2010 MODEL 699 40FT DISC CULTIVATOR
ASSEMBLY AND PARTS MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 699 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Salford 699

  • Page 1 2010 MODEL 699 40FT DISC CULTIVATOR ASSEMBLY AND PARTS MANUAL...
  • Page 2: Table Of Contents

    2011 699-40' Disc Cultivator Assembly and Parts Manual Table of Contents General Information Salford Recommended Torque Values ......................3 General Safety Precautions ..........................4 Torque Values for Tires ..........................6 Pressure Values for Tires ..........................7 Frame & Tongue Wing Installation ............................8 Self Leveling Tower Assembly ........................10 Rear 5th Bar Layout ...........................12...
  • Page 3: General Information

    2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents General Information Salford Recommended Torque Values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
  • Page 4: General Safety Precautions

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual General Safety Precautions Signal Words The words DANGER, WARNING or CAUTION are used with the safety alert symbol. Learn to recognize safety alerts, follow recommended precautions and safe practices.
  • Page 5 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents General Safety Precautions DANGER  Wings may fall rapidly causing injury.  Always stay clear of wings when being lowered, raised or in a elevated state.  Always use lockup device provided when raised.
  • Page 6: Torque Values For Tires

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual Torque Values for Tires WARNING Maintain proper torque to provide safe and secure attachment of the wheel hub/drum. Improperly tightened wheel nuts can cause the wheel to separate from the wheel mounting surface during operation.
  • Page 7: Pressure Values For Tires

    2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents Pressure Values for Tires Ensure proper inflation of each tire for safe operation and extended tire life. Pressure [psi] Pressure [bar] Tire Size 25 [psi] 1.72 [bar] 23.1 x 26 (16 ply) 35 [psi] 2.41 [bar]...
  • Page 8: Frame & Tongue

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual Frame & Tongue Wing Installation Page 8 06-2011 Salford Farm Machinery Ltd.
  • Page 9 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents Wing Installation ITEM DESCRIPTION PART NO. HS3536 3 1/2" BORE x 36" STROKE HYD. CYLINDER GPHF1600338H04 1" x 3 3/8" SHOULDER PIN HARDENED W/FLATS GP1600512A05 PIN 1" DIA. x 5 1/2" LG. - 2 HOLES BF16S 1"...
  • Page 10: Self Leveling Tower Assembly

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual Self Leveling Tower Assembly 34ft & UP / RT99 24ft - 30ft 32ft & UNDER Page 10 06-2011 Salford Farm Machinery Ltd.
  • Page 11 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents Self Leveling Tower Assembly QTY. DESCRIPTION ITEM PART NO. C10575 550/570/699/700 TRIPOD TOWER C10668 570 TRIPOD BRACE C10990 699 SELF-LEVELING PIVOT HSR40095 4" BORE x 9 1/2" STROKE HYD. CYLINDER HSR35095 3 1/2"...
  • Page 12: Rear 5Th Bar Layout

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual Rear 6th Bar Layout 107cm 335cm 102cm 33cm 123cm 151cm 61cm 498cm FRONT 151cm Start here by lining up this extension with beam on main frame 47cm 123cm 33cm...
  • Page 13: Rear 5Th Bar Installation

    2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents Rear 6th Bar Installation REAR 5TH BAR INSTALLATION ITEM NO. QTY. PART NO. DESCRIPTION C10782 23" DOUBLE 3/4" U-BOLT EXTENSION C10783 23" SINGLE 3/4" U-BOLT EXTENSION UC40604132 CAPPED TUBE 4" x 6" x 1/4"W x 132" LG.
  • Page 14: Tongue Installation

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual Tongue Installation Page 14 06-2011 Salford Farm Machinery Ltd.
  • Page 15 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents Tongue Installation ITEM QTY PART NUMBER DESCRIPTION C10981 699 LITE TONGUE WELDMENT C10578 699 TONGUE WELDMENT C10579 699 TELESCOPE WELDMENT GPSPEC24080 1 1/2" x 8 1/4" LG. WING HINGE PIN BL10 5/8"...
  • Page 16: 699 Hose Holder Assembly

