ZooZ ZEN15 VER. 2.0 User Manual

USER MANUAL
POWER SWITCH
ZEN15 VER. 2.0
www.getzooz.com
FEATURES
Z-Wave on/off control of large appliances up to 15A
Ÿ
Energy monitoring live and over time
Ÿ
On/off status recovery a er power failure
Ÿ
LED indicator to display Z-Wave signal strength and
Ÿ
power usage for the connected device
AES signal encryption for safer communication
Ÿ
Z-Wave Plus signal repeater to extend network range
Ÿ
Built-in overload protection and ETL certification
Ÿ
SPECIFICATIONS
Model Number: ZEN15 VER. 2.0
Ÿ
Z-Wave Signal Frequency: 908.42 MHz
Ÿ
Power: 120 VAC, 60 Hz
Ÿ
Maximum Load: 15 A, 1800 W
Ÿ
Operating Temperature: 14 – 104 F
Ÿ
Range: Up to 130 feet line of sight
Ÿ
Installation and Use: Indoor only
Ÿ
Dimensions: 20" (with cord) x 2.6" x 1.1"
Ÿ
Weight: 10oz
Ÿ
CAUTION
This is an electrical device - please use caution when
installing and operating the Power Switch. Remote
control of appliances may result in unintentional or
automated activation of power. Do NOT use this Z-
Wave device to control electric heaters or other
appliances which produce the risk of fire, burns, or
electrical shock when unattended.
INSTALLATION
Plug the Power Switch into any standard grounded
120 V receptacle. Do NOT connect any devices to the
plug at this point. Click the Z-Wave button to see if the
LED indicator changes color. If the LED indicator
doesn't light up at all, please try a different receptacle.
If it's still off, please get in touch with our support
team: ask@getzooz.com
BEFORE YOU PLUG ANYTHING IN
Make sure the load you are about to connect
does NOT exceed 15 A in power. This Power Switch
can hold up to 15 A in total.
Connecting 220 V equipment to this Power
Switch will DAMAGE the device and may cause
the connected appliance to malfunction.
X
DON'T USE WITH
220 V Boilers
Ÿ
220 V Pumps /
Ÿ
Compressors
Electrical Dryers
Ÿ
Chargers
Ÿ
Electric heaters
Ÿ
Routers
Ÿ
WARNING
This product should be installed indoors upon
Ÿ
completion of any building renovations.
Prior to installation, the device should be stored in a
Ÿ
dry, dust-and-mold-proof place.
Do not install the Smart Switch in a place with direct
Ÿ
sun exposure, high temperature, or humidity.
Keep away from chemicals, water, and dust.
Ÿ
Ensure the device is never close to any heat source or
Ÿ
open flame to prevent fire.
Ensure the device is connected to an electric power
Ÿ
source that does not exceed the maximum load power.
No part of the device may be replaced or repaired by
Ÿ
the user.
OK. TO USE WITH
(De)humidifiers
Ÿ
Window AC units
Ÿ
Sump pumps
Ÿ
Gas Dryers
Ÿ
Refrigerators
Ÿ
Floor Lamps
Ÿ
Tv's and Video
Ÿ
Computers
Ÿ
PAGE 1
Z-WAVE CONTROL
1. ADD DEVICE to your hub
Initiate inclusion (pairing) in the app (or
web interface). Not sure how? Get step-by-step
instructions for adding the plug to SmartThings, Vera,
Wink and other hubs here: www.support.getzooz.com
2. PLUG the ZEN15 into a receptacle
The LED indicator will start flashing and the plug will
join the network automatically.
MANUAL INCLUSION
Put your Z-Wave hub into inclusion
and click the Z-Wave Button 3
times quickly.
SECURE INCLUSION
Put your Z-Wave hub into secure
inclusion, then press and HOLD the
Z-Wave Button for at least 3 seconds.
TROUBLESHOOTING
The Power Switch won't add to your hub? Try this:
1. Initiate EXCLUSION and click the Z-Wave button 3
times quickly.
