SAMBA 75 USER'S GUIDE
The SAMBA 75 is not already plugged into the USB interface of your PC, plug
it.
Figure 7: Connect USB connector of SAMBA 75 to the USB serial port of PC. (Note that, the
The PC detects automatically the connected hardware device. Just click
the "Next>" button on the displayed dialog box.
Select on the opened wizard window the "Search for a suitable driver for
my device" radio button, and click Next.
On the next appeared screen select the Specific location check box, and
then click the Next button.
Use Browse button to select the path ('X:\SAMBA 75\driver\usb_modem\
usbmodem.inf' X means CD-ROM drive, in installation example is "F").
Select the "Driver" folder and click the Open button. You will be back to
the follow dialog box, and then click OK.
The selected manufacturer's installation driver is being installed. When the
button Next > is enabled click on it.
In the next window click the Finish button, the modem driver for the SAMBA
75 device is now installed.
The SAMBA 75 status LED labelled "ERR" will be turned off.
Close all opened windows.
Click Start button, point to Settings, then click Control Panel.
Double-click the System icon.
Select the Hardware register and click on the Device Manager button,
open the item Modems and select the USB Falcom Samba MC75
(Remember the allocated COM Port), click to the properties button by
using the right-mouse click.
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
SAMBA-USB-Kit is not a part of modem SAMBA 75).
