3.2 V-throttle, I-throttle, PWM throttle, SAEJ-throttle
No. Alarm code
Miss shift msg
1
port
Miss disp msg
2
port
Miss troll msg
3
port
Miss head msg
4
port
Miss shift msg
5
stbd
Miss disp msg
6
stbd
Miss troll msg
7
stbd
Miss head msg
8
stbd
9 Brownout
10 Ecc fault
11 Watchdog fault
12 Pll fault
13 Miss parameters
Meaning
The system has detected the lack of
CAN message of the port shift.
The system has detected the lack of
CAN message of the port control unit.
The system has detected the lack of
CAN message of the port troll.
The system has detected the lack of
CAN message of the port control
station
The system has detected the lack of
CAN message of the starboard shift.
The system has detected the lack of
CAN message of the starboard
control unit
The system has detected the lack of
CAN message of the starboard troll.
The system has detected the lack of
CAN message of the starboard
control station
The system has detected a heavy
brownout that could have affected the
operation.
Problem in the throttle unit
processor.
Problem in the throttle unit
processor.
Problem in the throttle unit
processor.
Problem in the throttle unit
processor.
Owner's manual
Solution
Check the CAN bus connection or
the power cord of the unit
controlling the shift.
Check the CAN bus connection
Check the CAN bus connection or
the power cord of the unit
controlling the trolling valve
Check the CAN bus connection
Check the CAN bus connection or
the power cord of the unit
controlling the shift.
Check the CAN bus connection
Check the CAN bus connection or
the power cord of the unit
controlling the trolling valve
Check the CAN bus connection
Check the electrical connections
that feed the system, check the
battery charge.
Contact the technical assistance
service to replace the throttle unit
Contact the technical assistance
service to replace the throttle unit
Contact the technical assistance
service to replace the throttle unit
Contact the technical assistance
service to replace the throttle unit