2. Click the Z-Wave button 4-5 times quickly when
adding it or try adding it in a non-secure mode.
3. Bring the Power Switch closer to your hub, it may be
out of range.
4. Double-check if the device is powered.
5. Get troubleshooting tips for your hub at
www.support.getzooz.com
EXCLUSION (REMOVING / UNPAIRING DEVICE)
1. Bring the Power Switch within direct range of your Z-
Wave gateway (hub).
2. Put the Z-Wave hub into exclusion mode (not sure
how to do that? ask@getzooz.com).
3. Press and release the Z-Wave button 3 times quickly.
4. Your hub will confirm exclusion and the Switch will
disappear from your controller's device list.
FACTORY RESET
When your network's primary controller is missing or
otherwise inoperable, you may need to reset the device
to factory settings manually. In order to complete the
process, plug the Power Switch into a grounded
receptacle, then PRESS AND HOLD the Z-Wave button
for AT LEAST 20 SECONDS. The LED indicator will flash
orange and then stay solid orange for 2 seconds to
indicate successful reset. The Switch will then turn off.
NOTE: You may only reset your Power Switch once it
has been included to a Z-Wave network.
All previously recorded activity and custom settings will
be erased from the device's memory.
This product is covered under a 12-month limited
warranty. To read the full warranty policy or file a
warranty claim, please go to ww.getzooz.com/warranty
IN NO EVENT SHALL ZOOZ OR ITS SUBSIDIARIES AND AFFILIATES BE LIABLE
FOR ANY INDIRECT, INCIDENTAL, PUNITIVE, SPECIAL, OR CONSEQUENTIAL
DAMAGES, OR DAMAGES FOR LOSS OF PROFITS, REVENUE, OR USE
INCURRED BY CUSTOMER OR ANY THIRD PARTY, WHE-THER IN AN ACTION IN
CONTRACT, OR OTHERWISE EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DA-MAGES. ZOOZ'S LIABILITY AND CUSTOMER'S EXCLUSIVE REMEDY FOR
ANY CAUSE OF ACTION ARISING IN CON-NECTION WITH THIS AGREEMENT
OR THE SALE OR USE OF THE PRODUCTS, WHETHER BASED ON
NEGLIGENCE, STRICT LIABILITY, BREACH OF WARRANTY, BREACH OF
AGREEMENT, OR EQUITABLE PRINCIPLES, IS EXPRESSLY LIMITED TO, AT
ZOOZ'S OPTION, REPLACEMENT OF, OR REPAYMENT OF THE PURCHASE
PRICE FOR THAT POR-TION OF PRODUCTS WITH RESPECT TO WHICH DA-
MAGES ARE CLAIMED. ALL CLAIMS OF ANY KIND ARISING IN CONNECTION
WITH THIS AGREEMENT OR THE SALE OR USE OF PRODUCTS SHALL BE
DEEMED WAIVED UNLESS MADE IN WRITING WITHIN THIRTY (30) DAYS FROM
ZOOZ'S DELIVERY, OR THE DATE FIXED FOR DELI-VERY IN THE EVENT OF
NONDELIVERY.
FCC NOTE
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY
TO OPERATE THE EQUIPMENT. STORE INDOORS WHEN NOT IN USE.
SUITABLE FOR DRY LOCATIONS ONLY. DO NOT IMMERSE IN WATER. NOT FOR
USE WHERE DIRECTLY EXPOSED TO WATER.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following conditions:
1. This device may not cause harmful interference,
2. This device must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used according to instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in any given
installation.
If this equipment causes harmful interference to radio or television
reception, the user may try to correct the interference by taking one or more
of the following measures:
- Reorient or relocate receiving antenna
- Increase the separation between equipment and receiver
- Connect equipment into a separate outlet or circuit from receiver
- Consult the dealer or an experienced radio/TV technician for additional
assistance
All brand names displayed are trademarks of their respective holders.
© Zooz 2018
Z-WAVE
BUTTON
WARRANTY
PAGE 2
