3.5 Mechanical actuator used as shift

No. Alarm code
Miss acc msg
1
Miss disp msg
2
Miss troll msg
3
Miss head msg
4
Sensor pos fault
5
Sensor V fault
6
Sensor I fault
7
Over I fault
8
9 Brownout
10 Ecc fault
11 Watchdog fault
12 Pll fault
13 Miss parameters
page 28
of 36-
POWER A MK2
Meaning
The system has detected the lack of
CAN message of the throttle.
The system has detected the lack of
CAN message of the control unit.
The system has detected the lack of
CAN message of the troll.
The system has detected the lack of
CAN message of the control station.
The system has detected a problem
on the actuator position sensor.
The system has detected a problem
on the actuator power sensor.
The system has detected a problem
on the actuator current sensor.
The system has detected an
exceeding current absorption of the
actuator.
The system has detected a heavy
brownout that could have affected the
operation.
Problem in the control station
processor.
Problem in the control station
processor.
Problem in the control station
processor.
Problem in the control station
processor.
Owner's manual
Solution
Check the CAN bus connection or
the power cord of the unit
controlling the throttle.
Check the CAN bus connection
Check the CAN bus connection or
the power cord of the unit
controlling the trolling valve
Check the CAN bus connection
Contact the technical assistance
service to replace the actuator
Contact the technical assistance
service to replace the actuator
Contact the technical assistance
service to replace the actuator
Check if the mechanical cable is
intact and free to slide.
Check the electrical connections
that feed the system, check the
battery charge.
Contact the technical assistance
service to replace the control
station
Contact the technical assistance
service to replace the control
station
Contact the technical assistance
service to replace the control
station
Contact the technical assistance
service to replace the control
station