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual 699 Hose Holder Assembly ITEM PART DESCRIPTION NUMBER A60104 OPERATOR STATION/HOSE HOLDER G106 HD OPERATORS MANUAL HOLDER GL11750 LIGHT PLUG HOLDER - PLASTIC P0160B HOSE CLAMP 4" BC0205 10-24 x 1/2" A307A LOW CARBON ZINC CARRIAGE BOLT...
  • Page 17: Wheels And Axles

    2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents Wheel & Axle Layout Wheels and Axles Page 17 06-2011 Salford Farm Machinery Ltd.
  • Page 18: 699 Main Frame Axle Installation

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual 699 Main Frame Axle Installation Page 18 06-2011 Salford Farm Machinery Ltd.
  • Page 19 6. Apply grease to all fittings. Notice: Salford uses replaceable bushings (item 27 - 30). These are slightly oversized and need to be tapped into place with a hammer. When removing worn bushings, take care not to gouge the seat surface.
  • Page 20: 699 Wing Axle Installation

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual 699 Wing Axle Installation 66" (168cm) INITIAL SETTING LH RH LH SHOWN, RH SIMILAR Page 20 06-2011 Salford Farm Machinery Ltd.
  • Page 21 (14) and 5/8" locknuts (15). 5. Apply grease to all fittings. Notice: Salford uses replaceable bushings (Item 19 - 22). The bushings are oversized and will need to be tapped into place with a hammer. When removing worn bushings, take care not to gouge the seat surface.
  • Page 22: 14,000 Lb Tandem Axle Assembly

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual 14,000 lb Tandem Axle Assembly (12.5L x 15 HIGHWAY SERVICE TIRES) Page 22 06-2011 Salford Farm Machinery Ltd.
  • Page 23 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents 14,000 lb Tandem Axle Assembly (12.5L x 15 HIGHWAY SERVICE TIRES) ITEM PART NUMBER DESCRIPTION C00110L 14,000 LB UPRIGHT BEAM - LH C00111L 14,000 LB WALKING BEAM - LH...
  • Page 24: 8000 Lb Tandem Axle Assembly

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual 8000 lb Tandem Axle Assembly Page 24 06-2011 Salford Farm Machinery Ltd.
  • Page 25 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents 8000 lb Tandem Axle Assembly ITEM NO. PART NO. DESCRIPTION C5542L 8000 LB UPRIGHT BEAM - LH C5542R 8000 LB UPRIGHT BEAM - RH C5542WL 8000 LB WING UPRIGHT BEAM - LH...
  • Page 26: 8000 Lb Hub And Spindle Assembly

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual 8000 lb Hub and Spindle Assembly Page 26 06-2011 Salford Farm Machinery Ltd.
  • Page 27 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents 8000 lb Hub and Spindle Assembly ITEM NO. QTY PART NUMBER DESCRIPTION GW8014 SPINDLE, 8 000 LBS. GW8110VW 8000 LB V-SEAL GRASS WRAP GUARD GW8110VS 8000 LB V-SEAL GW8110VC...
  • Page 28: 5000 Lb Hub And Spindle Assembly

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual 5000 lb Hub and Spindle Assembly Page 28 06-2011 Salford Farm Machinery Ltd.
  • Page 29 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents 5000 lb Hub and Spindle Assembly ITEM QTY PART NO. DESCRIPTION GW5014 5000 LB SPINDLE-14 IN. LG 1 GW5110VW 5000 LB V-SEAL GRASS WRAP GUARD GW5110VS 5000 LB V-SEAL...
  • Page 30: Shank Assembly

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual Shank Assembly Shank Assembly and Parts 1) FOR 4" x 6" BEAM 2) FOR 3" x 6" BEAM 3) FOR 2 1/2" BEAM Page 30 06-2011 Salford Farm Machinery Ltd.
  • Page 31 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents Shank Assembly and Parts DESCRIPTION ITEM PART NO. BU1061 U-BOLT 5/8" x 6" x 5 1/2" BU1062 U-BOLT 5/8" x 6" x 4 1/2" BU1025 U-BOLT 5/8" x 2 1/2" x 4"...
  • Page 32: Shank Head Parts

