- Page 1 1594A/1595A Super-Thermometer User’s Guide 159X____ugeng0000...
- Page 2 Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is avail- able if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable interna- tional price.
-
Page 3: Table Of Contents
Table of Contents Before you start................1 1.1 Symbols used ..................1 1.2 Safety information ..................1 1.2.1 WARNINGS .....................1 1.2.2 CAUTIONS ......................2 1.3 Authorized service centers ............... 2 Introduction and specifications ..........5 2.1 Introduction ....................5 2.2 Specifications ................... 5 2.2.1 General ......................5 2.2.2 Primary specifications ..................6 Resistance ratio accuracy ...................... 6 Resistor Stability ........................ - Page 4 1594A/1595ASuper-Thermometer 4.5 Menu structure ..................19 Getting started ...............23 5.1 Powering on the Super-Thermometer ............. 23 5.2 User settings screen ................23 5.3 Connecting a probe or resistor ............... 24 Making measurements ............27 6.1 Introduction ..................... 27 6.2 Temperature measurement ..............27 6.3 Ratio Measurement ................. 28 6.4 Using an External Resistor..............28...
- Page 5 Figures Figure 1 PEM (Power Entry Module) ..............12 Figure 2 Front view ..................13 Figure 3 Front panel display ................15 Figure 4 Rear view ................... 16 Figure 5 External resistor inputs ..............16 Figure 6 Power Entry Module ................18 Figure 7 Input wiring ..................24...
- Page 6 1594A/1595ASuper-Thermometer Tables Table 1 Symbols ....................1 Table 2 Resistance ratio accuracy specifications ..........6 Table 3 Resistor stability specifications ............. 7 Table 4 Absolute resistance accuracy specifications ........7 Table 5 Measurement current accuracy specifications ........8 Table 6 Temperature measurement noise specifications........8 Table 7 Relative measurement current specifications ........8 Table 8 General Specifications ................9 Table 9 Optional accessories ................11 Table 10 Front panel key descriptions ............. 14 Table 11 Remote operation connections ............17 Table 12 Recommended Reference Resistors and Sensing Current ....28...
-
Page 7: Before You Start
Beforeyoustart Safetyinformation 1 Before you start 1.1 Symbols used Table 1 lists the symbols that may be used on the instrument or in this manual and the meaning of each symbol. Table 1 Symbols Symbol Description Symbol Description AC (Alternating Current) PE Ground AC-DC Hot Surface (Burn Hazard) -
Page 8: Cautions
DO NOT connect AC voltage to any input terminal on the instrument. Permanent damage to the ● ● instrument will result. 1.3 Authorized service centers Please contact one of the following authorized Service Centers to coordinate service on your Fluke product: Fluke Corporation 799 E. Utah Valley Drive American Fork, UT 84003-9775 Phone: +1.801.763.1600 Telefax: +1.801.763.1010... - Page 9 Beforeyoustart Authorizedservicecenters Fluke South East Asia Pte Ltd. Fluke ASEAN Regional Office Service Center 60 Alexandra Terrace #03-16 The Comtech (Lobby D) 118502 SINGAPORE Phone: +65 6799-5588 Telefax: +65 6799-5588 E-mail: antng@singa.fluke.com When contacting these Service Centers for support, please have the following information available: Model Number ●...
