  • Page 1 VISION100 Use and maintenance manual ENGLISH READ AND KEEP REV. 02-18 ELECTRICAL BOARDS FOR REFRIGERATING INSTALLATIONS...
  • Page 2 VISION100 THR...

  • Page 3: Table Of Contents

    Page 6 Main warnings for the installer Page 6 Standard equipment for assembly and use Page 7 Board installation Page 8 Functions managed by VISION100 THR TECHNICAL FEATURES CHAP. 3 Page 9 Technical features WARRANTY CONDITIONS CHAP. 4 Page 10...

  • Page 4: Generality

    The system is composed of the 100N MASTER THR unit on which all electric connections are carried out and of the VISION100 THR control console equipped with LCD display for quick and complete information on the cell state. In its whole, it enables controlling cold, hot, ventilation, cell light, humidification, air change, refreshments, dehumidification, defrosting, alarms.

  • Page 5: Page

    CHAP. 1 - Introduction VISION100 THR PRODUCT IDENTIFICATION CODES 200VIS100THR Temperature and humidity control for seasoning, preservation and industrial processes. Complete with VISION THR and 100N MASTER THR display. OVERALL CLEARANCES Dimensions in mm: VISION THR 100N MASTER THR IDENTIFICATION DATA...

  • Page 6: Main Warnings For The Installer

    CHAP. 2 - Installation VISION100 THR CHAPTER 2: INSTALLATION MAIN WARNINGS FOR THE INSTALLER 1. Install the equipment in places complying with the protection degree and keep the box as intact as possible when making holes to house the cable glands and/or conduit glands;...

  • Page 7: Page

    CHAP. 2 - Installation VISION100 THR INSTALLATION Fig. 1: Position the module 100N MASTER on the DIN guide and close the 2 lower hooks to lock it on the same. Fig. 2: Fix the VISION THR console using the two screws to be inserted in the slots underneath the keys frame.

  • Page 8: Functions Managed By Vision100 Thr

    CHAP. 2 - Installation VISION100 THR FUNCTIONS MANAGED BY VISION 100 THR • Temperature set and humidity set (neutral area) parameters adjustment and displaying. • Stand-by state activation/deactivation. • Probes alarms signal. • Air change control parameters adjustment. • Defrosting parameters adjustment.

  • Page 9: Technical Features

    (Relay 16A AC1) 16A 250V (AC1) (see connections layout) Dimensional features 100N MASTER Dimensions 121.50mm x 71mm x 175mm (HxDxL) VISION100 THR Dimensions (fitted) 70mm x 32mm x 158mm (HxDxL) Mechanical and insulation features Display protection degree IP65 Box material Self-extinguishing ABS USE AND MAINTENANCE MANUAL Rev.

  • Page 10: Warranty Conditions

    The intervention service in warranty can be refused when the equipment is modified or transformed. Under no circumstances Pego S.r.l. will be liable for any loss of data and information, costs of goods or substitute services, damage to property, people or animals, loss of sales...

  • Page 11: Control Panel

    CHAP. 5 - Data programming VISION100 THR CHAPTER 5: DATA PROGRAMMING CONTROL PANEL       State LED FRONT KEYBOARD PROGRAM START/STOP (press for 5 seconds to select the program to be  performed, press for 5 seconds to end a program in progress)

  • Page 12: Led Display

    CHAP. 5 - Data programming VISION100 THR  DOWN / MUTE ALARM / AIR CHANGE FORCING  CELL LIGHT LED DISPLAY PHASE 0 Advance/Dripping/Germination day phase PHASE 1 advancement PHASE 2 advancement PHASE 3 advancement PHASE 4 advancement / Night PHASE germination...
  • Page 13 CHAP. 5 - Data programming VISION100 THR PHASE 5 advancement Refreshment Parameters/ambient temperature value Ambient relative humidity value/parameters value/error codes Time/date/time parameters values/program in progress/timer Programming (control is in programming phase) Cold (flashing if only called for dehumidification) Hot (flashing if only called for dehumidification)

  • Page 14: Setpoint Setting And Displaying

    Alarm Stand-by GENERALITY For operator safety and practicality, the VISION100 THR system envisions two programming levels; the first for configuration of the, frequently amendable, SETPOINT parameters only, the second for programming and setting of the main parameters relating to the various board functioning modes. It is not possible to directly access the second level from first level programming, exit current programming first.