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual Shank Head Parts DESCRIPTION ITEM PART NO. C90124 OUTER C-SHANK WELDMENT C90122 INNER C-SHANK WELDMENT A60059 1 OD-3/4 ID X 1 15/16" LONG BUSHING B1265 3/4"NC x 6 1/2" LG. HEX BOLT GR. 5 BN12J 3/4"...
  • Page 33: 40' Shank Layout

    2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents 40’ Shank Layout Page 33 06-2011 Salford Farm Machinery Ltd.
  • Page 34: Disc Gangs

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual Gang Mount Locations Disc Gangs Page 34 06-2011 Salford Farm Machinery Ltd.
  • Page 35: Disc Gang Layout

    2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents Disc Gang Layout Page 35 06-2011 Salford Farm Machinery Ltd.
  • Page 36: Disc Gang Installation

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual Disc Gang Installation Page 36 06-2011 Salford Farm Machinery Ltd.
  • Page 37 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents Disc Gang Installation ITEM NO. QTY. ITEM NO. QTY. PART NO. PART NO. DESCRIPTION DESCRIPTION C10773L C10773L 699 WING BOLT-ON GANG ANCHOR - LH 699 WING BOLT-ON GANG ANCHOR - LH...
  • Page 38 Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual Disc Gang Installation (continued from previous page) 6. Hang cylinders (10-13) from masts using 1" x 3 1/4" head pins (17) and 1/4" x 1 1/2" cotter pins (26). Cylinder locations are shown on gang layout drawing and gang cylinder hydraulic layout.
  • Page 39: Disc Gang Assembly And Scraper Installation

    2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents Disc Gang Assembly and Scraper Installation ITEM NO. PART NO. DESCRIPTION D10018R DISC SCRAPER BLADE - RIGHT D10018L DISC SCRAPER BLADE - LEFT BU0820 1/2" x 2 x 3 U-BOLT BN08L 1/2"...
  • Page 40: C-Flex Gang Hanger Assembly

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual C-Flex Gang Hanger Assembly Replacement bearing insert Only needed with Assemble with grease 1 3/4" ID bearings fittings pointing forward Page 40 06-2011 Salford Farm Machinery Ltd.
  • Page 41 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents C-Flex Gang Hanger Assembly ITEM PART NO. QTY DESCRIPTION NUMBER D10023 1 1/4" C-FLEX SPRING L00676 C-FLEX GANG MOUNTING TUBE PLATES B1285 3/4"NC x 8 1/2" LG. HEX BOLT GR.5 B1235 3/4 x 3 1/2"...
  • Page 42: Disc Gang Parts

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual Disc Gang Parts Page 42 06-2011 Salford Farm Machinery Ltd.
  • Page 43 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents Disc Gang Parts ITEM NO. PART NO. ITEM NO. PART NO. DESCRIPTION DESCRIPTION CT5030 CT5030 22" x 6.5mm NOTCHED CURVED BLADE 22" x 6.5mm NOTCHED CURVED BLADE CT5028 CT5028 20"...
  • Page 44: Disc Gang Depth Indicator

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual Disc Gang Depth Indicator ITEM NO. QTY. PART NO. DESCRIPTION C10971 699 GANG DEPTH POINTER BRACKET C10972 699 GANG DEPTH POINTER BN10S 5/8" NC STOVER LOCK NUT BU1043 U-BOLT 5/8" x 4" x 4 1/2"...
  • Page 45: Harrow Layout

    2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents Harrow Layout Harrows Page 45 06-2011 Salford Farm Machinery Ltd.
  • Page 46: Harrow Installation

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual Harrow Installation Page 46 06-2011 Salford Farm Machinery Ltd.
  • Page 47 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents Harrow Installation ITEM NO. PART NUMBER DESCRIPTION RB1091 62" HARROW ARM ASSEMBLY BU1061 U-BOLT 5/8" x 6" x 5 1/2" BN10L 5/8" NYLOCK NUT NC BU0825 1/2" x 2 1/2 x 3 1/2 U-BOLT BN08L 1/2"...
  • Page 48: 62 Inch Long Harrow Arm Assembly