-
Page 11: Introduction And Specifications
The Hart Scientific 1594A and 1595A Super-Thermometers continue this legacy adding new patent pending measurement technology and features that truly are best in class. Below is a summary of key capabilities and features. -
Page 12: Primary Specifications
Performance verification is guaranteed for 99% confidence level specifications within the specified operating temperature range of 15°C to 30°C. The listed uncertainties are in terms of parts-per-million (ppm) of reading unless stated otherwise. Table 2 Resistance ratio accuracy specifications 1594A accuracy 1595A accuracy Ratio range (ppm of reading) -
Page 13: Absolute Resistance Accuracy
Introductionandspecifications Specifications Table 3 Resistor stability specifications Resistor (Rs) Accuracy (ppm of reading) 24 hours 30 days 1 W 5 ppm 10 ppm 10 W 0.5 ppm 2 ppm 25 W 0.25 ppm 1 ppm 100 W 0.2 ppm 1 ppm 10 kW 0.25 ppm 1 ppm Absolute resistance accuracy Absolute resistance accuracy is the ability of the instrument to measure absolute resistance, Rx, using the... -
Page 14: Ancillary Specifications
1594A/1595ASuper-Thermometer Specifications Table 5 Measurement current accuracy specifications Current Range Accuracy 99% confidence level, 1-year 0.001 mA to 0.005 mA 0.00005 mA 0.005 mA to 0.02 mA 0.02 mA to 0.2 mA 0.5 % 0.2 mA to 2 mA 0.2 % 2 mA to 20 mA 0.5 %... -
Page 15: General Specifications
Introductionandspecifications Specifications 2.2.4 General Specifications Table 8 General Specifications Warm-up period 30 minutes Measurement range 0 W to 500 kW Measurement current range 0.001 mA to 20 mA Measurement current reversal interval: Sample period of 1 second or 2 seconds 0.2 second Sample period of 5 second or 10 seconds 1.2 second Standby current range... -
Page 17: Preparation For Operation
Super-Thermometer. It also includes instructions for remote operation, calibration and mainte- nance. The Technical Guide is available in English only. For ordering a replacement instruction manual CD contact your local Fluke representative or service center. All manuals are available online for download in PDF format. -
Page 18: Connecting To Line Power
1594A/1595ASuper-Thermometer ConnectingtoLinePower 1. Disconnect line power. 2. Observe what line voltage setting is displayed in the PEM window. If it is correct, the fuse assembly will be re-inserted in the same orientation it is removed. Otherwise, it will need to be rotated 180°... -
Page 19: Features
Features Frontpanelfeatures 4 Features 4.1 Introduction The Super-Thermometer has been designed with several features that help make setup and operation as simple as possible while still providing many measurement capabilities. This section describes the front and rear panel features as well as the menu system. Please read this section before operating the instrument. 4.2 Front panel features Figure 2 Front view 4.2.1... -
Page 20: Front Panel Keys
1594A/1595ASuper-Thermometer Frontpanelfeatures 4.2.3 Front panel keys Table 10 Front panel key descriptions The Power Standby key turns off the display and disables the front panel keys, sending the system into standby. Power remains applied to some internal components such as the resistor oven. -
Page 21: Front Panel Display
Features Frontpanelfeatures Front panel display The Front Panel Display is shown in Figure 3 on this page. The display screen is used to show all measure- ments, menus and configuration information. Figure 3 Front panel display The default display language is English. The display can be shown in the following language options: Eng- lish, Chinese, Spanish, Japanese, German, French, and Russian. -
Page 22: Rear Panel Features
1594A/1595ASuper-Thermometer Rearpanelfeatures 4.3 Rear panel features Figure 4 Rear view External resistor inputs Figure 5 External resistor inputs The Rs1 and Rs2 external reference resistor connections are located on the rear panel. The Current (C1, C2), Potential (P1, P2) and Guard (G) terminals are labeled to facilitate proper connection (see Figure 7 on page 24). -
Page 23: Future Peripheral Connection
Features Rearpanelfeatures 4.3.2 Future peripheral connection A USB peripheral port is intended for future peripheral control. Note: This port is NOT used for external memory connection. For external memory via USB see Section 4.2.2, USB connection, on page 13 and Figure 2 on page 13. 4.3.3 Remote Operation Connections The Super-Thermometer comes equipped with several remote operation connections. -
Page 24: Line Voltage Connection
1594A/1595ASuper-Thermometer Menusystemfeatures 4.3.4 Line voltage connection Figure 6 Power Entry Module The PEM (Power Entry Module) located on the rear panel connects the Super-Thermometer to line voltage. It contains the Line Voltage Power Switch, the Line Voltage Fuses, and the Line Voltage Selector. See the Line Voltage and Fuses section for configuration and connection instructions. -
Page 25: Main Menu Screen
Features Menustructure 4.4.3 Main menu screen Contains the menus and screens needed for configuration of the Super-Thermometer and its ● ● measurements. Directly accessed from any screen by pressing the MENU key. ● ● 4.4.4 Channel setup screen Contains the function keys needed to allow the user to quickly configure measurements including the ●... - Page 26 1594A/1595ASuper-Thermometer Menustructure ADD PROBE COPY PROBE EDIT PROBE TEST CALCULATION READ PROBE MANAGE PROBES READ FILE WRITE FILE MOVE UP MOVE DOWN DELETE PROBE MEASURE MENU SCAN SETTINGS TIMING SETTINGS DIGITAL FILTER RECORDING MENU RECORDING SETTINGS VIEW DATA READ FILE...