  • Page 15: First Level Programming

    CHAP. 5 - Data programming VISION100 THR FIRST LEVEL PROGRAMMING (User level) To access the first level configuration: 1. Keep the keys () and () pressed simultaneously for a few seconds until the first programming variable appears on the display.
  • Page 16 CHAP. 5 - Data programming VISION100 THR Fans pause after defrosting (minutes) Enables keeping the fans still for an F5 time after dripping. This time starts from the end of dripping. If dripping is not 0 ÷ 10 min 0 min set, the fans pause at the end of defrosting.

  • Page 17: Second Level Programming

    CHAP. 5 - Data programming VISION100 THR SECOND LEVEL PROGRAMMING (Installer level) To access second level programming, keep the UP (), DOWN () and LIGHT keys pressed for a few seconds. When the first programming variable appears, the system automatically switches to stand- 1.
  • Page 18 CHAP. 5 - Data programming VISION100 THR Evaporator fans activation duration for air recirculation. 0-240 sec 0:00:10 Functioning time of fans for F6 Fans speed during 0 = High speed seasoning/preservation The value of this variable is amended based on the setting...
  • Page 19 CHAP. 5 - Data programming VISION100 THR Differential of temperature referred to Setpoint for COLD LOCK. 0 ÷ 20 °C It constitutes the SET-btF limit below which the cold call relay (3-4) and the 0 = Disabled Dehumidification relay (25-26) are disabled.

  • Page 20: Automatic Programmes Pr1, Pr2, Pr3, Pr4, Pr5

    CHAP. 5 - Data programming VISION100 THR 0 = Total lock. It is possible to only see the temperature and humidity setpoint. 1 = Locks access in 1st and 2nd level programmes. Locks access in Password:type of protection. germination cycle (Active when PA is different from 0).
  • Page 21 CHAP. 5 - Data programming VISION100 THR VARIABLES MEANING VALUES DEFAULT CIC=0 at the end of the last program phase (phase 5) it switches to manual. 0 = it ends the program and CIC=1 at the end of the last timed phase switches to manual.

  • Page 22: Germination Day/Night Cycle

    CHAP. 5 - Data programming VISION100 THR 0 = High speed Phase 3 evaporator fans speed. Amends 1 = Low speed the value of 2nd level variable (F8) (only if rin=1) 0:00...99:30 Phase 3 duration 0:00 (at 30 min steps) Phase 4 temperature setpoint -45,0 ÷...

  • Page 23: Electronic Controller Vision100 Thr Ignition

    Temperature 2 SET. -45,0 ÷ +45,0 °C 0,0°C ELECTRONIC CONTROLLER VISION100 THR IGNITION 5.13 After having wired the electronic controller, apply voltage 230Vac; the control will immediately and simultaneously emit a sound for a few seconds and remain fully switched- on on the display.

  • Page 24: Humidity/Dehumidification: Ambient Humidity Maintenance

    CHAP. 5 - Data programming VISION100 THR Parameter C1 introduces a delay between a switch-off and the subsequent re-activation of the cold. Hot can be deactivated with parameter EnH (EnH=0 disables the hot relay in all conditions). HUMIDITY/DEHUMIDIFICATION: AMBIENT HUMIDITY MAINTENANCE 5.15...

  • Page 25: Air Change

    CHAP. 5 - Data programming VISION100 THR 2. Dehumidifies with the hot (the hot is called to dehumidify, the cold is added only to maintain ambient temperature). 3. Separate dehumidification (only the dehumidification output activates but hot and cold are not called).

