  • Page 1 Installation and maintenance manual SINGLE LEVER CONTROL B505 ULTRAFLEX ® Dis. 36923  ...
  • Page 2 All ULTRAFLEX products are designed and built to provide the best possible performance for the purpose for which they were designed. To protect your safety and maintain top quality, ULTRAFLEX guarantees its products only if they are used with original parts (refer to “Application Spare Parts” annex).
  • Page 3: Table Of Contents

    ULTRAFLEX Installation and maintenance manual TABLE OF CONTENTS Use of this manual and symbols ......................4 Note ................................. 5 Warranty ..............................5 SECTION 1 ­ PRODUCT DESCRIPTION Product description and recommendations for use ............6 Dimensions and angles of the lever....................6 SECTION 2 ­...
  • Page 4: Use Of This Manual And Symbols

    Provide the personnel who will be installing the product with appropriate training and make sure that they understand and implement the instructions provided. page 4 ­ B505  of 15...
  • Page 5: Note

    ALL RIGHTS RESERVED. Rights to publication, trademarks, logos and photographs of ULTRAFLEX products present in this manual are the property of ULTRAFLEX and may not be reproduced in full or in part. Great care has been taken to collect and verify documentation to make this manual as complete and easy to understand as possible.
  • Page 6: Section 1 ­ Product Description

    The lever control is assembled on the dashboard close to the vessel’s helm. The lever has an adjustable clutch and the neutral detent has an adjustable detent force. The B505 has the possibility of many customizations. See the chart 3. 1.2 Dimensions 1.2 Dimensions...
  • Page 7 ULTRAFLEX Installation and maintenance manual The figure below shows the stroke angles of the B505 control. page 7 B505  ­ of 15...
  • Page 8: Section 2 ­ Installation

    Take care not to damage the sensor during installation. After determining the appropriate location, cut the hole required to install the control using the template provided. WARNING Dispose of packaging in accordance with the law. page 8 ­ B505  of 15...
  • Page 9: Detent And Clutch Adjusting

    Now you have access to the hole in which you can find a threaded screw. Use an allen wrench (Ø3) to regulate it, untill you find the desired clutch force. Turn it clockwise to risen the force on the clutch, turn counterclockwise to lower it page 9 B505  ­ of 15...
  • Page 10: Section 3 ­ Customizable Systems

    3.1.2 Voltage Throttle Sensor The B505 lever can install the Voltage Throttle sensor. In this case, the output is a tension in a range between the 0.5V to 4.5V. It is possible to modify the Throttle curve, the feeling and the reactivity of the lever.
  • Page 11: Trim Switch - Neutral Safety Lock

    The B505 can be supplied with the Trim Switch or the Neutral Safety Lock underneath the handle. 3.2.1 Trim Switch If the B505 lever has the Trim switch, it is possible command the position of the Trim Tabs on the stern of the boat.
  • Page 12: Keyboard

    Installation and maintenance manual 3.3 KEYBOARD The B505 lever has got a keyboard in the rear side. It has three rubber button integrated in the styling of the lever. Buttons are simple ON/OFF inputs signals. Buttons can be personalized or left black.
  • Page 13: Section 4 ­ Safety Warnings

    PLEASE FOLLOW CAREFULLY the precautions and safety criteria indicated below. ULTRAFLEX shall not be held liable for the user’s failure to observe these precautions and criteria and shall not be held liable for any negligence in use of the system.
  • Page 14: Section 5 ­ Maintenance

    - Replace damaged parts that may compromise the integrity of the control. 5.2 Special maintenance Technical assistance For any information or assistance with particular applications, you are invited to contact our technical assistance service (refer to “Note”). page 14 ­ B505  of 15...
  • Page 15: Section 6 ­ Dismantling

    If you intend not to use the single lever control system any more, dispose of it in an environmentally sound way. Sheaths, hoses and components made of plastic or other non-metallic materials must be dismantled and disposed of separately. page 15 B505  ­ of 15...
