Dual-Ride Glider
Glider
Glider
Glider End
x2
Lock Nut
x6
Specifications subject to change without notice. Les spécifications expsent pout changer sans la notification. Las especificaciones sujetas cambiar sin nota.
Manufactured for / fabriqué pour / fabricado para: Backyard Play Systems • 1000 Ternes Drive, Monroe, MI 48162 • USA • 1-866-890-2211 • customerservice@backyard-play.com
Made in China / Fait en China / Hecho en China • Printed in China / Imprimé en China / Impreso en China
WARNING: Assembly by adult.
AVERTISSEMENT: L'assemblage dolt être exécuté par un adulte.
ADVERTENCIA: El ensamblaje lo debe hacer un adulto.
WARNING: Assembly by adult.
AVERTISSEMENT: L'assemblage dolt être exécuté par un adulte.
ADVERTENCIA: El ensamblaje lo debe hacer un adulto.
Glider Chain
x4
Flat Washer
Hex Bolt x2
CUBO DE DE LLAVE DE
Glider Seat
x12
1
Tools required:
Outils requis:
Herramientas requeridas:
WRENCH
TAPE MEASURE
CLÉ
RUBAN À MESURER
LLAVE
CINTAMÉTRICA
SOCKET & WRENCH
SCREWDRIVER
DOUILLE ET CLÉ DE
TOURNEVIS
DESTORNILLADOR
TRINQUETE
x1
Eye Bolt x4
NE 3452
WS 3452
Quick Link
x6
LA 7422
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Swing-N-Slide NE 3452
Summary of Contents for Swing-N-Slide NE 3452
- Page 1 Dual-Ride Glider NE 3452 WS 3452 Glider WARNING: Assembly by adult. AVERTISSEMENT: L’assemblage dolt être exécuté par un adulte. ADVERTENCIA: El ensamblaje lo debe hacer un adulto. Glider WARNING: Assembly by adult. AVERTISSEMENT: L’assemblage dolt être exécuté par un adulte.
- Page 2 GLIDER ASSEMBLE IMPORTANT! Even though some hardware may be inserted by manufacturer, tighten all Lock-Nuts as indicated to verify they are fully engaged. Eye bolts should be oriented perpendicular with Glider seat. Eye Bolt TOP VIEW It is helpful to use a screwdriver to hold eye bolt in place when tightening lock nut.
- Page 3 Quick Link Glider Chain Chain End Link Tighten clips securely with a wrench. 8” minimum between Glider and ground. Adjust Chains at Top. GLIDER FINAL INSPECTION !IMPORTANT! Inspect and confirm tightness of all Lock-Nuts and Quick Clips. !IMPORTANT! Attach (2) Chains per Swing Hanger (not included) using quick links 8”...