  • Page 26: Refreshment Or Pause

    CHAP. 5 - Data programming VISION100 THR REFRESHMENT OR PAUSE 5.18 The refreshment is a phase of the pause process of the temperature and humidity management. Refreshments are managed with parameters Pr and dr. Pr defines the interval between one refreshment and the subsequent one, dr defines refreshment duration.

  • Page 27: Password Function

    CHAP. 5 - Data programming VISION100 THR PASSWORD FUNCTION 5.21 The password function activates by setting a value for parameter PA different from 0. See parameter P1 for the different protection levels. Protection is enabled automatically after approx. 2 minutes of keyboard inactivity.
  • Page 28 CHAP. 5 - Data programming VISION100 THR • Temperature setpoint. • Humidity setpoint. • Refreshments enabling/disabling. • High or low fans speed. • Phase duration (maximum 99 hours with 30 min steps). For the dripping phase it is possible to exclude the humidity and the cold management.

  • Page 29: Day/Night Cycle For Germination Lights

    CHAP. 5 - Data programming VISION100 THR DAY/NIGHT CYCLE FOR GERMINATION LIGHTS 5.23 By setting parameter Cg (Germination/seasoning cycle) at second programming level, it is possible to choose use of the programmes or a special program suitable for day/night cycles: Cg = 0 (default) activates the automatic programmes management for seasoning;...
  • Page 30 CHAP. 6 - Options VISION100 THR CHAPTER 6: OPTIONS TELENET SUPERVISION/MONITORING SYSTEM To insert the board in a TeleNET network, refer to the layout below. To configure the instrument, refer to the TeleNET manual. IMPORTANT: During configuration, select "Instrument PLUS 100 THR rel. 8 or higher"...
  • Page 31 CHAP. 7 - Diagnostic VISION100 THR CHAPTER 7: DIAGNOSTIC DIAGNOSTIC VISION100 THR In case of anomalies, the controller warns the operator using alarm codes shown by the display and an acoustic signal emitted by a buzzer inside the Operational console. In...

  • Page 32: Eu Declaration Of Conformity

    DEL FABBRICANTE: THIS DECLARATION OF CONFORMITY IS ISSUED UNDER THE EXCLUSIVE RESPONSIBILITY OF THE MANUFACTURER: PEGO S.r.l. Via Piacentina 6/b, 45030 Occhiobello (RO) – Italy – DENOMINAZIONE DEL PRODOTTO IN OGGETTO / DENOMINATION OF THE PRODUCT IN OBJECT MOD.: VISION100 THR IL PRODOTTO DI CUI SOPRA E’...

  • Page 33: Vision100 Thr Connection Layout

    Attachments VISION100 THR VISION100 THR CONNECTION LAYOUT Power supply section Outputs section (contacts without voltage) 1-2 Power supply 230VAC 50/60 Hz 21-22 Alarm Analogical inputs section 23-24 Defrosting 29-30 Evaporator NTC probe 25-26 Dehumidification 31-32 Humidity probe 4-20 mA 15-16 Refreshment (rin=0)/ low speed fans...
  • Page 34 VISION100 THR NOTES USE AND MAINTENANCE MANUAL Page 34 Rev. 02-18...
  • Page 35 Attachments VISION100 THR NOTES USE AND MAINTENANCE MANUAL Rev. 02-18 Page 35...
  • Page 36 Tel. +39 0425 762906 Fax +39 0425 762905 e.mail: info@pego.it – www.pego.it AFTER-SALES ASSISTANCE CENTRE Tel. +39 0425 762906 e.mail: tecnico@pego.it Distributor: USE AND MAINTENANCE MANUAL Page 36 Rev. 02-18 PEGO s.r.l. reserves the right to make amendments to this user manual at any moment.
