System Control

RC Receiver
For interfacing with RC receivers, WIRIS Pro is equipped with a S.BUS input. The S.BUS input, communica ng
control of mul ple servo inputs allows user to control the system remotely in flight.
It is recommended to use a joys ck for naviga on in the system menu. If connected as recommended, then the
behavior of the joys ck is as shown on the following image.
Digital Input
1
2
3-4
S.BUS receivers tested as func onal are:
FUTABA SBE-1
HITEC OPTIMA D
USB Keyboard
Besides the digital inputs, the Workswell WIRIS Pro system can be controlled also via USB keyboard.
E-mail and Web Mobile:
support@workswell.eu +420 725 877 063
www.workswell.eu
Func on
Up/Down
OK/Cancel
Op onal (shorcuts)
Digital Input
Up
Down
Enter
Escape
F5
F6
F7
F8 Thermal Camera Correc on (NUC)
+
-
Table 1 – RC Receiver behavior table
ID:
Reg. No.: 29048575
VAT No.: CZ29048575
Func on
Up
Down
OK/Menu
Cancel
Mode switch
Image capture
Video record
Zoom in
Zoom out
