINDLE - 33” CUTTING DECK ITEM PART NO. DESCRIPTION 5-2917 ASSEMBLY, Spindle Housing, 33” Cutting Deck (Includes Items 2 thru 11) 1-2491 RING, Retaining (2) 1-3313 BEARING, Spindle (2) 5-2294 HOUSING, Spindle (Includes item 5) 1-0817 FITTING, Lube 9-0491 SCREW, 1/2-20 x 1-1/4” Hex Head Cap, Grade 5 (2) 9-1939 NUT, 1/2-20 Hex Jam (2) 9-0356...

  • Page 27: Spindle (38" Decks)

    SPINDLE - 38” CUTTING DECK ITEM PART NO. DESCRIPTION 5-8357 ASSEMBLY, Spindle Housing, 38” Cutting Deck (Includes items 2 thru 9) 1-0817 FITTING, Lube 1-2491 RING, Retaining (2) 1-3313 BEARING, Spindle (2) 5-8356 HOUSING, Spindle 7-2537 SHAFT, Spindle (7.181” overall length) 7-2109 WASHER, Spindle 2-4467...

  • Page 28: Engine Components

    ENGINE COMPONENTS ENGINE FOOT ENGINE FOOT OUTLINE OF FRAME (Front) NOTE: Decal mounts to outside of breather cover. MANUAL No. 06448...
  • Page 29 ENGINE, B & S 14.5HP, Model 287707, Type 1250, Trim E1 ENGINE, B & S 15.0HP, Model CV15S, Type PS-41603 9-0391 WASHER, 5/16 Internal Tooth Lock 7-2905 ASSEMBLY, Engine Pulley (LT145H33GBV & ELT145H33GBV) 7-2904 ASSEMBLY, Engine Pulley (LT145H38GBV & LT150H38GBV) 9-1301 WASHER, 7/16 Split Lock 9-1579 BOLT, 1/4-20 x 1/2”...

  • Page 30: Electrical (Wiring Schematic)

    ELECTRICAL – BRIGGS & STRATTON ENGINES WIRING HARNESS 2-6616 MANUAL No. 06448...

  • Page 31: Implement Lift Parts

    IMPLEMENT LIFT PARTS ITEM PART NO. DESCRIPTION 4-1655 LEVER, Implement Lift (33” Decks) 4-1015 LEVER, Implement Lift (38” Decks) 2-2565 ROD, Lift Lever 1-9363 KNOB, Lift Lever 1-4361 CAP, Lift Lever Rod 3-3449 QUADRANT, Lift Lever 9-1001 SCREW, 5/16-18 x 5/8” Truss Head (Torx) 9-1000 SCREW, 5/16-18 x 7/8”...

  • Page 32: Decals

    DECALS MANUAL No. 06448...

  • Page 33: Decals

    DECALS ITEM PART NO. DESCRIPTION 2-6154 DECAL, 38 Inch 2-2991 DECAL, 33 Inch Hi-Vac 1-6973 DECAL, Caution, Rotating Blades 1-4852 DECAL, Caution, Rotating Blades 2-6415 DECAL, Caution, Battery Location 2-9784 DECAL, Deck/Chute International Warning 1-3010 DECAL, Danger, Cut-Finger (shown) 2-6831 DECAL, Danger, Cut-Finger (Heavy Adhesive Version, 2-2841...

  • Page 34: Hydro Reservoir Assembly

    HYDRO RESERVOIR ASSEMBLY ITEM PART NO. DESCRIPTION 7-2739 BRACKET, Reservoir Mounting 7-2736 RESERVOIR, Expansion 1-6130 CLAMP, 13/16” (2) 7-2901 HOSE, Hydraulic 4-1/2” Long 9-1431 VALVE, Vent 9-0858 BOLT, 5/16-18 x 1/2” Hex Washer Self-Tap (2) 7-2914 CABLE TIE, 9” MANUAL No. 06448...
  • Page 35 NOTES...

  • Page 36: Manual No

    Parts Manual for LAWN TRACTORS MANUAL CLUTCH HYDRO DRIVE SERIES “G” COPYRIGHT © 2002 SNAPPER INC. ALL RIGHTS RESERVED MANUAL No. 06448 (Rev. 3, 01/27/04) Printed in U.S.A.
