Refuelling a Vehicle

There can be up to three storage banks for CNG refuelling. During filling the dispenser
sequences through these banks from low to high as the pressure in the vehicle
cylinder increases and the flow rate drops.
Appropriate personal safety equipment should be worn whilst refuelling a vehicle.
To refuel a vehicle
▪ Press the start button or remove the nozzle from the holster to initiate a fill.
▪ The display will show 888888 and clear, at this point both the gas and
value totals will display 0. 0 0
▪ Connect the refuelling nozzle to the vehicle.
▪ Open the nozzle refuelling valve to commence filling.
▪ The dispenser will emit a long beep signalling the end of the fill, at this point
the gas total display flashes
▪ Close the refuelling valve.
NOTE: Closing the valve shuts off the gas from the dispenser. It also vents the gas
between the refuelling valve and coupling to the dispenser vent point.
▪ Disconnect the nozzle from the vehicle.
▪ Return the refuelling nozzle to the nozzle holder.
Fin.
