Become Familiar with the Device

1
4
1.
Microphone:
anticipation of potential future features.
2. The speaker is used for:
Speaker:
MP3 file playback (the music format to
which stored CDs are converted)
Intercom (a potential future feature)
3. This dial is used during and after
Select Dial:
setup:
During setup: Press the select dial to have
Mini Touch Screen identify itself to the
system.
After setup: Rotate select dial to scroll
through displays. Press select dial to
choose currently highlighted item on the
screen.
4.
Shortcut Button:
programmed by your installer to perform any
action or sequence of actions supported by
the system.
This microphone is in place in
This backlit button can be
2
3
4