- Page 27 Features Menustructure RECALL CONFIG DELETE CONFIG RESTORE DEFAULT UPDATE FIRMWARE PASSWORD CALIBRATION SYSTEM TEST CURRENT TEST RATIO CALIBRATION RESISTANCE CALIBRATION CALIBRATION PARAMETERS...
-
Page 29: Getting Started
Gettingstarted Usersettingsscreen 5 Getting started 5.1 Powering on the Super-Thermometer CAUTION: Before powering the Super-Thermometer on, ensure that the line voltage selection is set properly. Refer to Section 3.3, Line voltage and fuses, on page 11 for instructions. Power the Super-Thermometer on by setting the power switch located on the back panel to the On position. After power is on, pressing the Power Standby switch on the front panel puts the system into hibernation, leav- ing key components such as the resistor oven powered on. -
Page 30: Connecting A Probe Or Resistor
1594A/1595ASuper-Thermometer Connectingaprobeorresistor KEYPAD BEEP- enables (ON) or disables (OFF) the audio indication that accompanies each key-press. The default option is ON. START-UP HELP- determines whether the User Settings screen appears automatically after power-on. When the settings is ON the User Settings screen will appear every time the power is switched on. If the setting is OFF the Measurement screen will appear instead. - Page 31 Gettingstarted Connectingaprobeorresistor The DWF connectors are labeled with C1, C2 (current connections) and P1, P2 (measurement potential con- nections). The guard connector is labeled with a “G” and is used for connecting to a probe or resistor guard or shield. The guard connection may help reduce measurement noise. Connect a probe or resistor, as specified by the device’s manufacturer, to any one of the four measurement channels located on the front panel.
-
Page 33: Making Measurements
Makingmeasurements Temperaturemeasurement 6 Making measurements 6.1 Introduction The Super-Thermometer has been designed to allow quick and easy measurement setup while providing flex- ible measurement options. A measurement setup varies with the type of measurement being performed. The purpose of the following sections is to guide the user through the setup of typical measurements. Refer to the Technical Guide for more detailed information concerning measurement setup. -
Page 34: Ratio Measurement
1594A/1595ASuper-Thermometer RatioMeasurement Table 12 Recommended Reference Resistors and Sensing Current Probe Type Reference Resistance Sensing Current 25 W SPRT 25 W 1.0 mA 100 W PRT or RTD 100 W 1.0 mA 2.5 W SPRT 10 W 5.0 mA 0.25 W SPRT 14.14 mA... -
Page 35: Maintenance
Maintenance 7 Maintenance Avoid operating the instrument in excessively wet, oily, dusty, or dirty environments. If the outside of the instrument becomes soiled it may be wiped clean with a damp cloth and mild detergent. DO NOT use harsh chemicals on the surface that may damage the paint or plastic.