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual 62 Inch Long Harrow Arm Assembly Page 48 06-2011 Salford Farm Machinery Ltd.
  • Page 49 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents 62 Inch Long Harrow Arm Assembly ITEM NO. QTY. PART NO. DESCRIPTION R30012 PARALLEL LINKAGE BAR R30006 PARALLEL LINKAGE ARM R80099 HEAD,SALFORD HARROW FOR 5/8" UPPER PIVOT BOLT R80100 62"...
  • Page 50: 1/2" Tine Harrow Assemblies

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual 1/2” Tine Harrow Assemblies Page 50 06-2011 Salford Farm Machinery Ltd.
  • Page 51: 1/2" Tine Harrow Assemblies

    2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents 1/2” Tine Harrow Assemblies 1/2" - 3 TINE HARROW ASSEMBLY PART NO. R633 ITEM NO. PART NO. DESCRIPTION U252503054 TUBE 2 1/2 x 2 1/2 x 3/16"W x 54" LG.
  • Page 52: 14" Roller Harrow Assemblies

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual 14” Roller Harrow Assemblies Page 52 06-2011 Salford Farm Machinery Ltd.
  • Page 53 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents 14” Roller Harrow Assemblies 14" ROLLER HARROW ASSEMBLY - 3' 0" (91.4) LONG COMPLETE ASSEMBLY PART NO. MR80143(L/R) ITEM NO. QTY. PART NO. DESCRIPTION ITEM NO. QTY. PART NO. DESCRIPTION R80147R 3' ROLLER ONLY RIGHT HAND SPIRAL, 14"...
  • Page 54: Harrow Settings

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual Harrow Settings HARROW SETTINGS Page 54 06-2011 Salford Farm Machinery Ltd.
  • Page 55: Harrow Tine Settings

    2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents Harrow Tine Settings For better trash flow, the tines are adjustable in 2 ways: use bottom bolt hole for 'standard' setting. Shown here is the 'standard' setting use top bolt...
  • Page 56: Hydraulics & Lights

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual Hydraulics & Lights Axle Lift Hydraulics Page 56 06-2011 Salford Farm Machinery Ltd.
  • Page 57 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents Axle Lift Hydraulics LABEL LENGTH FROM (cm) TRACTOR STROKE CONTROL VALVE INLET STROKE CONTROL VALVE OUTLET TEE AT BASE OF LEFT 40095 [A] TEE AT BASE OF LEFT 40095 [A]...
  • Page 58: Wing Lift Hydraulics

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual Wing Lift Hydraulics Page 58 06-2011 Salford Farm Machinery Ltd.
  • Page 59 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents Wing Lift Hydraulics LABEL QTY. LENGTH FROM HOSE SIZE END SIZES 20' 6" TRACTOR (GREEN) MANIFOLD 1/2" 3/8" - 1/2" 20' 6" TRACTOR (GREEN-GREY) MANIFOLD 1/2" 3/8" - 1/2"...
  • Page 60: 699 Disc Gang Hydraulics

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual 699 Disc Gang Hydraulics Page 60 06-2011 Salford Farm Machinery Ltd.
  • Page 61 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents 699 Disc Gang Hydraulics LENGTH LABEL FROM (cm) 1082 TRACTOR BASE OF 4008 [A] ROD OF 4008 [A] BASE OF 3708 [B] ROD OF 3708 [B] BASE OF 3508 [C]...
  • Page 62: Lights & Smv Install

    Return to Contents 2011 699-40' Disc Cultivator Assembly and Parts Manual Lights & SMV Install Page 62 06-2011 Salford Farm Machinery Ltd.
  • Page 63 2011 699-40' Disc Cultivator Assembly and Parts Manual Return to Contents Lights & SMV Install ITEM QTY PART NO. DESCRIPTION A60054 LIGHT BRACKET (LONG) L00425 OUTSIDE LIGHT MOUNTING PLATE C1011 SMV MOUNTING BRACKET GAP103NS SMV SIGN BN06L 3/8"-16NC LOCK NUT B0610 3/8 X 1"...
  • Page 64 Salford Farm Machinery Ltd. 364018 McBeth Road, N0J 1W0 Salford, Ontario Canada www.salfordmachine.com 1-866-442-1293...
