Summary of Contents for Grundig Diginotice
- Page 1 DIGINOTICE ENGLISH...
- Page 2 CONTROL ELEMENTS ______ Safety lock »HOLD« Recording pilot lamp (LED) LCD display Menu button »MENU« Loudspeaker Built-in microphone (MIC.) Erase button»ERASE« Recording/pause button »REC/PAUSE« Select/volume button » + VOL–« Play/pause button »PLAY/PAUSE« Stop button »STOP« Earphone socket (EAR Socket for external microphone (EXT.MIC.
- Page 3 LCD DISPLAY ______________ CLOCK Dictation folder (A, B) Playback volume (VOL) Battery state ( Recording time (MM:SS) or clock time (HH:MM) Clock setting (CLOCK) Sound signal setting ( ) 7. Voice activation setting (VA) Playback ( ) • Recording ( Pause (II) Erase (ERASE) Recording mode (LP, SP)
-
Page 4: Putting Into Operation
OPERATION _______________ 1. Putting into operation Inserting batteries Insert 2 AAA (LR03) alcaline batteries into the battery compartment of the dictation machine. – The current settings are shown in the display. Battery display The battery symbol in the display shows the remaining battery capacity in six levels: »... -
Page 5: Power Saving Mode
OPERATION _______________ 3. Power saving mode In the power saving mode, no control func- tion is possible. – Only the current clock time and the battery state are indicated in the display. A pressure on any button (except the »STOP« button) ends the power saving mode and switches the dictation machine in normal operating mode. -
Page 6: Recording Pause
OPERATION _______________ 6. Recording To start recording, press the »REC/PAUSE« button. During recording, the red LED is per- • manently lit and the recording symbol » « is visible in the display. – The display shows the current dictation number and the elapsed recording time in •... -
Page 7: Playback Volume
OPERATION _______________ 7. Playback To play back a dictation, press the »PLAY/ PAUSE« button. – The current recording is played back. – The display shows the remaining playing time of the current recording (backward counting). To play back a certain dictation, it is neces- sary to first open the folder »A«... -
Page 8: Deleting Dictations
OPERATION _______________ 8. Deleting dictations Deleting a certain dictation Select the number of the dictation to be deleted then press the »ERASE«- button. – »ERASE« flashes in the display. Press the »ERASE« button again. – The selected dictation is deleted. –... -
Page 9: Using An Earphone
Diginotice to a PC, CD-recorder or cassette recorder. For that, the supplied phono cable must be connected with the »EAR « socke on the Diginotice and the Line-In input of the recorder. Start the recorder. Press the »PLAY/PAUSE« button. Set the output level using the » + VOL–«... -
Page 10: Changing Settings
SETTINGS __________________ 1. Activating the settings When in normal operating mode, press and hold down the »MENU« button until »LP« or »SP« flashes in the display. Repeatedly pressing the »MENU« button selects one after the other the following settings in the display: –... -
Page 11: Sound Signal
3. Ending the settings When the last setting is completed (clock time), pressing the »MENU« button switches the Diginotice back in normal operating mode. If one or several settings have been carried out, the Diginotice switches automatically in the normal operating mode and activates all settings about 15 seconds after the last pressure of a button. -
Page 12: Technical Data
TECHNICAL DATA __________ Frequency response: 300-3.500 Hz Sampling rate: AtPLL-3.6864 MHz, 7.2 kHz Compressions rate AtPLL-3.6864 MHz, 4.4 kHz Microphone: Capacitor microphone (mono) Output: Earphone (mini plug, mono), 1 MP in 16 Ohm (preferably 32 Ohm) Maximum output power: 90 mW in 64 Ohm Power supply: 3 V =, LR03, two alcaline batteries (AAA or UM-4)
