Page 16
13.0 Special Functions
13.1
Hidden Lock for SimonsVoss VdS Shuntlock 3066
The Wireless Keypad can be used for activating SimonsVoss activation units (VdS
Shuntlock 3066). This is done by mounting the Keypad within the transmitting range
of the activation unit. After you have input the correct PIN, the activation unit is
addressed and the alarm system is activated or deactivated via the shuntlock. This
allows the requirements of VdS Class C up to SG 6 to be fulfilled by including a
hidden lock.
The VdS-certified activation units from SimonsVoss need a doubled opening protocol
for activation/deactivation procedures (double-click when the transponder should
activate or deactivate the system).
The following explains the configuration of the Wireless Keypad in order to have it
emulate the "double-click" and consequently be suitable for carrying out activation or
deactivation procedures.
1.
Press the "0" button three times.
2.
Input the master PIN.
3.
Then press:
•
either "91" for normal operation (default setting)
•
or "92" for a double-click for shuntlock operation.
If the input was correct, the Wireless Keypad stores the change and gives a positive
acknowledgement (LED and buzzer).
Wireless Keypad: TRA.PINCODE
Input "000"
Input "master PIN"
Input "91" (nor-
mal operation)
Input "92"
(shuntlock opera-
tion)
